1.创建项目

1
2
# 现在
npx create-react-app admin-react-app --template typescript

熟悉目录结构

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
- admin-app
	-node_modules
	-public
	-src
		App.css
		App.test.tsx App.tsx的测试文件  npm run test 查看测试结果
		App.tsx
		index.css
		index.tsx react应用程序的入口文件
		logo.svg
		react-app-env.d.ts // 声明文件 // 指令声明对包的依赖关系
		reportWebVitals.ts // 测试性能
		seupTests.ts // 使用jest做为测试工具
	.gitignore
	package-lock.json
	package.json
	README.md
	tsconfig.json

*.d.ts 代表ts的声明文件

2.改造目录结构

1
2
3
4
5
6
7
8
9
10
11
12
13
14
src
	api
	components
	layout
	store
	router
	utils
	views
	App.tsx
	index.tsx
	logo.svg
	react-app-env.d.ts
	reportWebVitals.ts
  seupTests.ts
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
// src/index.js
import React from 'react';
import ReactDOM from 'react-dom/client';
import './index.css';
import App from './App';
import reportWebVitals from './reportWebVitals';

const root = ReactDOM.createRoot(
  // document.getElementById('root') as HTMLElement
  document.getElementById('root') as HTMLDivElement // 缩小类型范围
);
root.render(
  <React.StrictMode>
    <App />
  </React.StrictMode>
);

reportWebVitals();

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/App.tsx
import React, { FC } from 'react';

interface IAppProps {

};

const App:FC<IAppProps> = () => {
  return (
    <div>
      App
    </div>
  )
};

export default App;

3.安装一些必须的模块

3.1 配置预处理器

两种方式：

  • 抽离配置文件配置预处理器
  • 不抽离配置文件craco进行预处理器配置

本项目推荐使用第二种方式

1
$ cnpm i @craco/craco @types/node -D

https://www.npmjs.com/package/@craco/craco

3.1.1 配置别名@

项目根目录创建 craco.config.js，代码如下：

1
2
3
4
5
6
7
8
9
// craco.config.js
const path = require('path')
module.exports = {
  webpack: {
    alias: {
      '@': path.resolve(__dirname, 'src')
    }
  }
}

为了使 TS 文件引入时的别名路径能够正常解析，需要配置 tsconifg.json，在 compilerOptions选项里添加 path 等属性。为了防止配置被覆盖，需要单独创建一个文件 tsconfig.path.json，添加以下代码

1
2
3
4
5
6
7
8
9
10
11
12
// tsconfig.path.json
{
  "compilerOptions": {
    "baseUrl": ".",
    "paths": {
      "@/*": ["./src/*"]
    },
    "types": [
      "node"
    ]
  }
}

在 tsconifg.json 引入配置文件：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
// tsconfig.json
{
  "compilerOptions": {
    "target": "es5",
    "lib": [
      "dom",
      "dom.iterable",
      "esnext"
    ],
    "allowJs": true,
    "skipLibCheck": true,
    "esModuleInterop": true,
    "allowSyntheticDefaultImports": true,
    "strict": true,
    "forceConsistentCasingInFileNames": true,
    "noFallthroughCasesInSwitch": true,
    "module": "esnext",
    "moduleResolution": "node",
    "resolveJsonModule": true,
    "isolatedModules": true,
    "noEmit": true,
    "jsx": "react-jsx"
  },
  "extends": "./tsconfig.path.json",
  "include": [
    "src"
  ]
}

修改 package.json 如下：

1
2
3
4
5
"scripts": {
  "start": "craco start",
  "build": "craco build",
  "test": "craco test"
},
1
$ npm run start

3.2安装状态管理器

根据项目需求 任选其一即可

1
2
3
4
5
6
7
$ cnpm i redux -S
$ cnpm i redux react-redux -S
$ cnpm i redux react-redux redux-thunk -S
$ cnpm i redux react-redux redux-saga -S
$ cnpm i redux react-redux redux-thunk immutable redux-immutable -S
$ cnpm i redux react-redux redux-saga immutable redux-immutable -S
$ cnpm i mobx mobx-react -S

本项目不采用之前的状态管理模式，使用 rtk 技术

1
cnpm i @reduxjs/toolkit redux react-redux redux-devtools -S

3.3 路由

2021年11月4日 发布了 react-router-dom的v6.0.0版本：https://reactrouter.com/

如需使用v5版本：https://v5.reactrouter.com/web/guides/quick-start cnpm i react-router-dom@5 -S

本项目采用 V6版本

1
cnpm i react-router-dom -S

3.4 数据验证

思考，有没有必要安装 prop-types ?

1
cnpm i prop-types -S

本项目其实没有必要安装，因为所有的数据都是基于ts，而ts需要指定类型注解

3.5数据请求

1
cnpm i axios -S

以前版本中 cnpm i @types/axios -S

Ts 中 @types/* 为声明文件

3.6ui库

官网地址：https://ant.design/index-cn 4.22.2

国内官方镜像地址：https://ant-design.antgroup.com/index-cn

国内gitee镜像地址：https://ant-design.gitee.io/index-cn

1
cnpm i antd -S

src/index.css

1
2
/* src/index.css */
@import '~antd/dist/antd.css';

src/index.tsx

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
// src/index.js
import React from 'react';
import ReactDOM from 'react-dom/client';
import './index.css';
import App from './App';
import reportWebVitals from './reportWebVitals';

const root = ReactDOM.createRoot(
  document.getElementById('root') as HTMLDivElement
);
root.render(
  <React.StrictMode>
    <App />
  </React.StrictMode>
);

reportWebVitals();

测试组件库

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
// src/App.tsx
import React, { FC } from 'react';
import { Button } from 'antd'
interface IAppProps {

};

const App:FC<IAppProps> = () => {
  return (
    <div>
      App
      <Button type="primary" danger>
        Primary
      </Button>
    </div>
  )
};

export default App;

浏览器查看发现测试通过

3.6.1 自定义主题

https://ant-design.antgroup.com/docs/react/use-in-typescript-cn

按照 配置主题 的要求，自定义主题需要用到类似 less-loader 提供的 less 变量覆盖功能。我们可以引入 craco-antd 或者是 craco-less来帮助加载 less 样式和修改变量。

1
2
$ cnpm i craco-antd -D
$ cnpm i craco-less -D

首先把 src/index.css 文件修改为 src/index.less，然后修改样式引用为 less 文件。

修改 craco.config.js如下：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
// craco.config.js
const CracoAntDesignPlugin = require('craco-antd'); // 推荐ts中写法
// const CracoLessPlugin = require('craco-less'); // js以及ts写法

const path = require('path')
module.exports = {
  webpack: {
    alias: {
      '@': path.resolve(__dirname, 'src')
    }
  },
  plugins: [
    {
      plugin: CracoAntDesignPlugin,
      options: {
        customizeTheme: {
          '@primary-color': '#1DA57A',
        },
      },
    },
  ]
  // plugins: [
  //   {
  //     plugin: CracoLessPlugin,
  //     options: {
  //       lessLoaderOptions: {
  //         lessOptions: {
  //           modifyVars: { '@primary-color': '#1DA57A' },
  //           javascriptEnabled: true,
  //         },
  //       },
  //     },
  //   },
  // ],
}

这里利用了 less-loader 的 modifyVars 来进行主题配置，变量和其他配置方式可以参考 配置主题 文档。修改后重启 yarn start，如果看到一个绿色的按钮就说明配置成功了。

antd 内建了深色主题和紧凑主题，你可以参照 使用暗色主题和紧凑主题 进行接入。

可以定制的变量列表如下：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
@primary-color: #1890ff; // 全局主色
@link-color: #1890ff; // 链接色
@success-color: #52c41a; // 成功色
@warning-color: #faad14; // 警告色
@error-color: #f5222d; // 错误色
@font-size-base: 14px; // 主字号
@heading-color: rgba(0, 0, 0, 0.85); // 标题色
@text-color: rgba(0, 0, 0, 0.65); // 主文本色
@text-color-secondary: rgba(0, 0, 0, 0.45); // 次文本色
@disabled-color: rgba(0, 0, 0, 0.25); // 失效色
@border-radius-base: 2px; // 组件/浮层圆角
@border-color-base: #d9d9d9; // 边框色
@box-shadow-base: 0 3px 6px -4px rgba(0, 0, 0, 0.12), 0 6px 16px 0 rgba(0, 0, 0, 0.08),
  0 9px 28px 8px rgba(0, 0, 0, 0.05); // 浮层阴影

完整的配置如下：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
// craco.config.js
const CracoAntDesignPlugin = require('craco-antd'); // 推荐ts中写法
// const CracoLessPlugin = require('craco-less'); // js以及ts写法

const path = require('path')
module.exports = {
  webpack: {
    alias: {
      '@': path.resolve(__dirname, 'src')
    }
  },
  plugins: [
    {
      plugin: CracoAntDesignPlugin,
      options: {
        customizeTheme: {
          '@primary-color': '#1890ff', // 全局主色
          '@link-color': '#1890ff', // 链接色
          '@success-color': '#52c41a', // 成功色
          '@warning-color': '#faad14', // 警告色
          '@error-color': '#f5222d', // 错误色
          '@font-size-base': '14px', // 主字号
          '@heading-color': 'rgba(0, 0, 0, 0.85)', // 标题色
          '@text-color': 'rgba(0, 0, 0, 0.65)', // 主文本色
          '@text-color-secondary': 'rgba(0, 0, 0, 0.45)', // 次文本色
          '@disabled-color': 'rgba(0, 0, 0, 0.25)', // 失效色
          '@border-radius-base': '2px', // 组件/浮层圆角
          '@border-color-base': '#d9d9d9', // 边框色
          '@box-shadow-base': '0 3px 6px -4px rgba(0, 0, 0, 0.12), 0 6px 16px 0 rgba(0, 0, 0, 0.08), 0 9px 28px 8px rgba(0, 0, 0, 0.05)' // 浮层阴影
        },
      },
    },
  ]
  // plugins: [
  //   {
  //     plugin: CracoLessPlugin,
  //     options: {
  //       lessLoaderOptions: {
  //         lessOptions: {
  //           modifyVars: { '@primary-color': '#1DA57A' },
  //           javascriptEnabled: true,
  //         },
  //       },
  //     },
  //   },
  // ],
}

同样，你可以使用 react-app-rewired 和 customize-cra 来自定义 create-react-app 的 webpack 配置。

3.7其他第三方工具包

https://www.lodashjs.com/

Lodash 工具包，项目必装，它提供了很多使用的函数

1
2
$ cnpm i lodash -S
$ cnpm i @types/lodash -D
1
2
3
4
5
6
7
8
9
10
import _ from 'lodash'

var users = [
  { 'user': 'barney',  'active': false },
  { 'user': 'fred',    'active': false },
  { 'user': 'pebbles', 'active': true }
];

console.log(_.findIndex(users, (item) => item.user === 'pebbles'))
console.log(users.findIndex((item) => item.user === 'pebbles'))

4.创建主布局文件

预览模板：https://pro.ant.design/zh-CN/

src/layout/Index.tsx 作为后台管理系统的主页面布局(包含左侧的菜单栏，顶部，底部等)

https://ant-design.gitee.io/components/layout-cn/#components-layout-demo-custom-trigger

不要照着代码敲，直接复制即可，给 Layout 组件添加 id为admin-app

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
// src/layout/Index.tsx 主要的布局文件
import {
  MenuFoldOutlined,
  MenuUnfoldOutlined,
  UploadOutlined,
  UserOutlined,
  VideoCameraOutlined,
} from '@ant-design/icons';
import { Layout, Menu } from 'antd';
import React, { useState } from 'react';

const { Header, Sider, Content } = Layout;

const App: React.FC = () => {
  const [collapsed, setCollapsed] = useState(false);

  return (
    <Layout id='admin-app'>
      <Sider trigger={null} collapsible collapsed={collapsed}>
        <div className="logo" />
        <Menu
          theme="dark"
          mode="inline"
          defaultSelectedKeys={['1']}
          items={[
            {
              key: '1',
              icon: <UserOutlined />,
              label: 'nav 1',
            },
            {
              key: '2',
              icon: <VideoCameraOutlined />,
              label: 'nav 2',
            },
            {
              key: '3',
              icon: <UploadOutlined />,
              label: 'nav 3',
            },
          ]}
        />
      </Sider>
      <Layout className="site-layout">
        <Header className="site-layout-background" style={{ padding: 0 }}>
          {React.createElement(collapsed ? MenuUnfoldOutlined : MenuFoldOutlined, {
            className: 'trigger',
            onClick: () => setCollapsed(!collapsed),
          })}
        </Header>
        <Content
          className="site-layout-background"
          style={{
            margin: '24px 16px',
            padding: 24,
            minHeight: 280,
          }}
        >
          Content
        </Content>
      </Layout>
    </Layout>
  );
};

export default App;

主组件引入 主界面的布局文件

1
2
3
4
5
6
7
8
9
10
11
12
13
// src/App.tsx
import { FC } from "react";
import Index from './layout/Index'

type AppProps = {}

const App: FC = (props: AppProps) => (
  <>
    <Index />
  </>
);

export default App

查看浏览器，预览运行结果

发现页面并不是全屏。审查元素设置 root以及 components-layout-demo-custom-trigger 高度为 100%

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
/* src/index.css */
@import '~antd/dist/antd.less';

// 设置全屏  --- 审查元素 一层一层找 坚决不放过任何一个遗漏的
html, body, #root {
  height: 100%;
}

#admin-app {
  height: 100%;
}
// 布局文件
// #components-layout-demo-custom-trigger .trigger {  // 组件库提供案例id，改成自己的
#admin-app .trigger {
  padding: 0 24px;
  font-size: 18px;
  line-height: 64px;
  cursor: pointer;
  transition: color 0.3s;
}
// #components-layout-demo-custom-trigger .trigger:hover
#admin-app .trigger:hover {
  color: #1890ff;
}

// #components-layout-demo-custom-trigger .logo {
#admin-app .logo {
  height: 32px;
  margin: 16px;
  background: rgba(255, 255, 255, 0.3);
}

.site-layout .site-layout-background {
  background: #fff;
}

5.拆分主界面

先拆分左侧的菜单栏组件

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
// src/layout/components/SideBar.tsx 左侧菜单栏
import React, { FC, useState } from 'react';
import {
  UploadOutlined,
  UserOutlined,
  VideoCameraOutlined,
} from '@ant-design/icons';
import { Layout, Menu } from 'antd';
interface ISideBarProps {

};

const { Sider } = Layout;
const SideBar:FC<ISideBarProps> = () => {
  const [collapsed] = useState(false);
  return (
    <Sider trigger={null} collapsible collapsed={collapsed}>
      <div className="logo" />
      <Menu
        theme="dark"
        mode="inline"
        defaultSelectedKeys={['1']}
        items={[
          {
            key: '1',
            icon: <UserOutlined />,
            label: 'nav 1',
          },
          {
            key: '2',
            icon: <VideoCameraOutlined />,
            label: 'nav 2',
          },
          {
            key: '3',
            icon: <UploadOutlined />,
            label: 'nav 3',
          },
        ]}
      />
    </Sider>
  )
};

export default SideBar;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
// src/layout/components/AppHeader.tsx 头部组件
import React, { FC, useState } from 'react';
import {
  MenuFoldOutlined,
  MenuUnfoldOutlined
} from '@ant-design/icons';
import { Layout } from 'antd';
const { Header } = Layout;
interface IAppHeaderProps {

};

const AppHeader:FC<IAppHeaderProps> = () => {
  const [collapsed, setCollapsed] = useState(false);
  return (
    <Header className="site-layout-background" style={{ padding: 0 }}>
      {React.createElement(collapsed ? MenuUnfoldOutlined : MenuFoldOutlined, {
        className: 'trigger',
        onClick: () => setCollapsed(!collapsed),
      })}
    </Header>
  )
};

export default AppHeader;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
// src/layout/components/AppMain.tsx 内容区域
import React, { FC } from 'react';
import { Layout } from 'antd';
interface IAppMainProps {

};
const { Content } = Layout;
const AppMain:FC<IAppMainProps> = () => {
  return (
    <Content
      className="site-layout-background"
      style={{
        margin: '24px 16px',
        padding: 24,
        minHeight: 280,
      }}
    >
      Content
    </Content>
  )
};

export default AppMain;

整和组件资源

1
2
3
4
// src/layout/components/index.ts
export { default as SideBar } from './SideBar'
export { default as AppHeader } from './AppHeader'
export { default as AppMain } from './AppMain'
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
// src/layout/Index.tsx 主要的布局文件
import { Layout } from 'antd';
import React  from 'react';

import { AppHeader, AppMain, SideBar } from './components'

const App: React.FC = () => {
  return (
    <Layout id='admin-app'>
      {/* 左侧菜单栏 */}
      <SideBar />
      <Layout className="site-layout">
        {/* 头部 */}
        <AppHeader />
        {/* 内容 */}
        <AppMain />
      </Layout>
    </Layout>
  );
};

export default App;

此时点击头部的控制器，发现只有头部组件的 图标在切换，但是并没有影响左侧菜单的收缩

建议使用状态管理器管理控制的这个状态

6.使用rtk来管理状态

http://cn.redux.js.org/

参考链接：http://cn.redux.js.org/tutorials/typescript-quick-start

6.1 定义State和Dispatch类型

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/store/index.ts
import { configureStore } from '@reduxjs/toolkit';

const store = configureStore({
  reducer: { // 整合模块

  }
});

// redux store  store.getState  store.subscribe  store.dispatch
// 定义State和dispatch类型  从 store 本身推断出 `RootState` 和 `AppDispatch` 类型
export type RootState = ReturnType<typeof store.getState>
export type AppDispatch = typeof store.dispatch


export default store;

构建app的模块用于管理 头部和 左侧菜单的共同的状态

6.2 定义 Hooks 类型

虽然可以将RootStateandAppDispatch类型导入到每个组件中，但最好创建useDispatchand useSelectorhooks 的类型化版本以在您的应用程序中使用。

1
2
3
4
5
6
7
8
// src/store/hook.ts 自定义useSelector 以及 useDispatch 避免后续组件使用时需要单独引入每一次 js不需要
import { useSelector, useDispatch, TypedUseSelectorHook } from 'react-redux'
import { AppDispatch, RootState } from './index'

// 在整个应用程序中使用，而不是简单的 `useDispatch` 和 `useSelector`
export const useAppDispatch: () => AppDispatch = useDispatch // () => AppDispatch 代表返回的是一个函数
export const useAppSelector: TypedUseSelectorHook<RootState> = useSelector // TypedUseSelectorHook<RootState> 类型注解
// 以后组件中不要再单独使用 useSelector, useDispatch，使用useAppSelector 以及useAppDispatch 代替

6.3 应用程序中使用

创建状态管理

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
// src/store/modules/app.ts
import { createSlice, PayloadAction } from '@reduxjs/toolkit' // PayloadAction 添加类型注解需要 js中不需要

interface IState { // js不需要
  count: number
  collapsed: boolean
}
const initialState: IState = { // IState js不要
  count: 100,
  collapsed: false
}
// 固定写法,定义模块，无法直接被使用，需要暴露相关的内容
const appSlice = createSlice({
  name: 'app', // 模块名称
  initialState, // 初始化状态
  reducers: { // 修改状态的方法
    addCount (state, action: PayloadAction<number>) {
     state.count += action.payload
    },
    setCollapsed (state, action: PayloadAction<boolean>) { // js不需要
      // 修改状态
      state.collapsed = action.payload
    }
  }
})

// console.log(appSlice)
// appSlice { reducer: '需要的状态', actions: '改变状态函数', caseReducers: '类似actions', getInitialState: '获取初始化状态', name: '模块名称'}

// 暴露后续组件中可以修改状态的函数
export const { addCount, setCollapsed } = appSlice.actions // appSlice.actions 实际上就是 上面模块 reducers内的函数

// 默认暴露出去 模块的reducer
export default appSlice.reducer

6.4 整合reducer

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/store/index.ts
import { configureStore } from '@reduxjs/toolkit';
import appReducer from './modules/app'
const store = configureStore({
  reducer: { // 整合模块
    app: appReducer
  }
});

// redux store  store.getState  store.subscribe  store.dispatch
// 定义State和dispatch类型  从 store 本身推断出 `RootState` 和 `AppDispatch` 类型
export type RootState = ReturnType<typeof store.getState> // js 不需要
export type AppDispatch = typeof store.dispatch // js 不需要


export default store;

6.5 入口文件配置状态管理器

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
// src/index.js
import React from 'react';
import ReactDOM from 'react-dom/client';
import { Provider } from 'react-redux';
import store from '@/store'
import '@/index.less';
import App from '@/App';
import reportWebVitals from '@/reportWebVitals';

const root = ReactDOM.createRoot(
  document.getElementById('root') as HTMLDivElement
);
root.render(
  <React.StrictMode>
    <Provider store = { store }>
      <App />
    </Provider>
  </React.StrictMode>
);

reportWebVitals();

6.6 左侧菜单栏使用状态管理器

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
// src/layout/components/SideBar.tsx 左侧菜单栏
import React, { FC } from 'react';
import {
  UploadOutlined,
  UserOutlined,
  VideoCameraOutlined,
} from '@ant-design/icons';
import { Layout, Menu } from 'antd';
// import { useSelector } from 'react-redux';
// import { RootState } from '@/store';
import { useAppSelector } from '@/store/hook';
interface ISideBarProps {

};

const { Sider } = Layout;
const SideBar:FC<ISideBarProps> = () => {
  // const [collapsed] = useState(false);

  // const collapsed = useSelector(state => state.app.collapsed); // js中的写法
  // const collapsed = useSelector((state: RootState) => state.app.collapsed); // ts中的写法,组件引入类型，冗余度会高
  const collapsed = useAppSelector(state => state.app.collapsed); // ts推荐写法

  return (
    <Sider trigger={null} collapsible collapsed={collapsed}>
      <div className="logo" />
      <Menu
        theme="dark"
        mode="inline"
        defaultSelectedKeys={['1']}
        items={[
          {
            key: '1',
            icon: <UserOutlined />,
            label: 'nav 1',
          },
          {
            key: '2',
            icon: <VideoCameraOutlined />,
            label: 'nav 2',
          },
          {
            key: '3',
            icon: <UploadOutlined />,
            label: 'nav 3',
          },
        ]}
      />
    </Sider>
  )
};

export default SideBar;

6.7 头部组件使用状态管理器

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
// src/layout/components/AppHeader.tsx 头部组件
import React, { FC } from 'react';
import {
  MenuFoldOutlined,
  MenuUnfoldOutlined
} from '@ant-design/icons';
import { Layout } from 'antd';
import { useAppDispatch, useAppSelector } from '@/store/hook';
import { setCollapsed } from '@/store/modules/app'
// import { useDispatch } from 'react-redux';
// import { AppDispatch } from '@/store';
const { Header } = Layout;
interface IAppHeaderProps {
};

const AppHeader:FC<IAppHeaderProps> = () => {
  // const [collapsed, setCollapsed] = useState(false);

  const collapsed = useAppSelector(state => state.app.collapsed)

  // const dispatch: AppDispatch = useDispatch() // ts中添加类型注解
  const dispatch = useAppDispatch() // ts推荐写法

  return (
    <Header className="site-layout-background" style={{ padding: 0 }}>
      {/* {React.createElement(collapsed ? MenuUnfoldOutlined : MenuFoldOutlined, {
        className: 'trigger',
        onClick: () => {
          dispatch(setCollapsed(!collapsed))
        }
      })} */}
      {
        collapsed ? <MenuUnfoldOutlined  className="trigger" onClick={ () => {
          dispatch(setCollapsed(!collapsed))
        }}/> : <MenuFoldOutlined  className="trigger" onClick={ () => {
          dispatch(setCollapsed(!collapsed))
        }}/>
      }
    </Header>
  )
};

export default AppHeader;

6.8保留用户习惯-可选

永久存储 用户习惯

此时发现 头部的 按钮可以控制左侧菜单栏了，但是还没有满足需求

需求如下：保留用户的使用习惯

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
// src/store/modules/app.ts
import { createSlice, PayloadAction } from '@reduxjs/toolkit' // PayloadAction 添加类型注解需要 js中不需要

interface IState { // js不需要
  count: number
  collapsed: boolean
}
const initialState: IState = { // IState js不要
  count: 100,
  // collapsed: false // 每次一样
  collapsed: localStorage.getItem('collapsed') === 'true' // 保留用户的使用习惯
}
// 固定写法,定义模块，无法直接被使用，需要暴露相关的内容
const appSlice = createSlice({
  name: 'app', // 模块名称
  initialState, // 初始化状态
  reducers: { // 修改状态的方法
    addCount (state, action: PayloadAction<number>) {
     state.count += action.payload
    },
    setCollapsed (state, action: PayloadAction<boolean>) { // js不需要
      // 修改状态
      // 保存到本地
      localStorage.setItem('collapsed', String(action.payload)) // 保留用户的使用习惯
      state.collapsed = action.payload
    }
  }
})

// console.log(appSlice)
// appSlice { reducer: '需要的状态', actions: '改变状态函数', caseReducers: '类似actions', getInitialState: '获取初始化状态', name: '模块名称'}

// 暴露后续组件中可以修改状态的函数
export const { addCount, setCollapsed } = appSlice.actions // appSlice.actions 实际上就是 上面模块 reducers内的函数

// 默认暴露出去 模块的reducer
export default appSlice.reducer

6.9 永久存储的 类 localStorage 的工具 store2

1
$ cnpm i store2 -S

https://www.npmjs.com/package/store2

推荐一个好用的永久存储的 类 localStorage 的工具 store2

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
// src/store/modules/app.ts
import { createSlice, PayloadAction } from '@reduxjs/toolkit' // PayloadAction 添加类型注解需要 js中不需要
import store2 from 'store2'
interface IState { // js不需要
  count: number
  collapsed: boolean
}
const initialState: IState = { // IState js不要
  count: 100,
  // collapsed: false // 每次一样
  // collapsed: localStorage.getItem('collapsed') === 'true' // 保留用户的使用习惯
  collapsed: store2.get('collapsed') === 'true' // 保留用户的使用习惯
}
// 固定写法,定义模块，无法直接被使用，需要暴露相关的内容
const appSlice = createSlice({
  name: 'app', // 模块名称
  initialState, // 初始化状态
  reducers: { // 修改状态的方法
    addCount (state, action: PayloadAction<number>) {
     state.count += action.payload
    },
    setCollapsed (state, action: PayloadAction<boolean>) { // js不需要
      // 修改状态
      // 保存到本地
      // localStorage.setItem('collapsed', String(action.payload)) // 保留用户的使用习惯
      store2.set('collapsed', String(action.payload))
      state.collapsed = action.payload
    }
  }
})

// console.log(appSlice)
// appSlice { reducer: '需要的状态', actions: '改变状态函数', caseReducers: '类似actions', getInitialState: '获取初始化状态', name: '模块名称'}

// 暴露后续组件中可以修改状态的函数
export const { addCount, setCollapsed } = appSlice.actions // appSlice.actions 实际上就是 上面模块 reducers内的函数

// 默认暴露出去 模块的reducer
export default appSlice.reducer

7.左侧菜单栏

7.1.设计左侧菜单栏的数据

https://ant-design.gitee.io/components/menu-cn/#components-menu-demo-sider-current

Antd 4.20以上版本直接实现 递归

antd 4.20版本以下需要手动实现

1
2
3
4
5
6
7
8
9
10
// src/router/inter.d.ts
import { ReactNode } from 'react'

// key属性可以使用 左侧菜单的路由地址，因为它具有唯一性
export interface IMenuProps {
  label: string
  key: string
  icon?: ReactNode
  children?: IMenuProps[]
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
// src/router/menu.tsx
import { IMenuProps } from './inter'
import {
  HomeOutlined,
  UploadOutlined,
  PictureOutlined,
  ProfileOutlined,
  OrderedListOutlined,
  FilterOutlined,
  TeamOutlined,
  UserOutlined,
  SettingOutlined
} from '@ant-design/icons'
const menus: IMenuProps[] = [
  {
    label: '系统首页',
    key: '/',
    icon: <HomeOutlined />
  },
  // {
  //   label: '轮播图管理',
  //   key: '/banner',
  //   icon: <UploadOutlined />,
  //   children: [
  //     {
  //       label: '首页轮播图',
  //       key: '/banner/home',
  //       icon: <PictureOutlined />,
  //       children: [
  //         {
  //           label: '轮播图列表',
  //           key: '/banner/home/list',
  //           icon: <PictureOutlined />
  //         },
  //         {
  //           label: '添加轮播图',
  //           key: '/banner/home/add',
  //           icon: <UploadOutlined />
  //         }
  //       ]
  //     },
  //     {
  //       label: '活动页轮播图',
  //       key: '/banner/active',
  //       icon: <PictureOutlined />,
  //       children: [
  //         {
  //           label: '轮播图列表',
  //           key: '/banner/home/list',
  //           icon: <PictureOutlined />
  //         },
  //         {
  //           label: '添加轮播图',
  //           key: '/banner/home/add',
  //           icon: <UploadOutlined />
  //         }
  //       ]
  //     },

  //   ]
  // }
  {
    label: '轮播图管理',
    key: '/banner',
    icon: <UploadOutlined />,
    children: [
      {
        label: '首页轮播图',
        key: '/banner/home',
        icon: <PictureOutlined />
      },
      {
        label: '活动页轮播图',
        key: '/banner/active',
        icon: <PictureOutlined />
      },
      {
        label: '添加轮播图',
        key: '/banner/add',
        icon: <UploadOutlined />
      },
    ]
  },
  {
    label: '产品管理',
    key: '/pro',
    icon: <ProfileOutlined />,
    children: [
      {
        label: '产品列表',
        key: '/pro/list',
        icon: <OrderedListOutlined /> ,
        children: [
          {
            label: '首页产品列表',
            key: '/pro/list/home'
          },
          {
            label: '详情推荐列表',
            key: '/pro/list/detail'
          },
          {
            label: '购物车推荐列表',
            key: '/pro/list/cart'
          },
        ]
      },
      {
        label: '筛选列表',
        key: '/pro/search',
        icon: <FilterOutlined />
      },
    ]
  },
  {
    label: '账户管理',
    key: '/account',
    icon: <TeamOutlined />,
    children: [
      {
        label: '用户列表',
        key: '/account/userlist',
        icon: <UserOutlined />
      },
      {
        label: '管理员列表',
        key: '/account/adminlist',
        icon: <UserOutlined />
      }
    ]
  },
  {
    label: '设置',
    key: '/setting',
    icon: <SettingOutlined />
  }
]


export default menus

7.2.渲染左侧菜单栏

左侧菜单栏的头部设定logo以及后台管理系统名称

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
// src/layout/components/SideBar.tsx 左侧菜单栏
import React, { FC } from 'react';

import { Layout, Menu, Image } from 'antd';
import { useAppSelector } from '@/store/hook';
import menus from '@/router/menu'
import logo from '@/logo.svg'
interface ISideBarProps {

};

const { Sider } = Layout;
const SideBar:FC<ISideBarProps> = () => {
  const collapsed = useAppSelector(state => state.app.collapsed);

  return (
    <Sider trigger={null} collapsible collapsed={collapsed}>
      <div className="logo" style={ {
        display: 'flex',
        justifyContent: 'center',
        alignItems: 'center',
        color: '#fff'
      }}>
        <Image src = { logo } width="28px" height="28px" preview={ false }></Image>
        { !collapsed && <div style={{
          height: '32px',
          overflow: 'hidden',
          lineHeight: '32px'
        }}>嗨购后台管理系统</div> }
      </div>
      <Menu
        theme="dark"
        mode="inline"
        defaultSelectedKeys={['1']}
        items={ menus }
      />
    </Sider>
  )
};

export default SideBar;

7.3 低版本处理

以上菜单项的设置在antd 4.20.0版本以上好使，如果在4.20.0版本以下，应该使用 递归组件实现

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
// src/layout/components/SideBar.tsx 左侧菜单栏
import React, { FC } from 'react';

import { Layout, Menu, Image } from 'antd';
import { useAppSelector } from '@/store/hook';
import menus from '@/router/menu'
import logo from '@/logo.svg'
import { IMenuProps } from '@/router/inter';
interface ISideBarProps {

};

const { Sider } = Layout;

const renderMenu = (menus: IMenuProps[]) => {
  return menus.map(item => {
    if (item.children) {
      return (
        <Menu.SubMenu title = { item.label } icon = { item.icon } key = { item.key }>
          {
            renderMenu(item.children)
          }
        </Menu.SubMenu>
      )
    } else {
      return <Menu.Item key = { item.key } icon = { item.icon }>{ item.label }</Menu.Item>
    }
  })
}

const SideBar:FC<ISideBarProps> = () => {
  const collapsed = useAppSelector(state => state.app.collapsed);

  return (
    <Sider trigger={null} collapsible collapsed={collapsed}>
      <div className="logo" style={ {
        display: 'flex',
        justifyContent: 'center',
        alignItems: 'center',
        color: '#fff'
      }}>
        <Image src = { logo } width="28px" height="28px" preview={ false }></Image>
        { !collapsed && <div style={{
          height: '32px',
          overflow: 'hidden',
          lineHeight: '32px'
        }}>嗨购后台管理系统</div> }
      </div>
      <Menu
        theme="dark"
        mode="inline"
        defaultSelectedKeys={['1']}
      >
        {
          renderMenu(menus)
        }
      </Menu>
    </Sider>
  )
};

export default SideBar;

优化：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
// src/router/utils.tsx

import { Menu } from 'antd';
import { IMenuProps } from './inter';
export const renderMenu = (menus: IMenuProps[]) => {
  return menus.map(item => {
    if (item.children) {
      return (
        <Menu.SubMenu title = { item.label } icon = { item.icon } key = { item.key }>
          {
            renderMenu(item.children)
          }
        </Menu.SubMenu>
      )
    } else {
      return <Menu.Item key = { item.key } icon = { item.icon }>{ item.label }</Menu.Item>
    }
  })
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
// src/layout/components/SideBar.tsx 左侧菜单栏
import React, { FC } from 'react';

import { Layout, Menu, Image } from 'antd';
import { useAppSelector } from '@/store/hook';
import menus from '@/router/menu'
import logo from '@/logo.svg'
// import { IMenuProps } from '@/router/inter';
import { renderMenu } from '@/router/utils'
interface ISideBarProps {

};

const { Sider } = Layout;

// antd 4.20.0版本以下，递归生成菜单项
// 建议可以把这个代码放到另一个模块中
// const renderMenu = (menus: IMenuProps[]) => {
//   return menus.map(item => {
//     if (item.children) {
//       return (
//         <Menu.SubMenu title = { item.label } icon = { item.icon } key = { item.key }>
//           {
//             renderMenu(item.children)
//           }
//         </Menu.SubMenu>
//       )
//     } else {
//       return <Menu.Item key = { item.key } icon = { item.icon }>{ item.label }</Menu.Item>
//     }
//   })
// }

const SideBar:FC<ISideBarProps> = () => {
  const collapsed = useAppSelector(state => state.app.collapsed);

  return (
    <Sider trigger={null} collapsible collapsed={collapsed}>
      <div className="logo" style={ {
        display: 'flex',
        justifyContent: 'center',
        alignItems: 'center',
        color: '#fff'
      }}>
        <Image src = { logo } width="28px" height="28px" preview={ false }></Image>
        { !collapsed && <div style={{
          height: '32px',
          overflow: 'hidden',
          lineHeight: '32px'
        }}>嗨购后台管理系统</div> }
      </div>
      <Menu
        theme="dark"
        mode="inline"
        defaultSelectedKeys={['1']}
      >
        {
          renderMenu(menus)
        }
      </Menu>
    </Sider>
  )
};

export default SideBar;

7.4 菜单渲染优化

如果左侧菜单栏数据过于庞大，每个管理项里又有很多项，需要只展开一个菜单项

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
// src/layout/components/SideBar.tsx 左侧菜单栏
import React, { FC, useState } from 'react';

import { Layout, Menu, Image, MenuProps } from 'antd';
import { useAppSelector } from '@/store/hook';
import menus from '@/router/menu'
import logo from '@/logo.svg'
// import { IMenuProps } from '@/router/inter';
import { renderMenu } from '@/router/utils'
interface ISideBarProps {

};

const { Sider } = Layout;

// antd 4.20.0版本以下，递归生成菜单项
// 建议可以把这个代码放到另一个模块中
// const renderMenu = (menus: IMenuProps[]) => {
//   return menus.map(item => {
//     if (item.children) {
//       return (
//         <Menu.SubMenu title = { item.label } icon = { item.icon } key = { item.key }>
//           {
//             renderMenu(item.children)
//           }
//         </Menu.SubMenu>
//       )
//     } else {
//       return <Menu.Item key = { item.key } icon = { item.icon }>{ item.label }</Menu.Item>
//     }
//   })
// }

// 设置只展开一个菜单项
const rootSubmenuKeys: string[] = [];
menus.forEach(item => {
  item.children && rootSubmenuKeys.push(item.key)
})
console.log(rootSubmenuKeys)

const SideBar:FC<ISideBarProps> = () => {
  const collapsed = useAppSelector(state => state.app.collapsed);


  // 展开哪一项数据
  const [openKeys, setOpenKeys] = useState<string[]>([])
  // 打开一个菜单项时，需要做判断 - SubMenu 展开/关闭的回调
  const onOpenChange: MenuProps['onOpenChange'] = keys => {
    // 如果当前展开项是 轮播图管理，再点击 账户管理 ['/banner', '/account']
    console.log('keys', keys) // ['/banner'] =>  ['/banner', '/account']
    console.log('openKeys', openKeys) // [] => ['/banner']
    // 得到当前
    const latestOpenKey = keys.find(key => openKeys.indexOf(key) === -1);
    console.log('latestOpenKey', latestOpenKey) // /banner ===> /account
    if (rootSubmenuKeys.indexOf(latestOpenKey!) === -1) {
      setOpenKeys(keys);
    } else {
      setOpenKeys(latestOpenKey ? [latestOpenKey] : []);
    }
  }

  return (
    <Sider trigger={null} collapsible collapsed={collapsed}>
      <div className="logo" style={ {
        display: 'flex',
        justifyContent: 'center',
        alignItems: 'center',
        color: '#fff'
      }}>
        <Image src = { logo } width="28px" height="28px" preview={ false }></Image>
        { !collapsed && <div style={{
          height: '32px',
          overflow: 'hidden',
          lineHeight: '32px'
        }}>嗨购后台管理系统</div> }
      </div>
      <Menu
        theme="dark"
        mode="inline"
        defaultSelectedKeys={['1']}
        openKeys = { openKeys } // 打开哪一个菜单项
        onOpenChange = { onOpenChange } // 打开某一个菜单项时需要关闭其他菜单项
      >
        {
          renderMenu(menus)
        }
      </Menu>
    </Sider>
  )
};

export default SideBar;

8.定义路由

8.1 官方文档

https://reactrouter.com/

8.2 创建对应的页面

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
|-src
|  |- ...
|  |-views
|    |- banner
|    |  |- Index.tsx    #轮播图管理页面
|    |  |- List.tsx     #首页轮播图
|    |  |- Active.tsx   #活动页轮播图
|	 |  |- Add.tsx		#添加轮播图
|	 |- home
|    |  |- Index.tsx	#系统首页
|    |- product
|    |  |- Index.tsx 	#产品管理
|    |  |- Search.tsx 	#筛选列表
|    |  |- list
|    |  |  |- Index.tsx #产品列表
|    |  |  |- Home.tsx  #首页产品列表
|    |  |  |- Detail.tsx#详情推荐列表
|    |  |  |- Cart.tsx  #购物车推荐列表
|    |- Account
|    |  |- Index.tsx	#账户管理
|    |  |- UserList.tsx #用户列表
|    |  |- AdminList.tsx#管理员列表
|    |- setting
|    |  |- Index.tsx    #设置页面

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/account/Index.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>账户管理</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/account/UserList.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>用户列表</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/account/AdminList.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>管理员列表</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/banner/Index.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>轮播图管理</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/banner/List.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>首页轮播图列表</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/banner/Active.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>活动页轮播图</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/banner/Add.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>添加轮播图</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/home/Index.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>系统首页</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/Product/Index.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>产品管理</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/Product/Search.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>筛选列表</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/Product/list/Index.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>产品列表</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/Product/list/Home.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>首页产品列表</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/Product/list/Detail.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>详情推荐列表</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/Product/list/Cart.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>购物车推荐列表</h1>
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/setting/Index.tsx
import React, { FC } from 'react';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>设置页面</h1>
    </>
  )
};

export default Index;

有二级菜单，能想到的 就是使用 嵌套路由

https://reactrouter.com/docs/en/v6/getting-started/overview#index-routes

8.3 定义菜单路由信息

v6的路由通过 element 属性定义匹配的组件

因此menus中可以添加一个 element 属性，值就为组件的引用即可

1
2
3
4
5
6
7
8
9
10
11
// src/router/inter.d.ts
import { ReactNode } from 'react'

// key属性可以使用 左侧菜单的路由地址，因为它具有唯一性
export interface IMenuProps {
  label: string
  key: string
  icon?: ReactNode
  children?: IMenuProps[]
  element: ReactNode // 因为页面创建时 指定了多级了路由的页面，故这里设置为 必传属性
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
// src/router/menu.tsx
import { IMenuProps } from './inter'
import {
  HomeOutlined,
  UploadOutlined,
  PictureOutlined,
  ProfileOutlined,
  OrderedListOutlined,
  FilterOutlined,
  TeamOutlined,
  UserOutlined,
  SettingOutlined
} from '@ant-design/icons'

import Home from '@/views/home/Index'

import Banner from '@/views/banner/Index'
import BannerList from '@/views/banner/List'
import BannerActive from '@/views/banner/Active'
import BannerAdd from '@/views/banner/Add'

import Product from '@/views/product/Index'
import ProductSearch from '@/views/product/Search'
import ProductList from '@/views/product/list/Index'
import ProductHomeList from '@/views/product/list/Home'
import ProductDetailList from '@/views/product/list/Detail'
import ProductCartList from '@/views/product/list/Cart'

import Account from '@/views/account/Index'
import UserList from '@/views/account/UserList'
import AdminList from '@/views/account/AdminList'

import Setting from '@/views/setting/Index'

const menus: IMenuProps[] = [
  {
    label: '系统首页',
    key: '/',
    icon: <HomeOutlined />,
    element: <Home />
  },
  {
    label: '轮播图管理',
    key: '/banner',
    icon: <UploadOutlined />,
    element: <Banner />,
    children: [
      {
        label: '首页轮播图',
        key: '/banner/home',
        icon: <PictureOutlined />,
        element: <BannerList />
      },
      {
        label: '活动页轮播图',
        key: '/banner/active',
        icon: <PictureOutlined />,
        element: <BannerActive />
      },
      {
        label: '添加轮播图',
        key: '/banner/add',
        icon: <UploadOutlined />,
        element: <BannerAdd />
      },
    ]
  },
  {
    label: '产品管理',
    key: '/pro',
    icon: <ProfileOutlined />,
    element: <Product />,
    children: [
      {
        label: '产品列表',
        key: '/pro/list',
        icon: <OrderedListOutlined />,
        element: <ProductList />,
        children: [
          {
            label: '首页产品列表',
            key: '/pro/list/home',
            element: <ProductHomeList />
          },
          {
            label: '详情推荐列表',
            key: '/pro/list/detail',
            element: <ProductDetailList />
          },
          {
            label: '购物车推荐列表',
            key: '/pro/list/cart',
            element: <ProductCartList />
          },
        ]
      },
      {
        label: '筛选列表',
        key: '/pro/search',
        icon: <FilterOutlined />,
        element: <ProductSearch />
      },
    ]
  },
  {
    label: '账户管理',
    key: '/account',
    icon: <TeamOutlined />,
    element: <Account />,
    children: [
      {
        label: '用户列表',
        key: '/account/userlist',
        icon: <UserOutlined />,
        element: <UserList />
      },
      {
        label: '管理员列表',
        key: '/account/adminlist',
        icon: <UserOutlined />,
        element: <AdminList />
      }
    ]
  },
  {
    label: '设置',
    key: '/setting',
    icon: <SettingOutlined />,
    element: <Setting />
  }
]


export default menus

8.4.装载路由

在根组件添加 BrowserRouter 或者 HashRouter

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
// src/index.js
import React from 'react';
import ReactDOM from 'react-dom/client';
import { Provider } from 'react-redux';
import store from '@/store'
import '@/index.less';
import App from '@/App';
import reportWebVitals from '@/reportWebVitals';
import { BrowserRouter } from 'react-router-dom' // +++++

const root = ReactDOM.createRoot(
  document.getElementById('root') as HTMLDivElement
);
root.render(
  <React.StrictMode>
    <Provider store = { store }>
      <BrowserRouter >
        <App />
      </BrowserRouter>
    </Provider>
  </React.StrictMode>
);

reportWebVitals();

8.5 定义路由组件

在menu.tsx里已经定义好了请求的路径（其实就是数据中key属性）和路径对应组件（其实就是数据中的element属性）,剩下就是定义路由组件了

组件渲染的区域 AppMain 组件

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
// src/router/utils.tsx
import { Menu } from 'antd';
import { IMenuProps } from './inter';
import { Route } from 'react-router-dom'
// 定义左侧菜单栏数据
export const renderMenu = (menus: IMenuProps[]) => {
  return menus.map(item => {
    if (item.children) {
      return (
        <Menu.SubMenu title = { item.label } icon = { item.icon } key = { item.key }>
          {
            renderMenu(item.children)
          }
        </Menu.SubMenu>
      )
    } else {
      return <Menu.Item key = { item.key } icon = { item.icon }>{ item.label }</Menu.Item>
    }
  })
}
// 定义路由组件
export const renderRoute = (menus: IMenuProps[]) => {
  return menus.map(item => {
    if (item.children) {
      return (
        <Route key = { item.key } path = { item.key } element = { item.element }>
          { renderRoute(item.children) }
        </Route>
      )
    } else {
      return (
        <Route key = { item.key } path = { item.key } element = { item.element }>
        </Route>
      )
    }
  })
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
// src/layout/components/AppMain.tsx 内容区域
import React, { FC } from 'react';
import { Layout } from 'antd';
import menus from '@/router/menu';
import { renderRoute } from '@/router/utils';
import { Routes } from 'react-router-dom'
interface IAppMainProps {

};
const { Content } = Layout;
const arr = renderRoute(menus)
console.log('arr', arr[1])
const AppMain:FC<IAppMainProps> = () => {
  return (
    <Content
      className="site-layout-background"
      style={{
        margin: '24px 16px',
        padding: 24,
        minHeight: 280,
      }}
    >
      {/*
        多个路由需要定义时，包裹在Routes选项下
      */}
      <Routes>
        {
          renderRoute(menus)
        }
      </Routes>
    </Content>
  )
};

export default AppMain;

8.6 二级乃至三级菜单生效

二级菜单对应的二级路由要生效，需要给以及页面添加 <Outlet /> 标识

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
// src/views/account/Index.tsx
import React, { FC } from 'react';
import { Outlet } from 'react-router-dom';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>账户管理</h1>
      <Outlet />
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
// src/views/banner/Index.tsx
import React, { FC } from 'react';
import { Outlet } from 'react-router-dom';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>轮播图管理</h1>
      <Outlet />
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
// src/views/Product/Index.tsx
import React, { FC } from 'react';
import { Outlet } from 'react-router-dom';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>产品管理</h1>
      <Outlet />
    </>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
// src/views/Product/Index.tsx
import React, { FC } from 'react';
import { Outlet } from 'react-router-dom';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <>
      <h1>产品列表</h1>
      <Outlet />
    </>
  )
};

export default Index;

8.7 手动测试路由

可以在地址栏输入路径，测试是否正常

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
http://localhost:3000/ 					#系统首页

http://localhost:3000/banner			#轮播图管理
http://localhost:3000/banner/home		#首页轮播图
http://localhost:3000/banner/active		#活动页轮播图
http://localhost:3000/banner/add		#添加轮播图

http://localhost:3000/pro				#产品管理
http://localhost:3000/pro/search		#筛选列表
http://localhost:3000/pro/list			#产品列表
http://localhost:3000/pro/list/home		#首页产品列表
http://localhost:3000/pro/list/detail	#详情推荐列表
http://localhost:3000/pro/list/cart		#购物车推荐列表

http://localhost:3000/account			#账户管理
http://localhost:3000/account/userlist	#用户列表
http://localhost:3000/account/adminlist	#管理员列表

http://localhost:3000/settinig			#设置

8.8 设置默认路由

参照 https://reactrouter.com/docs/en/v6/getting-started/overview#index-routes 学习默认路由

根据渲染需求，当路由包含一层或者多层子路由时，当选择父级路由时，希望能够自动跳转到某个子路由。也就是路由的重定向。

在路由表添加标记默认打开子路由

1
2
3
4
5
6
7
8
9
10
11
12
// src/router/inter.d.ts
import { ReactNode } from 'react'

// key属性可以使用 左侧菜单的路由地址，因为它具有唯一性
export interface IMenuProps {
  label: string
  key: string
  icon?: ReactNode
  children?: IMenuProps[]
  element: ReactNode // 因为页面创建时 指定了多级了路由的页面，故这里设置为 必传属性
  index?: 1 | 0 // 不建议使用 boolean，因为react在渲染属性时，具有boolean值的属性会有特殊的含义
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
// src/router/menu.tsx
import { IMenuProps } from './inter'
import {
  HomeOutlined,
  UploadOutlined,
  PictureOutlined,
  ProfileOutlined,
  OrderedListOutlined,
  FilterOutlined,
  TeamOutlined,
  UserOutlined,
  SettingOutlined
} from '@ant-design/icons'

import Home from '@/views/home/Index'

import Banner from '@/views/banner/Index'
import BannerList from '@/views/banner/List'
import BannerActive from '@/views/banner/Active'
import BannerAdd from '@/views/banner/Add'

import Product from '@/views/product/Index'
import ProductSearch from '@/views/product/Search'
import ProductList from '@/views/product/list/Index'
import ProductHomeList from '@/views/product/list/Home'
import ProductDetailList from '@/views/product/list/Detail'
import ProductCartList from '@/views/product/list/Cart'

import Account from '@/views/account/Index'
import UserList from '@/views/account/UserList'
import AdminList from '@/views/account/AdminList'

import Setting from '@/views/setting/Index'

const menus: IMenuProps[] = [
  {
    label: '系统首页',
    key: '/',
    icon: <HomeOutlined />,
    element: <Home />
  },
  {
    label: '轮播图管理',
    key: '/banner',
    icon: <UploadOutlined />,
    element: <Banner />,
    children: [
      {
        label: '首页轮播图',
        key: '/banner/home',
        icon: <PictureOutlined />,
        element: <BannerList />,
        index: 1
      },
      {
        label: '活动页轮播图',
        key: '/banner/active',
        icon: <PictureOutlined />,
        element: <BannerActive />
      },
      {
        label: '添加轮播图',
        key: '/banner/add',
        icon: <UploadOutlined />,
        element: <BannerAdd />
      },
    ]
  },
  {
    label: '产品管理',
    key: '/pro',
    icon: <ProfileOutlined />,
    element: <Product />,
    children: [
      {
        label: '产品列表',
        key: '/pro/list',
        icon: <OrderedListOutlined />,
        element: <ProductList />,
        index: 1,
        children: [
          {
            label: '首页产品列表',
            key: '/pro/list/home',
            element: <ProductHomeList />,
            index: 1
          },
          {
            label: '详情推荐列表',
            key: '/pro/list/detail',
            element: <ProductDetailList />
          },
          {
            label: '购物车推荐列表',
            key: '/pro/list/cart',
            element: <ProductCartList />
          },
        ]
      },
      {
        label: '筛选列表',
        key: '/pro/search',
        icon: <FilterOutlined />,
        element: <ProductSearch />
      },
    ]
  },
  {
    label: '账户管理',
    key: '/account',
    icon: <TeamOutlined />,
    element: <Account />,
    children: [
      {
        label: '用户列表',
        key: '/account/userlist',
        icon: <UserOutlined />,
        element: <UserList />,
        index: 1
      },
      {
        label: '管理员列表',
        key: '/account/adminlist',
        icon: <UserOutlined />,
        element: <AdminList />
      }
    ]
  },
  {
    label: '设置',
    key: '/setting',
    icon: <SettingOutlined />,
    element: <Setting />
  }
]


export default menus

为了配合路由跳转组件，修改代码如下

image-20221024164450685

image-20221024164412284

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
// src/router/utils.tsx
import { Menu } from 'antd';
import { IMenuProps } from './inter';
import { Navigate, Route } from 'react-router-dom'
import React from 'react';
// 定义左侧菜单栏数据
export const renderMenu = (menus: IMenuProps[]) => {
  return menus.map(item => {
    if (item.children) {
      return (
        <Menu.SubMenu title = { item.label } icon = { item.icon } key = { item.key }>
          {
            renderMenu(item.children)
          }
        </Menu.SubMenu>
      )
    } else {
      return <Menu.Item key = { item.key } icon = { item.icon }>{ item.label }</Menu.Item>
    }
  })
}
// 定义路由组件
// export const renderRoute = (menus: IMenuProps[]) => {
//   return menus.map(item => {
//     if (item.children) {
//       return (
//         <Route key = { item.key } path = { item.key } element = { item.element }>
//           { renderRoute(item.children) }
//         </Route>
//       )
//     } else {
//       return (
//         <Route key = { item.key } path = { item.key } element = { item.element }>
//         </Route>
//       )
//     }
//   })
// }
// 定义路由组件  ---- 设置默认路由
export const renderRoute = (menus: IMenuProps[]) => {
  return menus.map(item => {
    if (item.children) {
      if (!!item.index) {
        return (
          <React.Fragment key={item.key}>
            <Route index element = { <Navigate to={item.key} replace = { true } />} />
            <Route path = { item.key } element = { item.element }>
              { renderRoute(item.children) }
            </Route>
          </React.Fragment>
        )
      } else {
        return (
          <Route key = { item.key } path = { item.key } element = { item.element }>
            { renderRoute(item.children) }
          </Route>
        )
      }
    } else {
      if (!!item.index) { // 如果index存在
        return (
          <React.Fragment key = { item.key }>
            <Route index element = { <Navigate to={item.key} replace = { true } />} />
            <Route path = { item.key } element = { item.element }></Route>
          </React.Fragment>
        )
      } else {
        return (
          <Route key = { item.key } path = { item.key } element = { item.element }></Route>
        )
      }
    }
  })
}
1
2
3
http://localhost:3000/banner   ===> http://localhost:3000/banner/home
http://localhost:3000/pro  ===> http://localhost:3000/pro/list/home
http://localhost:3000/account ===> http://localhost:3000/account/userlist

8.9 设置404页面

1
2
3
4
5
6
7
8
9
10
11
12
13
14
// src/views/error/Page404.tsx
import React, { FC } from 'react';

interface IPage404Props {

};

const Page404:FC<IPage404Props> = ({}) => {
  return (
    <h1>当前页面未找到</h1>
  )
};

export default Page404;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
// src/layout/components/AppMain.tsx 内容区域
import React, { FC } from 'react';
import { Layout } from 'antd';
import menus from '@/router/menu';
import { renderRoute } from '@/router/utils';
import { Routes, Route } from 'react-router-dom'
import Page404 from '@/views/error/Page404';
interface IAppMainProps {

};
const { Content } = Layout;
// const arr = renderRoute(menus)
// console.log('arr', arr[1])
const AppMain:FC<IAppMainProps> = () => {
  return (
    <Content
      className="site-layout-background"
      style={{
        margin: '24px 16px',
        padding: 24,
        minHeight: 280,
      }}
    >
      {/*
        多个路由需要定义时，包裹在Routes选项下
      */}
      <Routes>
        {
          renderRoute(menus)
        }
		{/*
            ++++++ 404+++++
        */}
        <Route path="*" element = { <Page404 /> } />
      </Routes>
    </Content>
  )
};

export default AppMain;

9 切换路由

上诉项目中，切换路由都是手动输入的，实际上应该点击左侧菜单栏进行路由导航。

左侧菜单的逻辑交互，前面已经生成了（openKeys 以及 onOpenChanges 实现）

现在通过点击事件来切换导航

9.1 点击切换路由

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
// src/layout/components/SideBar.tsx 左侧菜单栏
import React, { FC, useState } from 'react';

import { Layout, Menu, Image, MenuProps } from 'antd';
import { useAppSelector } from '@/store/hook';
import menus from '@/router/menu'
import logo from '@/logo.svg'
import { renderMenu } from '@/router/utils'
import { useNavigate } from 'react-router-dom';
interface ISideBarProps {

};

const { Sider } = Layout;

// 设置只展开一个菜单项
const rootSubmenuKeys: string[] = [];
menus.forEach(item => {
  item.children && rootSubmenuKeys.push(item.key)
})
console.log(rootSubmenuKeys)

const SideBar:FC<ISideBarProps> = () => {
  const collapsed = useAppSelector(state => state.app.collapsed);


  // 展开哪一项数据
  const [openKeys, setOpenKeys] = useState<string[]>([])
  // 打开一个菜单项时，需要做判断 - SubMenu 展开/关闭的回调
  const onOpenChange: MenuProps['onOpenChange'] = keys => {
    // 如果当前展开项是 轮播图管理，再点击 账户管理 ['/banner', '/account']
    console.log('keys', keys) // ['/banner'] =>  ['/banner', '/account']
    console.log('openKeys', openKeys) // [] => ['/banner']
    // 得到当前
    const latestOpenKey = keys.find(key => openKeys.indexOf(key) === -1);
    console.log('latestOpenKey', latestOpenKey) // /banner ===> /account
    if (rootSubmenuKeys.indexOf(latestOpenKey!) === -1) {
      setOpenKeys(keys);
    } else {
      setOpenKeys(latestOpenKey ? [latestOpenKey] : []);
    }
  }

  // 点击切换路由 // +++++++++
  const navigate = useNavigate()
  const changeUrl = ({ key }: { key: string }) => {
    console.log(key)
    navigate(key, { replace: false })
  }

  return (
    <Sider trigger={null} collapsible collapsed={collapsed}>
      <div className="logo" style={ {
        display: 'flex',
        justifyContent: 'center',
        alignItems: 'center',
        color: '#fff'
      }}>
        <Image src = { logo } width="28px" height="28px" preview={ false }></Image>
        { !collapsed && <div style={{
          height: '32px',
          overflow: 'hidden',
          lineHeight: '32px'
        }}>嗨购后台管理系统</div> }
      </div>
      <Menu
        theme="dark"
        mode="inline"
        defaultSelectedKeys={['1']}
        openKeys = { openKeys } // 打开哪一个菜单项
        onOpenChange = { onOpenChange } // 打开某一个菜单项时需要关闭其他菜单项
        onClick = { changeUrl } // +++++++++
      >
        {
          renderMenu(menus)
        }
      </Menu>
    </Sider>
  )
};

export default SideBar;

9.2 刷新保持左侧菜单状态

当页面刷新时，需要保证当前二级路由是展开的，且当前路由是被选中的状态

编写一个 getSubMenu 函数, 用来生成 ['pro', 'pro/list', 'pro/list/home']的数组，用于展开当前的 SubMenu 菜单项

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
// src/router/utils.tsx
import { Menu } from 'antd';
import { IMenuProps } from './inter';
import { Navigate, Route } from 'react-router-dom'
import React from 'react';
// 定义左侧菜单栏数据
export const renderMenu = (menus: IMenuProps[]) => {
  return menus.map(item => {
    if (item.children) {
      return (
        <Menu.SubMenu title = { item.label } icon = { item.icon } key = { item.key }>
          {
            renderMenu(item.children)
          }
        </Menu.SubMenu>
      )
    } else {
      return <Menu.Item key = { item.key } icon = { item.icon }>{ item.label }</Menu.Item>
    }
  })
}
// 定义路由组件
// export const renderRoute = (menus: IMenuProps[]) => {
//   return menus.map(item => {
//     if (item.children) {
//       return (
//         <Route key = { item.key } path = { item.key } element = { item.element }>
//           { renderRoute(item.children) }
//         </Route>
//       )
//     } else {
//       return (
//         <Route key = { item.key } path = { item.key } element = { item.element }>
//         </Route>
//       )
//     }
//   })
// }
// 定义路由组件  ---- 设置默认路由
export const renderRoute = (menus: IMenuProps[]) => {
  return menus.map(item => {
    if (item.children) {
      if (!!item.index) {
        return (
          <React.Fragment key={item.key}>
            <Route index element = { <Navigate to={item.key} replace = { true } />} />
            <Route path = { item.key } element = { item.element }>
              { renderRoute(item.children) }
            </Route>
          </React.Fragment>
        )
      } else {
        return (
          <Route key = { item.key } path = { item.key } element = { item.element }>
            { renderRoute(item.children) }
          </Route>
        )
      }
    } else {
      if (!!item.index) { // 如果index存在
        return (
          <React.Fragment key = { item.key }>
            <Route index element = { <Navigate to={item.key} replace = { true } />} />
            <Route path = { item.key } element = { item.element }></Route>
          </React.Fragment>
        )
      } else {
        return (
          <Route key = { item.key } path = { item.key } element = { item.element }></Route>
        )
      }
    }
  })
}

// 获取当前 需要展开的菜单项（可展开二级以及三级乃至更多展开项） +++++++++++
// pathname  /pro/list/cart
//  ===> ['/pro', '/pro/list', '/pro/list/cart']
export const getSubMenu = (pathname: string) => {
  // 1.以 / 分割 pathname.split('/')  //  ['', 'pro', 'list', 'cart']
  const pathArray = pathname.split('/').slice(1) // ['pro', 'list', 'cart']
  // console.log(pathArray)
  const result = pathArray.reduce((newArr, item, index) => {
    const str = newArr[index] + '/' + item
    newArr.push(str)
    return newArr
  }, [''])
  console.log('result', result)
  return result
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
// src/layout/components/SideBar.tsx 左侧菜单栏
import React, { FC, useState } from 'react';

import { Layout, Menu, Image, MenuProps } from 'antd';
import { useAppSelector } from '@/store/hook';
import menus from '@/router/menu'
import logo from '@/logo.svg'
import { renderMenu, getSubMenu } from '@/router/utils'
import { useLocation, useNavigate } from 'react-router-dom';
interface ISideBarProps {

};

const { Sider } = Layout;

// 设置只展开一个菜单项
const rootSubmenuKeys: string[] = [];
menus.forEach(item => {
  item.children && rootSubmenuKeys.push(item.key)
})

const SideBar:FC<ISideBarProps> = () => {
  const collapsed = useAppSelector(state => state.app.collapsed);
  // 获取当前路由的路径信息
  const { pathname } = useLocation() // ++++++++++
  // 当前选中的菜单项key数组
  // 初始值设置为 [pathname],刷新进入选中某一个菜单项
  const [selectedKeys, setSelectedKeys] = useState([pathname]) // ++++++++++

  // const [openKeys, setOpenKeys] = useState<string[]>(['/pro', '/pro/list'])
  const [openKeys, setOpenKeys] = useState<string[]>(getSubMenu(pathname))  // ++++++++++

  // 展开哪一项数据
  // const [openKeys, setOpenKeys] = useState<string[]>([]) // -------------
  // 打开一个菜单项时，需要做判断 - SubMenu 展开/关闭的回调
  const onOpenChange: MenuProps['onOpenChange'] = keys => {
    // 如果当前展开项是 轮播图管理，再点击 账户管理 ['/banner', '/account']
    console.log('keys', keys) // ['/banner'] =>  ['/banner', '/account']
    console.log('openKeys', openKeys) // [] => ['/banner']
    // 得到当前
    const latestOpenKey = keys.find(key => openKeys.indexOf(key) === -1);
    console.log('latestOpenKey', latestOpenKey) // /banner ===> /account
    if (rootSubmenuKeys.indexOf(latestOpenKey!) === -1) {
      setOpenKeys(keys);
    } else {
      setOpenKeys(latestOpenKey ? [latestOpenKey] : []);
    }
  }

  // 点击切换路由
  const navigate = useNavigate()
  const changeUrl = ({ key }: { key: string }) => {
    console.log(key)
    navigate(key, { replace: false })

    // 点击左侧菜单，切换菜单项，选中样式
    setSelectedKeys([key]) // ++++++++++
  }

  return (
    <Sider trigger={null} collapsible collapsed={collapsed}>
      <div className="logo" style={ {
        display: 'flex',
        justifyContent: 'center',
        alignItems: 'center',
        color: '#fff'
      }}>
        <Image src = { logo } width="28px" height="28px" preview={ false }></Image>
        { !collapsed && <div style={{
          height: '32px',
          overflow: 'hidden',
          lineHeight: '32px'
        }}>嗨购后台管理系统</div> }
      </div>
      <Menu
        theme="dark"
        mode="inline"
        defaultSelectedKeys={['1']}
        openKeys = { openKeys } // 打开哪一个菜单项
        onOpenChange = { onOpenChange } // 打开某一个菜单项时需要关闭其他菜单项
        onClick = { changeUrl }
        selectedKeys = { selectedKeys } // ++++++++++
      >
        {
          renderMenu(menus)
        }
      </Menu>
    </Sider>
  )
};

export default SideBar;

10 设置面包屑导航

10.1 参考文档

通过案例项目，得知 面包屑组件应该包含在 页面的头部 https://vvbin.cn/next/#/feat/breadcrumb/flat

参照组件库的面包屑 https://ant-design.gitee.io/components/breadcrumb-cn/#components-breadcrumb-demo-react-router

10.2 设置面包屑导航

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
/**
面包屑导航映射表
/: 系统首页
/banner: 轮播图管理
/banner/home： 首页轮播图
/banner/active: 活动页轮播图
/banner/add: 添加轮播图
/pro: 产品管理
/pro/list: 产品列表
/pro/list/home: 首页产品列表
/pro/list/detail: 详情推荐列表
/pro/list/cart: 购物车推荐列表
/pro/search: 筛选列表
/account: 账户管理
/account/userlist: 用户列表
/account/adminlist: 管理员列表
/setting: 设置
**/
// 如果将上述的映射表 放到一个对象中，可以通过地址栏的pathname属性 获取相应的 该对象的key值即可得到 对应的value值
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
// src/layout/components/AppBreadcrumb.tsx

import { IMenuProps } from '@/router/inter';
import menus from '@/router/menu';
import React, { FC } from 'react';
import { Breadcrumb } from 'antd'
import { useLocation, Link } from 'react-router-dom';

interface IAppBreadcrumbProps {

};

const breadcrumbNameMap: Record<string, string> = {}

const getBreadcrumbData = (menus: IMenuProps[]) => {
  menus.forEach(item => {
    if (item.children) {
      breadcrumbNameMap[item.key] = item.label
      getBreadcrumbData(item.children)
    } else {
      breadcrumbNameMap[item.key] = item.label
    }
  })
}
getBreadcrumbData(menus)
// console.log(breadcrumbNameMap)
/**
 * /: "系统首页"
/account: "账户管理"
/account/adminlist: "管理员列表"
/account/userlist: "用户列表"
/banner: "轮播图管理"
/banner/active: "活动页轮播图"
/banner/add: "添加轮播图"
/banner/home: "首页轮播图"
/pro: "产品管理"
/pro/list: "产品列表"
/pro/list/cart: "购物车推荐列表"
/pro/list/detail: "详情推荐列表"
/pro/list/home: "首页产品列表"
/pro/search: "筛选列表"
/setting: "设置"
 */

const AppBreadcrumb:FC<IAppBreadcrumbProps> = () => {
  const location = useLocation()
  // /pro/list/cart
  const pathSnippets = location.pathname.split('/').filter(i => i); // ['pro', 'list', 'cart']
  console.log(pathSnippets)

  const extraBreadcrumbItems = pathSnippets.map((_, index) => {
    // url /
    const url = `/${pathSnippets.slice(0, index + 1).join('/')}`;
    console.log(url) // /pro  /pro/list /pro/list/cart
    return (
      <Breadcrumb.Item key={url}>
        <Link to={url}>{breadcrumbNameMap[url]}</Link>
      </Breadcrumb.Item>
    );
  });

  const breadcrumbItems = [
    location.pathname === '/' ? null : <Breadcrumb.Item key="home">
    <Link to="/">系统首页</Link>
  </Breadcrumb.Item>,
  ].concat(extraBreadcrumbItems);

  return (
    <div style={{ height: '100%', display: 'flex', alignItems: 'center' }}>
      <Breadcrumb>{breadcrumbItems}</Breadcrumb>
    </div>
  )
};

export default AppBreadcrumb;
1
2
3
4
5
// src/layout/components/index.ts
export { default as SideBar } from './SideBar'
export { default as AppHeader } from './AppHeader'
export { default as AppMain } from './AppMain'
export { default as AppBreadcrumb } from './AppBreadcrumb'

头部组件加入了面包屑导航组件，尽可能不动原来的布局

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
// src/layout/components/AppHeader.tsx 头部组件
import React, { FC } from 'react';
import {
  MenuFoldOutlined,
  MenuUnfoldOutlined
} from '@ant-design/icons';
import { Layout } from 'antd';
import { useAppDispatch, useAppSelector } from '@/store/hook';
import { setCollapsed } from '@/store/modules/app'
import AppBreadcrumb from './AppBreadcrumb';
// import { useDispatch } from 'react-redux';
// import { AppDispatch } from '@/store';
const { Header } = Layout;
interface IAppHeaderProps {
};

const AppHeader:FC<IAppHeaderProps> = () => {
  // const [collapsed, setCollapsed] = useState(false);

  const collapsed = useAppSelector(state => state.app.collapsed)

  // const dispatch: AppDispatch = useDispatch() // ts中添加类型注解
  const dispatch = useAppDispatch() // ts推荐写法

  return (
    <Header className="site-layout-background" style={{ padding: 0, display: 'flex'  }}>
      {/* {React.createElement(collapsed ? MenuUnfoldOutlined : MenuFoldOutlined, {
        className: 'trigger',
        onClick: () => {
          dispatch(setCollapsed(!collapsed))
        }
      })} */}
      <div >
        {
          collapsed ? <MenuUnfoldOutlined  className="trigger" onClick={ () => {
            dispatch(setCollapsed(!collapsed))
          }}/> : <MenuFoldOutlined  className="trigger" onClick={ () => {
            dispatch(setCollapsed(!collapsed))
          }}/>
        }
      </div>
      <AppBreadcrumb />
    </Header>
  )
};

export default AppHeader;

随之而来的问题就是，当点击面包屑导航时，地址栏的路由已经发生了跳转，但是左侧菜单栏数据效果没有实时更新（左侧菜单栏组件早就创建完毕，选中和打开的选项已经做了固定， 点击面包屑没有引起左侧菜单栏组件的状态以及属性的更新，左侧菜单栏不会重新渲染）

此时可以在左侧菜单栏组件监听 路由的变化 – -useEffect

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
// src/layout/components/SideBar.tsx 左侧菜单栏
import React, { FC, useState, useEffect } from 'react';

import { Layout, Menu, Image, MenuProps } from 'antd';
import { useAppSelector } from '@/store/hook';
import menus from '@/router/menu'
import logo from '@/logo.svg'
import { renderMenu, getSubMenu } from '@/router/utils'
import { useLocation, useNavigate } from 'react-router-dom';
interface ISideBarProps {

};

const { Sider } = Layout;

// 设置只展开一个菜单项
const rootSubmenuKeys: string[] = [];
menus.forEach(item => {
  item.children && rootSubmenuKeys.push(item.key)
})

const SideBar:FC<ISideBarProps> = () => {
  const collapsed = useAppSelector(state => state.app.collapsed);
  // 获取当前路由的路径信息
  const { pathname } = useLocation()
  // 当前选中的菜单项key数组
  // 初始值设置为 [pathname],刷新进入选中某一个菜单项
  const [selectedKeys, setSelectedKeys] = useState([pathname])

  // const [openKeys, setOpenKeys] = useState<string[]>(['/pro', '/pro/list'])
  const [openKeys, setOpenKeys] = useState<string[]>(getSubMenu(pathname))

  // 展开哪一项数据
  // const [openKeys, setOpenKeys] = useState<string[]>([])
  // 打开一个菜单项时，需要做判断 - SubMenu 展开/关闭的回调
  const onOpenChange: MenuProps['onOpenChange'] = keys => {
    // 如果当前展开项是 轮播图管理，再点击 账户管理 ['/banner', '/account']
    // console.log('keys', keys) // ['/banner'] =>  ['/banner', '/account']
    // console.log('openKeys', openKeys) // [] => ['/banner']
    // 得到当前
    const latestOpenKey = keys.find(key => openKeys.indexOf(key) === -1);
    // console.log('latestOpenKey', latestOpenKey) // /banner ===> /account
    if (rootSubmenuKeys.indexOf(latestOpenKey!) === -1) {
      setOpenKeys(keys);
    } else {
      setOpenKeys(latestOpenKey ? [latestOpenKey] : []);
    }
  }

  // 点击切换路由
  const navigate = useNavigate()
  const changeUrl = ({ key }: { key: string }) => {
    // console.log(key)
    navigate(key, { replace: false })

    // 点击左侧菜单，切换菜单项，选中样式
    setSelectedKeys([key])
  }

  // 监听 pathname 的变化，然后调整左侧菜单打开和选中状态 ++++++++
  useEffect(() => {
    setSelectedKeys([pathname])
    setOpenKeys(getSubMenu(pathname))
  }, [pathname])

  return (
    <Sider trigger={null} collapsible collapsed={collapsed}>
      <div className="logo" style={ {
        display: 'flex',
        justifyContent: 'center',
        alignItems: 'center',
        color: '#fff'
      }}>
        <Image src = { logo } width="28px" height="28px" preview={ false }></Image>
        { !collapsed && <div style={{
          height: '32px',
          overflow: 'hidden',
          lineHeight: '32px'
        }}>嗨购后台管理系统</div> }
      </div>
      <Menu
        theme="dark"
        mode="inline"
        defaultSelectedKeys={['1']}
        openKeys = { openKeys } // 打开哪一个菜单项
        onOpenChange = { onOpenChange } // 打开某一个菜单项时需要关闭其他菜单项
        onClick = { changeUrl }
        selectedKeys = { selectedKeys }
      >
        {
          renderMenu(menus)
        }
      </Menu>
    </Sider>
  )
};

export default SideBar;

11.快捷切换页

image-20221025113910072

  • 系统默认路由为系统首页，所以第一个就为系统首页，且系统首页不可关闭
  • 切换路由，判断当前页面是否已存在，如果存在，找到列表项的索引值，设置该索引值选中效果，并且页面切换至该索引值
  • 如果当前路由对应的页面不存在，则在最后添加一项新的数据，并且设置最后一项为选中项

11.1 准备组件

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
// src/layout/components/AppTabs.tsx
import React, { FC } from 'react';

interface IAppTabsProps {

};

const AppTabs:FC<IAppTabsProps> = () => {
  return (
    <div style={ {
      'backgroundColor': '#f66',
      'height': 40
    } }></div>
  )
};

export default AppTabs;
1
2
3
4
5
6
// src/layout/components/index.ts
export { default as SideBar } from './SideBar'
export { default as AppHeader } from './AppHeader'
export { default as AppMain } from './AppMain'
export { default as AppBreadcrumb } from './AppBreadcrumb'
export { default as AppTabs } from './AppTabs'
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
// src/layout/Index.tsx 主要的布局文件
import { Layout } from 'antd';
import React  from 'react';

import { AppHeader, AppMain, AppTabs, SideBar } from './components'

const App: React.FC = () => {
  return (
    <Layout id='admin-app'>
      {/* 左侧菜单栏 */}
      <SideBar />
      <Layout className="site-layout">
        {/* 头部 */}
        <AppHeader />
        {/* 快捷切换组件 */}
        <AppTabs />
        {/* 内容 */}
        <AppMain />
      </Layout>
    </Layout>
  );
};

export default App;

11.2 处理数据

后期 监听地址栏 从tabsArr 中提取数据

1
2
3
4
5
6
7
8
9
10
const tabsArr = [{"label":"系统首页","key":"/"},
{"label":"首页轮播图","key":"/banner/home"},
{"label":"活动页轮播图","key":"/banner/active"},
{"label":"首页产品列表","key":"/pro/list/home"},
{"label":"详情推荐列表","key":"/pro/list/detail"},
{"label":"购物车推荐列表","key":"/pro/list/cart"},
{"label":"筛选列表","key":"/pro/search"},
{"label":"用户列表","key":"/account/userlist"},
{"label":"管理员列表","key":"/account/adminlist"},
{"label":"设置","key":"/setting"}]
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
// src/router/utils.tsx
import { Menu } from 'antd';
import { IMenuProps } from './inter';
import { Navigate, Route } from 'react-router-dom'
import React from 'react';
// 定义左侧菜单栏数据
export const renderMenu = (menus: IMenuProps[]) => {
  return menus.map(item => {
    if (item.children) {
      return (
        <Menu.SubMenu title = { item.label } icon = { item.icon } key = { item.key }>
          {
            renderMenu(item.children)
          }
        </Menu.SubMenu>
      )
    } else {
      return <Menu.Item key = { item.key } icon = { item.icon }>{ item.label }</Menu.Item>
    }
  })
}
// 定义路由组件
// export const renderRoute = (menus: IMenuProps[]) => {
//   return menus.map(item => {
//     if (item.children) {
//       return (
//         <Route key = { item.key } path = { item.key } element = { item.element }>
//           { renderRoute(item.children) }
//         </Route>
//       )
//     } else {
//       return (
//         <Route key = { item.key } path = { item.key } element = { item.element }>
//         </Route>
//       )
//     }
//   })
// }
// 定义路由组件  ---- 设置默认路由
export const renderRoute = (menus: IMenuProps[]) => {
  return menus.map(item => {
    if (item.children) {
      if (!!item.index) {
        return (
          <React.Fragment key={item.key}>
            <Route index element = { <Navigate to={item.key} replace = { true } />} />
            <Route path = { item.key } element = { item.element }>
              { renderRoute(item.children) }
            </Route>
          </React.Fragment>
        )
      } else {
        return (
          <Route key = { item.key } path = { item.key } element = { item.element }>
            { renderRoute(item.children) }
          </Route>
        )
      }
    } else {
      if (!!item.index) { // 如果index存在
        return (
          <React.Fragment key = { item.key }>
            <Route index element = { <Navigate to={item.key} replace = { true } />} />
            <Route path = { item.key } element = { item.element }></Route>
          </React.Fragment>
        )
      } else {
        return (
          <Route key = { item.key } path = { item.key } element = { item.element }></Route>
        )
      }
    }
  })
}

// 获取当前 需要展开的菜单项（可展开二级以及三级乃至更多展开项）
// pathname  /pro/list/cart
//  ===> ['/pro', '/pro/list', '/pro/list/cart']
export const getSubMenu = (pathname: string) => {
  // 1.以 / 分割 pathname.split('/')  //  ['', 'pro', 'list', 'cart']
  const pathArray = pathname.split('/').slice(1) // ['pro', 'list', 'cart']
  // console.log(pathArray)
  const result = pathArray.reduce((newArr, item, index) => {
    // '/pro'
    // '/pro/list'
    // 'pro/list/cart'
    const str = newArr[index] + '/' + item
    // ['', '/pro']
    // ['', '/pro', '/pro/list']
    // ['', '/pro', '/pro/list', '/pro/list/cart']
    newArr.push(str)
    return newArr
  }, [''])
  // console.log('result', result)
  return result
}

export interface ITabProps {
  label: string
  key: string
}
// 提取快捷切换页的数据
const tabsArr: ITabProps[] = []
export const getTabsData = (menus: IMenuProps[]) => {
  // const tabsArr: ITabProps[] = []
  menus.forEach(item => {
    if (item.children) {
      getTabsData(item.children)
    } else {
      tabsArr.push({
        label: item.label,
        key: item.key
      })
    }
  })
  return tabsArr
}

11.3 监听路由添加数据

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
// src/layout/components/AppTabs.tsx
import menus from '@/router/menu';
import { getTabsData } from '@/router/utils';
import { Tag } from 'antd'
import React, { FC, useState, useEffect } from 'react';
import { useLocation } from 'react-router-dom';

interface IAppTabsProps {

};

const tabArrs = getTabsData(menus)
console.log(tabArrs)
/**
 *
 * [{"label":"系统首页","key":"/"},
 {"label":"首页轮播图","key":"/banner/home"},
 {"label":"活动页轮播图","key":"/banner/active"},
 {"label":"首页产品列表","key":"/pro/list/home"},
 {"label":"详情推荐列表","key":"/pro/list/detail"},
 {"label":"购物车推荐列表","key":"/pro/list/cart"},
 {"label":"筛选列表","key":"/pro/search"},
 {"label":"用户列表","key":"/account/userlist"},
 {"label":"管理员列表","key":"/account/adminlist"},
 {"label":"设置","key":"/setting"}]
 */

const AppTabs:FC<IAppTabsProps> = () => {
  // 获取当前的路由信息
  const { pathname } = useLocation()

  // 准备快捷导航的真实的数据
  const [arr, setArr] = useState([{ label: '系统首页', key: '/' }])
  // 当前选中项
  const [current, setCurrent] = useState(0)

  // 监听路由
  useEffect(() => {
    const index = arr.findIndex(item => item.key === pathname)

    if (index === -1) { // 相当于现在展示数据数组arr中没有当前的页面
      // 从原始数据中获取值
      const item = tabArrs.find(item => item.key === pathname)
      const newArr = arr
      // 如果item被查询到，将查询到的数据填充到arr中
      item && newArr.push(item) // 添加数据

      // 修改状态
      setArr(newArr)
      setCurrent(arr.length - 1)

    } else {
      // 当前的数据中含有此页面，只需要改变索引值
      setCurrent(index)
    }
  }, [pathname, arr])


  return (
    <div style={ {
      'backgroundColor': '#fff',
      'height': 40,
      'borderTop': '1px solid #ccc',
      'borderBottom': '1px solid #ccc',
      'overflow': 'auto',
      'whiteSpace': 'nowrap' // 不换行 滚动条
    } }>
      {
        arr && arr.map((item, index) => {
          return (
            <Tag
              key = { item.key }
              style={ {
                height: 36,
                lineHeight: '36px',
                marginTop: 2,
                marginLeft: 5,
                color: current === index ? '#fff' : '#333'
              } }
              color = { current === index ? '#108ee9' : '#efefef' }
            >
              { item.label }
            </Tag>
          )
        })
      }
    </div>
  )
};

export default AppTabs;

11.4 点击tab页切换路由,关闭效果

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
// src/layout/components/AppTabs.tsx
import menus from '@/router/menu';
import { getTabsData } from '@/router/utils';
import { Tag } from 'antd'
import React, { FC, useState, useEffect } from 'react';
import { useLocation, useNavigate } from 'react-router-dom';

interface IAppTabsProps {

};

const tabArrs = getTabsData(menus)
console.log(tabArrs)
/**
 *
 * [{"label":"系统首页","key":"/"},
 {"label":"首页轮播图","key":"/banner/home"},
 {"label":"活动页轮播图","key":"/banner/active"},
 {"label":"首页产品列表","key":"/pro/list/home"},
 {"label":"详情推荐列表","key":"/pro/list/detail"},
 {"label":"购物车推荐列表","key":"/pro/list/cart"},
 {"label":"筛选列表","key":"/pro/search"},
 {"label":"用户列表","key":"/account/userlist"},
 {"label":"管理员列表","key":"/account/adminlist"},
 {"label":"设置","key":"/setting"}]
 */

const AppTabs:FC<IAppTabsProps> = () => {
  // 获取当前的路由信息
  const { pathname } = useLocation()

  // 准备快捷导航的真实的数据
  const [arr, setArr] = useState([{ label: '系统首页', key: '/' }])
  // 当前选中项
  const [current, setCurrent] = useState(0)

  // 监听路由
  useEffect(() => {
    const index = arr.findIndex(item => item.key === pathname)

    if (index === -1) { // 相当于现在展示数据数组arr中没有当前的页面
      // 从原始数据中获取值
      const item = tabArrs.find(item => item.key === pathname)
      const newArr = arr
      // 如果item被查询到，将查询到的数据填充到arr中
      item && newArr.push(item) // 添加数据

      // 修改状态
      setArr(newArr)
      setCurrent(arr.length - 1)

    } else {
      // 当前的数据中含有此页面，只需要改变索引值
      setCurrent(index)
    }
  }, [pathname, arr])


  const navigate = useNavigate()
  return (
    <div style={ {
      'backgroundColor': '#fff',
      'height': 36,
      'borderTop': '1px solid #ccc',
      'borderBottom': '1px solid #ccc',
      'overflow': 'auto',
      'whiteSpace': 'nowrap' // 不换行 滚动条
    } }>
      {
        arr && arr.map((item, index) => {
          return (
            <Tag
              key = { item.key }
              style={ {
                height: 32,
                lineHeight: '32px',
                marginTop: 2,
                marginLeft: 5,
                color: current === index ? '#fff' : '#333',
                cursor: 'pointer'
              } }
              color = { current === index ? '#108ee9' : '#efefef' }
              onClick = { () => {// ++++++
                navigate(item.key, { replace: false })
                setCurrent(index)
              }}
              closable = { current === index && index !== 0 } // ++++++
              onClose = { (e) => { // ++++++
                e.preventDefault()
                arr.splice(index, 1)
                setArr(arr)
                setCurrent(index - 1)
                navigate(arr[current - 1].key, { replace: false })
              }}
            >
              { item.label }
            </Tag>
          )
        })
      }
    </div>
  )
};

export default AppTabs;

12.数据请求的封装

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
// src/utils/request.ts
import { message } from 'antd'
import axios, { AxiosRequestConfig } from 'axios'
import store from 'store2'

const isDev = process.env.NODE_ENV === 'development'

const instance = axios.create({
  baseURL: isDev ? 'http://121.89.205.189:3000/admin' : 'http://121.89.205.189:3000/admin',
  timeout: 6000
})


// 请求拦截器封装
instance.interceptors.request.use((config) => {
  // 可以从本地获取用户的信息，如果用户的信息存在，提取Token,通过头信息传递给服务器
  // 以前给本地存储中存储多个数据，本项目存储的是一个对象 { loginState: true, adminname: '', 'X-Token': '', role: 1, checkedKeys: []}
  const storeUsers = store.get('haigou-users') // 存的时候就是存的对象

  // 传递token信息
  config.headers!.token = storeUsers && (storeUsers['X-Token'] || '')

  return config
}, (error) => Promise.reject(error))

// 响应拦截器封装
instance.interceptors.response.use((response: any) => {
  // 验证token
  if (response.data.code === '10119') {
    // token 无效
    message.warning('登录失效，请重新登录');

    // 防止后期系统首页以及登录来回切换
    store.remove('haigou-users')

    // 跳转到登录页面 --- 如果使用的是 HashRouter ,此处地址需要改为 '/#/login'
    window.location.href = '/login'

    // 返回
    return
  }

  // 登录成功 放行
  return response
}, (error) => Promise.reject(error))

// 自定义各种常用的restful api的请求
// axios.get('url', { params: { key: value } })
// axios.post('url', { key: value })
// axios({ url: '', method: 'GET', params: { key: value }})
// axios({ url: '', method: 'POST', data: { key: value }})
export default function request( config: AxiosRequestConfig ) {
  // 接口请求 必须参数  url method  data  headers
  const { url = '', method = 'GET', data = {}, headers = {} } = config

  // 区分不同的数据请求 为了执行时传入的数据请求方式统一性 GEt GeT get GET
  switch (method.toUpperCase()) {
    case 'GET':
      return instance.get(url, { params: data })

    case 'POST':
      // 可能数据请求方式 表单提交  文件提交   默认json
      // 表单提交
      if (headers['content-type'] === 'application/x-www-form-url-encoded') {
        // 转换参数  URLSearchParams  / 第三方库 qs
        const p = new URLSearchParams()
        for (const key in data) {
          p.append(key, data[key])
        }
        return instance.post(url, p, { headers })
      }

      // 文件提交
      if (headers['content-type'] === 'multipart/form-data') {
        const p = new FormData()
        for (const key in data) {
          p.append(key, data[key])
        }
        return instance.post(url, p, { headers })
      }

      // 默认 application/json
      return instance.post(url, data)

    // 修改数据 - 所有的数据的更新
    case 'PUT':
      return instance.put(url, data)

    // 删除数据
    case 'DELETE':
      return instance.delete(url, { data })

    // 修改数据 - 部分的数据的更新
    case 'PATCH':
      return instance.patch(url, data)

    default:
      return instance(config)
  }
}

按照思维来看，此时需要请求以及渲染轮播图管理相关功能，但是查看后端接口，发现基本所有的借口都需要基于 token，那么需要首先完成登录功能

接口文档：http://121.89.205.189:3000/admindoc/

13 构建登录页面

13.1 参考组件库组件

https://ant-design.gitee.io/components/form-cn/#components-form-demo-normal-login

13.2 构造登录接口API

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/api/admin.ts

import request from '@/utils/request'
export interface IAdminParams {
  adminname: string
  password: string
}

// 登录
export function adminLoginFn (params: IAdminParams) {
  return request({
    url: '/admin/login',
    method: 'POST',
    data: params
  })
}

13.3 创建登录的页面

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/login/Index.tsx
import React, { FC } from 'react';

interface ILoginProps {

};

const Login:FC<ILoginProps> = () => {
  return (
    <>
      <h1>登录页面</h1>
    </>
  )
};

export default Login;

13.4 创建登录路由

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
// src/App.tsx
import React, { FC } from 'react';
import Index from '@/layout/Index'
import Login from '@/views/login/Index'

import { Routes, Route } from 'react-router-dom'

interface IAppProps {
};

const App:FC<IAppProps> = () => {
  // reactrouterv6版本中需要加*
  return (
    <Routes>
      <Route path="/login" element = { <Login /> } />
      <Route path="/*" element = { <Index /> } />
    </Routes>
  )
};

export default App;

地址栏访问 http://localhost:3000/login 即可看到登录页面出现，其余路由还保持和之前一致

13.4 完善登录界面

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
// src/views/login/Index.tsx
import { LockOutlined, UserOutlined } from '@ant-design/icons';
import { Button, Form, Input } from 'antd';
import React from 'react';
import './style.less';

const App: React.FC = () => {
  const onFinish = (values: any) => {
    console.log('Received values of form: ', values);
  };

  return (
    <div id='loginForm'>
      <div className='loginBox'>
        <h1>嗨购管理系统</h1>
        <Form
          name="normal_login"
          className="login-form"
          initialValues={{ // 表单自动填充的字段
            adminname: 'admin',
            password: '123456'
          }}
          onFinish={onFinish}
        >
          <Form.Item
            name="adminname"
            rules={[{ required: true, message: '请输入管理员账户!' }]}
          >
            <Input prefix={<UserOutlined className="site-form-item-icon" />} placeholder="账户" />
          </Form.Item>
          <Form.Item
            name="password"
            rules={[{ required: true, message: '请输入密码!' }]}
          >
            <Input
              prefix={<LockOutlined className="site-form-item-icon" />}
              type="password"
              placeholder="密码"
            />
          </Form.Item>


          <Form.Item>
            <Button type="primary" htmlType="submit" className="login-form-button">
              登 录
            </Button>

          </Form.Item>
        </Form>
      </div>
    </div>

  );
};

export default App;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
// src/views/login/style.less
#loginForm {
  height: 100%;
  display: flex;
  flex-direction: column;
  justify-content: center;
  align-items: center;
  background: url(https://cas.1000phone.net/cas/images/login/bg.png) no-repeat center center;
  background-size: cover;
  .loginBox {
    width: 400px;
    min-height: 300px;
    background-color: #fff;
    border-radius: 30px;
    display: flex;
    flex-direction: column;
    justify-content: center;
    align-items: center;
    padding: 50px 0;
    .login-form {
      width: 300px;
    }
  }
}

#loginForm .login-form-forgot {
  float: right;
}
#loginForm .ant-col-rtl .login-form-forgot {
  float: left;
}
#loginForm .login-form-button {
  width: 100%;
}

使用状态管理器，异步操作可以在组件，也可以在状态管理器

14 执行登录

使用状态管理器（RTK）管理登录信息。

14.1 构建模块 admins

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
// src/store/modules/admins.ts
import { createSlice, PayloadAction } from '@reduxjs/toolkit'
import store from 'store2'

export interface IAdminState {
  loginState: boolean
  adminname: string
  token: string
  role: number
  checkedKeys: any[]
}

// const initialState: IAdminState = store.get('haigou-users') ? {
//   loginState: store.get('haigou-users')['loginState'],
//   adminname: store.get('haigou-users')['adminname'],
//   token: store.get('haigou-users')['X-Token'],
//   role: store.get('haigou-users')['role'],
//   checkedKeys: store.get('haigou-users')['checkedKeys']
// } : {
//   loginState: false,
//   adminname: '',
//   token: '',
//   role: 0,
//   checkedKeys: []
// }

const initialState: IAdminState =  {
  loginState: store.get('haigou-users') ? store.get('haigou-users')['loginState'] : false,
  adminname: store.get('haigou-users') ? store.get('haigou-users')['adminname'] : '',
  token: store.get('haigou-users') ? store.get('haigou-users')['X-Token'] : '',
  role: store.get('haigou-users') ? store.get('haigou-users')['role'] : 0,
  checkedKeys: store.get('haigou-users') ? store.get('haigou-users')['checkedKeys'] : []
}
const adminSlice = createSlice({
  name: 'admins',
  initialState,
  reducers: {
    changeLoginState (state, action: PayloadAction<boolean>) {
      state.loginState = action.payload
    },
    changeAdminName (state, action: PayloadAction<string>) {
      state.adminname = action.payload
    },
    changeToken (state, action: PayloadAction<string>) {
      state.token = action.payload
    },
    changeRole (state, action: PayloadAction<number>) {
      state.role = action.payload
    },
    changecheckedKeys (state, action: PayloadAction<any[]>) {
      state.checkedKeys = action.payload
    }
  }
})

export const {
  changeLoginState,
  changeAdminName,
  changeToken,
  changeRole,
  changecheckedKeys
} = adminSlice.actions

export default adminSlice.reducer

14.2 装载模块

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
// src/store/index.ts
import { configureStore } from '@reduxjs/toolkit';
import appReducer from './modules/app'
import adminReducer from './modules/admins'
const store = configureStore({
  reducer: { // 整合模块
    app: appReducer,
    admins: adminReducer
  }
});

// redux store  store.getState  store.subscribe  store.dispatch
// 定义State和dispatch类型  从 store 本身推断出 `RootState` 和 `AppDispatch` 类型
export type RootState = ReturnType<typeof store.getState> // js 不需要
export type AppDispatch = typeof store.dispatch // js 不需要


export default store;

14.3 登录实现

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
// src/views/login/Index.tsx
import { IAdminParams, adminLoginFn } from '@/api/admin';
import { LockOutlined, UserOutlined } from '@ant-design/icons';
import { Button, Form, Input, message } from 'antd';
import store from 'store2'
import React from 'react';
import './style.less';
import { useAppDispatch } from '@/store/hook';
import { changeAdminName, changecheckedKeys, changeLoginState, changeRole, changeToken } from '@/store/modules/admins';
import { useNavigate } from 'react-router-dom';

const App: React.FC = () => {

  const dispatch = useAppDispatch()

  const navigate = useNavigate()

  const onFinish = (values: IAdminParams) => {
    adminLoginFn(values).then(res => {
      console.log(res.data)
      switch (res.data.code) {
        case '10003':
          message.error('密码错误')
          break;
        case '10005':
          message.error('没有该账户，请联系超管')
          break;
        default:
          message.success('登录成功')

          // 存信息到本地以及状态管理器
          const result = res.data.data
          const haigouUsers = {
            loginState: true,
            'X-Token': result.token,
            adminname: result.adminname,
            role: result.role,
            checkedKeys: result.checkedkeys
          }
          store.set('haigou-users', haigouUsers)

          dispatch(changeLoginState(true))
          dispatch(changeAdminName(result.adminname))
          dispatch(changeToken(result.token))
          dispatch(changeRole(result.role))
          dispatch(changecheckedKeys(result.checkedkeys))

          // 跳转到系统首页
          navigate('/', { replace: true })
          break;
      }
    })

  };

  return (
    <div id='loginForm'>
      <div className='loginBox'>
        <h1>嗨购管理系统</h1>
        <Form
          name="normal_login"
          className="login-form"
          initialValues={{ // 表单自动填充的字段
            adminname: 'admin',
            password: '123456'
          }}
          onFinish={onFinish}
        >
          <Form.Item
            name="adminname"
            rules={[{ required: true, message: '请输入管理员账户!' }]}
          >
            <Input prefix={<UserOutlined className="site-form-item-icon" />} placeholder="账户" />
          </Form.Item>
          <Form.Item
            name="password"
            rules={[{ required: true, message: '请输入密码!' }]}
          >
            <Input
              prefix={<LockOutlined className="site-form-item-icon" />}
              type="password"
              placeholder="密码"
            />
          </Form.Item>


          <Form.Item>
            <Button type="primary" htmlType="submit" className="login-form-button">
              登 录
            </Button>

          </Form.Item>
        </Form>
      </div>
    </div>

  );
};

export default App;

15.前端登录验证

当前路由在登录页面，判断用户的登录状态，如果登录，则跳转到系统的首页，如果未登录，显示登录页面

当前路由在非登录页面，判断用户的登录状态，如果登录，则显示非登录页面，如果未登录，跳转到登录页面

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
// src/App.tsx
import React, { FC } from 'react';
import Index from '@/layout/Index'
import Login from '@/views/login/Index'

import { Routes, Route, Navigate } from 'react-router-dom'
import { useAppSelector } from './store/hook';

interface IAppProps {
};

const App:FC<IAppProps> = () => {
  const loginState = useAppSelector(state => state.admins.loginState)
  // reactrouterv6版本中需要加*
  return (
    <Routes>
      <Route path="/login" element = { loginState ? <Navigate to="/"/> : <Login /> } />
      <Route path="/*" element = { loginState ? <Index /> : <Navigate to="/login" /> } />
    </Routes>
  )
};

export default App;

16 .后端token校验

封装axios时已经实现 — 响应拦截器

后台管理系统都需要请求数据，而请求数据 都需要添加token字段

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
// src/utils/request.ts
....
// 请求拦截器封装
instance.interceptors.request.use((config) => {
  // 可以从本地获取用户的信息，如果用户的信息存在，提取Token,通过头信息传递给服务器
  // 以前给本地存储中存储多个数据，本项目存储的是一个对象 { loginState: true, adminname: '', 'X-Token': '', role: 1, checkedKeys: []}
  const storeUsers = store.get('haigou-users') // 存的时候就是存的对象

  // 传递token信息
  config.headers!.token = storeUsers && (storeUsers['X-Token'] || '')

  return config
}, (error) => Promise.reject(error))

// 响应拦截器封装
instance.interceptors.response.use((response: any) => {
  // 验证token
  if (response.data.code === '10119') {
    // token 无效
    message.warning('登录失效，请重新登录');

    // 防止后期系统首页以及登录来回切换
    store.remove('haigou-users')

    // 跳转到登录页面 --- 如果使用的是 HashRouter ,此处地址需要改为 '/#/login'
    window.location.href = '/login'

    // 返回
    return
  }

  // 登录成功 放行
  return response
}, (error) => Promise.reject(error))
....

17.退出登录

17.1 实现退出登录

https://ant-design.gitee.io/components/dropdown-cn/#components-dropdown-demo-trigger

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
// src/layout/components/AppHeader.tsx 头部组件
import React, { FC } from 'react';
import {
  MenuFoldOutlined,
  MenuUnfoldOutlined,
  DownOutlined
} from '@ant-design/icons';
import { Layout, Dropdown, Space, Menu } from 'antd';
import { useAppDispatch, useAppSelector } from '@/store/hook';
import { setCollapsed } from '@/store/modules/app'
import AppBreadcrumb from './AppBreadcrumb';
import { useNavigate } from 'react-router-dom';
import store from 'store2';
import { changeLoginState } from '@/store/modules/admins';
// import { useDispatch } from 'react-redux';
// import { AppDispatch } from '@/store';
const { Header } = Layout;
interface IAppHeaderProps {
};

const AppHeader:FC<IAppHeaderProps> = () => {
  // const [collapsed, setCollapsed] = useState(false);

  const collapsed = useAppSelector(state => state.app.collapsed)

  // const dispatch: AppDispatch = useDispatch() // ts中添加类型注解
  const dispatch = useAppDispatch() // ts推荐写法
  const navigate = useNavigate()
  const menu = (
    <Menu
      onClick={ ({key}) => {
        console.log(key)
        if (key === '/setting') {
          navigate(key)
        } else if (key === 'logout'){
          store.remove('haigou-users')
          dispatch(changeLoginState(false))
          navigate('/login')
        } else {
          // 其余选项
        }
      }}
      items={[
        {
          label: '设置',
          key: '/setting',
        },
        {
          type: 'divider',
        },
        {
          label: '退出',
          key: 'logout',
        },
      ]}
    />
  );

  const adminname = useAppSelector(state => state.admins.adminname)
  return (
    <Header className="site-layout-background" style={{ padding: 0, display: 'flex'  }}>
      {/* {React.createElement(collapsed ? MenuUnfoldOutlined : MenuFoldOutlined, {
        className: 'trigger',
        onClick: () => {
          dispatch(setCollapsed(!collapsed))
        }
      })} */}
      <div >
        {
          collapsed ? <MenuUnfoldOutlined  className="trigger" onClick={ () => {
            dispatch(setCollapsed(!collapsed))
          }}/> : <MenuFoldOutlined  className="trigger" onClick={ () => {
            dispatch(setCollapsed(!collapsed))
          }}/>
        }
      </div>
      <AppBreadcrumb />
      <div style={{ position: 'absolute', right: '16px'  }}>
        <Dropdown overlay={menu} trigger={['click']}>
          <span>
            <Space>
              { adminname }
              <DownOutlined />
            </Space>
          </span>
        </Dropdown>
      </div>
    </Header>
  )
};

export default AppHeader;

17.2 保留退出时的页面

先获取退出登陆时 路由的地址

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
// src/layout/components/AppHeader.tsx 头部组件
import React, { FC } from 'react';
import {
  MenuFoldOutlined,
  MenuUnfoldOutlined,
  DownOutlined
} from '@ant-design/icons';
import { Layout, Dropdown, Space, Menu } from 'antd';
import { useAppDispatch, useAppSelector } from '@/store/hook';
import { setCollapsed } from '@/store/modules/app'
import AppBreadcrumb from './AppBreadcrumb';
import { useLocation, useNavigate } from 'react-router-dom';
import store from 'store2';
import { changeLoginState } from '@/store/modules/admins';
// import { useDispatch } from 'react-redux';
// import { AppDispatch } from '@/store';
const { Header } = Layout;
interface IAppHeaderProps {
};

const AppHeader:FC<IAppHeaderProps> = () => {
  // const [collapsed, setCollapsed] = useState(false);

  const collapsed = useAppSelector(state => state.app.collapsed)

  // const dispatch: AppDispatch = useDispatch() // ts中添加类型注解
  const dispatch = useAppDispatch() // ts推荐写法
  const navigate = useNavigate()
  const { pathname } = useLocation() // 当前页面地址 // +++++++++
  const menu = (
    <Menu
      onClick={ ({key}) => {
        console.log(key)
        if (key === '/setting') {
          navigate(key)
        } else if (key === 'logout'){
          store.remove('haigou-users')
          dispatch(changeLoginState(false))
          navigate('/login?r=' + pathname) // +++++++++
        } else {
          // 其余选项
        }
      }}
      items={[
        {
          label: '设置',
          key: '/setting',
        },
        {
          type: 'divider',
        },
        {
          label: '退出',
          key: 'logout',
        },
      ]}
    />
  );

  const adminname = useAppSelector(state => state.admins.adminname)
  return (
    <Header className="site-layout-background" style={{ padding: 0, display: 'flex'  }}>
      {/* {React.createElement(collapsed ? MenuUnfoldOutlined : MenuFoldOutlined, {
        className: 'trigger',
        onClick: () => {
          dispatch(setCollapsed(!collapsed))
        }
      })} */}
      <div >
        {
          collapsed ? <MenuUnfoldOutlined  className="trigger" onClick={ () => {
            dispatch(setCollapsed(!collapsed))
          }}/> : <MenuFoldOutlined  className="trigger" onClick={ () => {
            dispatch(setCollapsed(!collapsed))
          }}/>
        }
      </div>
      <AppBreadcrumb />
      <div style={{ position: 'absolute', right: '16px'  }}>
        <Dropdown overlay={menu} trigger={['click']}>
          <span>
            <Space>
              { adminname }
              <DownOutlined />
            </Space>
          </span>
        </Dropdown>
      </div>
    </Header>
  )
};

export default AppHeader;

正常考虑问题思路是，在登陆时，登录成功之后 判断有没有退出时的记录地址，然后跳转

但实际上程序运行的思路是，放你登录成功之后，已经修改了登录状态，状态的改变引起视图的二次渲染，所以真正决定跳转地址的是App.tsx组件

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
// src/App.tsx
import React, { FC } from 'react';
import Index from '@/layout/Index'
import Login from '@/views/login/Index'

import { Routes, Route, Navigate, useSearchParams } from 'react-router-dom'
import { useAppSelector } from './store/hook';

interface IAppProps {
};

const App:FC<IAppProps> = () => {
  const loginState = useAppSelector(state => state.admins.loginState)

  const [params] = useSearchParams() // /login?r=/banner/home
  const url = params.get('r') as string
  console.log(url) // /banner/home
  // reactrouterv6版本中需要加*
  return (
    <Routes>
      <Route path="/login" element = { loginState ? <Navigate to={  url ? url : '/' }/> : <Login /> } />
      <Route path="/*" element = { loginState ? <Index /> : <Navigate to="/login" /> } />
    </Routes>
  )
};

export default App;

18.隐藏子菜单

设置路由已经放到头部，左侧菜单栏不需要显示设置选项了

给router/menu.tsx中不需要出现的 添加 hidden

给添加轮播图以及设置选项添加 hidden 属性

1
2
3
4
5
6
7
8
9
10
11
12
13
// src/router/inter.d.ts
import { ReactNode } from 'react'

// key属性可以使用 左侧菜单的路由地址，因为它具有唯一性
export interface IMenuProps {
  label: string
  key: string
  icon?: ReactNode
  children?: IMenuProps[]
  element: ReactNode // 因为页面创建时 指定了多级了路由的页面，故这里设置为 必传属性
  index?: 1 | 0 // 不建议使用 boolean，因为react在渲染属性时，具有boolean值的属性会有特殊的含义
  hidden?: 1 | 0 // ++++++++
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
// src/router/menu.tsx
import { IMenuProps } from './inter'
import {
  HomeOutlined,
  UploadOutlined,
  PictureOutlined,
  ProfileOutlined,
  OrderedListOutlined,
  FilterOutlined,
  TeamOutlined,
  UserOutlined,
  SettingOutlined
} from '@ant-design/icons'

import Home from '@/views/home/Index'

import Banner from '@/views/banner/Index'
import BannerList from '@/views/banner/List'
import BannerActive from '@/views/banner/Active'
import BannerAdd from '@/views/banner/Add'

import Product from '@/views/product/Index'
import ProductSearch from '@/views/product/Search'
import ProductList from '@/views/product/list/Index'
import ProductHomeList from '@/views/product/list/Home'
import ProductDetailList from '@/views/product/list/Detail'
import ProductCartList from '@/views/product/list/Cart'

import Account from '@/views/account/Index'
import UserList from '@/views/account/UserList'
import AdminList from '@/views/account/AdminList'

import Setting from '@/views/setting/Index'

const menus: IMenuProps[] = [
  {
    label: '系统首页',
    key: '/',
    icon: <HomeOutlined />,
    element: <Home />
  },
  {
    label: '轮播图管理',
    key: '/banner',
    icon: <UploadOutlined />,
    element: <Banner />,
    children: [
      {
        label: '首页轮播图',
        key: '/banner/home',
        icon: <PictureOutlined />,
        element: <BannerList />,
        index: 1
      },
      {
        label: '活动页轮播图',
        key: '/banner/active',
        icon: <PictureOutlined />,
        element: <BannerActive />
      },
      {
        label: '添加轮播图',
        key: '/banner/add',
        icon: <UploadOutlined />,
        element: <BannerAdd />,
        hidden: 1 // +++++++
      },
    ]
  },
  {
    label: '产品管理',
    key: '/pro',
    icon: <ProfileOutlined />,
    element: <Product />,
    children: [
      {
        label: '产品列表',
        key: '/pro/list',
        icon: <OrderedListOutlined />,
        element: <ProductList />,
        index: 1,
        children: [
          {
            label: '首页产品列表',
            key: '/pro/list/home',
            element: <ProductHomeList />,
            index: 1
          },
          {
            label: '详情推荐列表',
            key: '/pro/list/detail',
            element: <ProductDetailList />
          },
          {
            label: '购物车推荐列表',
            key: '/pro/list/cart',
            element: <ProductCartList />
          },
        ]
      },
      {
        label: '筛选列表',
        key: '/pro/search',
        icon: <FilterOutlined />,
        element: <ProductSearch />
      },
    ]
  },
  {
    label: '账户管理',
    key: '/account',
    icon: <TeamOutlined />,
    element: <Account />,
    children: [
      {
        label: '用户列表',
        key: '/account/userlist',
        icon: <UserOutlined />,
        element: <UserList />,
        index: 1
      },
      {
        label: '管理员列表',
        key: '/account/adminlist',
        icon: <UserOutlined />,
        element: <AdminList />
      }
    ]
  },
  {
    label: '设置',
    key: '/setting',
    icon: <SettingOutlined />,
    element: <Setting />,
    hidden: 1  ++++++
  }
]


export default menus

渲染左侧菜单栏数据时，可以过滤数据，将有hidden: 1子菜单删除掉

4.20.0以前写法

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
// src/router/utils.tsx
import { Menu } from 'antd';
import { IMenuProps } from './inter';
import { Navigate, Route } from 'react-router-dom'
import React from 'react';
// 定义左侧菜单栏数据
export const renderMenu = (menus: IMenuProps[]) => {
  return menus.map(item => {
    if (item.children) { // ++++++++
      return item.hidden ? null : (<Menu.SubMenu title = { item.label } icon = { item.icon } key = { item.key }>
      {
        renderMenu(item.children)
      }
    </Menu.SubMenu>)
    } else {// ++++++++
      return item.hidden  ?  null : <Menu.Item key = { item.key } icon = { item.icon }>{ item.label }</Menu.Item>
    }
  })
}
// 定义路由组件  ---- 设置默认路由
export const renderRoute = (menus: IMenuProps[]) => {
  return menus.map(item => {
    if (item.children) {
      if (!!item.index) {
        return (
          <React.Fragment key={item.key}>
            <Route index element = { <Navigate to={item.key} replace = { true } />} />
            <Route path = { item.key } element = { item.element }>
              { renderRoute(item.children) }
            </Route>
          </React.Fragment>
        )
      } else {
        return (
          <Route key = { item.key } path = { item.key } element = { item.element }>
            { renderRoute(item.children) }
          </Route>
        )
      }
    } else {
      if (!!item.index) { // 如果index存在
        return (
          <React.Fragment key = { item.key }>
            <Route index element = { <Navigate to={item.key} replace = { true } />} />
            <Route path = { item.key } element = { item.element }></Route>
          </React.Fragment>
        )
      } else {
        return (
          <Route key = { item.key } path = { item.key } element = { item.element }></Route>
        )
      }
    }
  })
}

// 获取当前 需要展开的菜单项（可展开二级以及三级乃至更多展开项）
// pathname  /pro/list/cart
//  ===> ['/pro', '/pro/list', '/pro/list/cart']
export const getSubMenu = (pathname: string) => {
  // 1.以 / 分割 pathname.split('/')  //  ['', 'pro', 'list', 'cart']
  const pathArray = pathname.split('/').slice(1) // ['pro', 'list', 'cart']
  // console.log(pathArray)
  const result = pathArray.reduce((newArr, item, index) => {
    // '/pro'
    // '/pro/list'
    // 'pro/list/cart'
    const str = newArr[index] + '/' + item
    // ['', '/pro']
    // ['', '/pro', '/pro/list']
    // ['', '/pro', '/pro/list', '/pro/list/cart']
    newArr.push(str)
    return newArr
  }, [''])
  // console.log('result', result)
  return result
}

export interface ITabProps {
  label: string
  key: string
}
// 提取快捷切换页的数据
const tabsArr: ITabProps[] = []
export const getTabsData = (menus: IMenuProps[]) => {
  // const tabsArr: ITabProps[] = []
  menus.forEach(item => {
    if (item.children) {
      getTabsData(item.children)
    } else {
      tabsArr.push({
        label: item.label,
        key: item.key
      })
    }
  })
  return tabsArr
}

4.20.0以上写法

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
// src/layout/components/SideBar.tsx 左侧菜单栏
import React, { FC, useState, useEffect } from 'react';

import { Layout, Menu, Image, MenuProps } from 'antd';
import { useAppSelector } from '@/store/hook';
import menus from '@/router/menu'
import logo from '@/logo.svg'
import { getSubMenu } from '@/router/utils'
import { useLocation, useNavigate } from 'react-router-dom';

interface ISideBarProps {

};

const { Sider } = Layout;

// 设置只展开一个菜单项
const rootSubmenuKeys: string[] = [];
menus.forEach(item => {
  item.children && rootSubmenuKeys.push(item.key)
})

const SideBar:FC<ISideBarProps> = () => {
  const collapsed = useAppSelector(state => state.app.collapsed);
  // 获取当前路由的路径信息
  const { pathname } = useLocation()
  // 当前选中的菜单项key数组
  // 初始值设置为 [pathname],刷新进入选中某一个菜单项
  const [selectedKeys, setSelectedKeys] = useState([pathname])

  // const [openKeys, setOpenKeys] = useState<string[]>(['/pro', '/pro/list'])
  const [openKeys, setOpenKeys] = useState<string[]>(getSubMenu(pathname))

  // 展开哪一项数据
  // const [openKeys, setOpenKeys] = useState<string[]>([])
  // 打开一个菜单项时，需要做判断 - SubMenu 展开/关闭的回调
  const onOpenChange: MenuProps['onOpenChange'] = keys => {
    // 如果当前展开项是 轮播图管理，再点击 账户管理 ['/banner', '/account']
    // console.log('keys', keys) // ['/banner'] =>  ['/banner', '/account']
    // console.log('openKeys', openKeys) // [] => ['/banner']
    // 得到当前
    const latestOpenKey = keys.find(key => openKeys.indexOf(key) === -1);
    // console.log('latestOpenKey', latestOpenKey) // /banner ===> /account
    if (rootSubmenuKeys.indexOf(latestOpenKey!) === -1) {
      setOpenKeys(keys);
    } else {
      setOpenKeys(latestOpenKey ? [latestOpenKey] : []);
    }
  }

  // 点击切换路由
  const navigate = useNavigate()
  const changeUrl = ({ key }: { key: string }) => {
    // console.log(key)
    navigate(key, { replace: false })

    // 点击左侧菜单，切换菜单项，选中样式
    setSelectedKeys([key])
  }

  // 监听 pathname 的变化，然后调整左侧菜单打开和选中状态
  useEffect(() => {
    setSelectedKeys([pathname])
    setOpenKeys(getSubMenu(pathname))
  }, [pathname])

  return (
    <Sider trigger={null} collapsible collapsed={collapsed}>
      <div className="logo" style={ {
        display: 'flex',
        justifyContent: 'center',
        alignItems: 'center',
        color: '#fff'
      }}>
        <Image src = { logo } width="28px" height="28px" preview={ false }></Image>
        { !collapsed && <div style={{
          height: '32px',
          overflow: 'hidden',
          lineHeight: '32px'
        }}>嗨购后台管理系统</div> }
      </div>
      <Menu
        theme="dark"
        mode="inline"
        defaultSelectedKeys={['1']}
        openKeys = { openKeys } // 打开哪一个菜单项
        onOpenChange = { onOpenChange } // 打开某一个菜单项时需要关闭其他菜单项
        onClick = { changeUrl }
        selectedKeys = { selectedKeys }
        items = { menus }
      >
      </Menu>
    </Sider>
  )
};

export default SideBar;

隐藏子菜单使用 hidden 属性，如果使用的不是hidden属性，那么需要自行过滤数据

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
function getData (menus: IMenuProps[]) { // ++++++++++
	const items:IMenuProps[] = []
    menus.forEach(item => {
     if (item.children) {
       if (!item.hidden) {
         items.push({...item}) // 只提取二级菜单项中的第一层级
       }
     } else {
       if (!item.hidden) {
         items.push({...item}) // 一级菜单提取出来
       }
     }
    })

    items.forEach(item => { // 因为上面只提取了第一层级的数据
     if(item.children) {
       let a = getData(item.children)
       item.children = a
     }
    })
    return items
}

19. 管理员管理

19.1.设计接口

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
// src/api/admin.ts

import request from '@/utils/request'
export interface IAdminParams {
  adminname: string
  password: string
}
export interface IAdminAddParams {
  adminname: string
  token: string
  role: number
  checkedKeys: any[]
}

// 登录
export function adminLoginFn (params: IAdminParams) {
  return request({
    url: '/admin/login',
    method: 'POST',
    data: params
  })
}

export function getAdminList () {
  return request({
    url: '/admin/list'
  })
}

export function getAdminDetail (params: { adminname: string }) {
  return request({
    url: '/admin/detail',
    data: params
  })
}

export function addAdmin (params: IAdminAddParams) {
  return request({
    url: '/admin/add',
    data: params,
    method: 'POST'
  })
}

export function deleteAdmin (params: { adminid: string }) {
  return request({
    url: '/admin/delete',
    method: 'POST',
    data: params
  })
}

export function updateAdmin (params: IAdminAddParams) {
  return request({
    url: '/admin/update',
    method: 'POST',
    data: params
  })
}

19.2.展示管理员列表

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
// src/views/account/AdminList.tsx
import React, { FC, useEffect, useState } from 'react';
import { Table, Space, Button, Tag } from 'antd'
import {
  EditOutlined,
  DeleteOutlined
} from '@ant-design/icons'
import type { ColumnsType } from 'antd/es/table';
import { getAdminList } from '@/api/admin';
interface IIndexProps {
};
interface DataType {
  adminid: string
  adminname: string
  role: number
  checkedKeys: any[]
}

const Index:FC<IIndexProps> = () => {
  const [adminList, setAdminList] = useState<DataType[]>([])
  const getAdminListData = () => { // 获取列表数据
    getAdminList().then(res => {
      console.log(res.data)
      setAdminList(res.data.data)
    })
  }
  useEffect(() => {
    getAdminListData()
  }, [])

  const columns: ColumnsType<DataType> = [
    {
      title: '序号',
      render (_, record, index) {
        return (<span>{ index + 1 }</span>)
      }
    },
    {
      title: '账户',
      dataIndex: 'adminname'
    },
    {
      title: '角色',
      dataIndex: 'role',
      render: (text) => { // 第一个参数即为 role
        return text === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      }
      // render: (_, { role }) => { // 第一个参数即为 role 字段的值 第二个参数是当前对象
      //   return role === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      // }
    },
    {
      title: '操作',
      render (_, record, index) {
        return (
          <Space>
            <Button type='ghost'  shape="circle" icon={<EditOutlined />}></Button>
            <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
          </Space>
        )
      }
    }
  ]
  return (
    <Space style={{ width: '100%' }} direction="vertical">
      <Button type='primary'>添加管理员</Button>
      <Table
        columns={ columns }
        dataSource={ adminList }
        // rowKey = "adminid"
        rowKey = { (record) => record.adminid }
      ></Table>
    </Space>
  )
};

export default Index;

19.3 优化表格滚动

如果屏幕比较小，默认展示的都是10条数据，就容易超出固定容器大小，此时可以通过 限制表格的滚动属性解决问题

第三方hooks库 https://ahooks.js.org/zh-CN/

1
$ cnpm i ahooks -S

？？？？ ahooks的useSize获取到的是 undefined

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
// src/views/account/AdminList.tsx
import React, { FC, useEffect, useState } from 'react';
import { Table, Space, Button, Tag } from 'antd'
import {
  EditOutlined,
  DeleteOutlined
} from '@ant-design/icons'
import type { ColumnsType } from 'antd/es/table';
import { getAdminList } from '@/api/admin';
interface IIndexProps {
};
interface DataType {
  adminid: string
  adminname: string
  role: number
  checkedKeys: any[]
}

const Index:FC<IIndexProps> = () => {
  const [height] = useState(document.body.offsetHeight) // 计算body的高度

  const [adminList, setAdminList] = useState<DataType[]>([])
  const getAdminListData = () => { // 获取列表数据
    getAdminList().then(res => {
      console.log(res.data)
      setAdminList(res.data.data)
    })
  }
  useEffect(() => {
    getAdminListData()
  }, [])


  const columns: ColumnsType<DataType> = [
    {
      title: '序号',
      render (_, record, index) {
        return (<span>{ index + 1 }</span>)
      }
    },
    {
      title: '账户',
      dataIndex: 'adminname'
    },
    {
      title: '角色',
      dataIndex: 'role',
      render: (text) => { // 第一个参数即为 role
        return text === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      }
      // render: (_, { role }) => { // 第一个参数即为 role 字段的值 第二个参数是当前对象
      //   return role === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      // }
    },
    {
      title: '操作',
      render (_, record, index) {
        return (
          <Space>
            <Button type='ghost'  shape="circle" icon={<EditOutlined />}></Button>
            <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
          </Space>
        )
      }
    }
  ]
  return (
    <Space style={{ width: '100%' }} direction="vertical">
      <Button type='primary'>添加管理员</Button>
      <Table
        columns={ columns }
        dataSource={ adminList }
        // rowKey = "adminid"
        rowKey = { (record) => record.adminid }
        scroll = {{ y: height - 330 }}
      ></Table>
    </Space>
  )
};

export default Index;

19.4 优化表格的分页器

优化数据表格（分页器优化 - 序号-分页之后需要要连贯）

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
// src/views/account/AdminList.tsx
import React, { FC, useEffect, useState } from 'react';
import { Table, Space, Button, Tag } from 'antd'
import {
  EditOutlined,
  DeleteOutlined
} from '@ant-design/icons'
import type { ColumnsType } from 'antd/es/table';
import { getAdminList } from '@/api/admin';
interface IIndexProps {
};
interface DataType {
  adminid: string
  adminname: string
  role: number
  checkedKeys: any[]
}

const Index:FC<IIndexProps> = () => {
  // 分页设置 // +++++++
  const [current, setCurrent] = useState(1)
  const [pageSize, setPageSize] = useState(10)

  const [height] = useState(document.body.offsetHeight) // 计算body的高度

  const [adminList, setAdminList] = useState<DataType[]>([])
  const getAdminListData = () => { // 获取列表数据
    getAdminList().then(res => {
      console.log(res.data)
      setAdminList(res.data.data)
    })
  }
  useEffect(() => {
    getAdminListData()
  }, [])


  const columns: ColumnsType<DataType> = [
    {
      title: '序号',
      render (_, record, index) { // +++++++
        return (<span>{ (current - 1) * pageSize + index + 1 }</span>)
      }
    },
    {
      title: '账户',
      dataIndex: 'adminname'
    },
    {
      title: '角色',
      dataIndex: 'role',
      render: (text) => { // 第一个参数即为 role
        return text === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      }
      // render: (_, { role }) => { // 第一个参数即为 role 字段的值 第二个参数是当前对象
      //   return role === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      // }
    },
    {
      title: '操作',
      render (_, record, index) {
        return (
          <Space>
            <Button type='ghost'  shape="circle" icon={<EditOutlined />}></Button>
            <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
          </Space>
        )
      }
    }
  ]
  return (
    <Space style={{ width: '100%' }} direction="vertical">
      <Button type='primary'>添加管理员</Button>
      <Table
        columns={ columns }
        dataSource={ adminList }
        // rowKey = "adminid"
        rowKey = { (record) => record.adminid }
        scroll = {{ y: height - 330 }}
        pagination = {{ // +++++++
          position: ['bottomRight'],
          current: current,
          pageSize: pageSize,
          showSizeChanger: true,
          pageSizeOptions: [5, 10, 50, 200],
          showQuickJumper: true,
          showTotal: (total) => {
            return (<span>共有{total}条数据</span>)
          },
          onChange: (page, pageSize) => {
            setCurrent(page)
            setPageSize(pageSize)
          }
        }}
      ></Table>
    </Space>
  )
};

export default Index;

19.5 添加中文包

由于 antd 组件的默认文案是英文，所以需要修改为中文

image-20221026163808513

https://ant-design.gitee.io/docs/react/getting-started-cn

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
// src/index.js
import React from 'react';
import ReactDOM from 'react-dom/client';
import { Provider } from 'react-redux';
import store from '@/store'
import '@/index.less';
import App from '@/App';
import reportWebVitals from '@/reportWebVitals';
import { BrowserRouter } from 'react-router-dom'

import { ConfigProvider } from 'antd'; // ++++++++
// 由于 antd 组件的默认文案是英文，所以需要修改为中文
import zhCN from 'antd/es/locale/zh_CN';// ++++++++

const root = ReactDOM.createRoot(
  document.getElementById('root') as HTMLDivElement
);
root.render(
  <React.StrictMode>
    <Provider store = { store }>
      <BrowserRouter >
        { /*++++++++++*/}
        <ConfigProvider locale={zhCN}>
          <App />
        </ConfigProvider>
      </BrowserRouter>
    </Provider>
  </React.StrictMode>
);

reportWebVitals();

19.6 抽离分页器

可以抽离，但不是必须

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
// src/hooks/usePagination.tsx
import { JSXElementConstructor, ReactElement, ReactFragment, ReactPortal, SetStateAction, useState } from 'react'
export default function usePagination(config: any) {
  let { position, showSizeChanger, pageSizeOptions, showQuickJumper } =  config
  const [current, setCurrent] = useState(1)
  const [pageSize, setPageSize] = useState(10)
  const onChange = (page: SetStateAction<number>, pageSize: SetStateAction<number>) => {
    setCurrent(page)
    setPageSize(pageSize)
  }
  const showTotal =  (total: string | number | boolean | ReactElement<any, string | JSXElementConstructor<any>> | ReactFragment | ReactPortal | null | undefined) => {
    return (<span>共有{total}条数据</span>)
  }
  return {
    position,
    current,
    pageSize,
    showSizeChanger,
    pageSizeOptions,
    showQuickJumper,
    showTotal,
    onChange
  }
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
// src/views/account/AdminList.tsx
import React, { FC, useEffect, useState } from 'react';
import { Table, Space, Button, Tag } from 'antd'
import {
  EditOutlined,
  DeleteOutlined
} from '@ant-design/icons'
import type { ColumnsType } from 'antd/es/table';
import { getAdminList } from '@/api/admin';
import usePagination from '@/hooks/usePagination';
interface IIndexProps {
};
interface DataType {
  adminid: string
  adminname: string
  role: number
  checkedKeys: any[]
}

const Index:FC<IIndexProps> = () => {
  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [1, 2, 3, 4],
    showQuickJumper: true
  })

  const [height] = useState(document.body.offsetHeight) // 计算body的高度

  const [adminList, setAdminList] = useState<DataType[]>([])
  const getAdminListData = () => { // 获取列表数据
    getAdminList().then(res => {
      console.log(res.data)
      setAdminList(res.data.data)
    })
  }
  useEffect(() => {
    getAdminListData()
  }, [])


  const columns: ColumnsType<DataType> = [
    {
      title: '序号',
      render (_, record, index) {
        return (<span>{ (config.current - 1) * config.pageSize + index + 1 }</span>)
      }
    },
    {
      title: '账户',
      dataIndex: 'adminname'
    },
    {
      title: '角色',
      dataIndex: 'role',
      render: (text) => { // 第一个参数即为 role
        return text === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      }
      // render: (_, { role }) => { // 第一个参数即为 role 字段的值 第二个参数是当前对象
      //   return role === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      // }
    },
    {
      title: '操作',
      render (_, record, index) {
        return (
          <Space>
            <Button type='ghost'  shape="circle" icon={<EditOutlined />}></Button>
            <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
          </Space>
        )
      }
    }
  ]
  return (
    <Space style={{ width: '100%' }} direction="vertical">
      <Button type='primary'>添加管理员</Button>
      <Table
        columns={ columns }
        dataSource={ adminList }
        // rowKey = "adminid"
        rowKey = { (record) => record.adminid }
        scroll = {{ y: height - 330 }}
        pagination = { config }
      ></Table>
    </Space>
  )
};

export default Index;

19.7删除管理员

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
// src/views/account/AdminList.tsx
import React, { FC, useEffect, useState } from 'react';
import { Table, Space, Button, Tag, Popconfirm } from 'antd'
import {
  EditOutlined,
  DeleteOutlined
} from '@ant-design/icons'
import type { ColumnsType } from 'antd/es/table';
import { deleteAdmin, getAdminList } from '@/api/admin';
import usePagination from '@/hooks/usePagination';
interface IIndexProps {
};
interface DataType {
  adminid: string
  adminname: string
  role: number
  checkedKeys: any[]
}

const Index:FC<IIndexProps> = () => {
  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [1, 2, 3, 4],
    showQuickJumper: true
  })

  const [height] = useState(document.body.offsetHeight) // 计算body的高度

  const [adminList, setAdminList] = useState<DataType[]>([])
  const getAdminListData = () => { // 获取列表数据
    getAdminList().then(res => {
      console.log(res.data)
      setAdminList(res.data.data)
    })
  }
  useEffect(() => {
    getAdminListData()
  }, [])


  const columns: ColumnsType<DataType> = [
    {
      title: '序号',
      render (_, record, index) {
        return (<span>{ (config.current - 1) * config.pageSize + index + 1 }</span>)
      }
    },
    {
      title: '账户',
      dataIndex: 'adminname'
    },
    {
      title: '角色',
      dataIndex: 'role',
      render: (text) => { // 第一个参数即为 role
        return text === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      }
      // render: (_, { role }) => { // 第一个参数即为 role 字段的值 第二个参数是当前对象
      //   return role === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      // }
    },
    {
      title: '操作',
      render (_, record, index) {
        return (
          <Space>
            <Button type='ghost'  shape="circle" icon={<EditOutlined />}></Button>
           {/* +++++++++++++ */}
            <Popconfirm title="确定删除吗?" onConfirm={ () => {
              deleteAdmin({ adminid: record.adminid}).then(() => {
                // 删除完毕重新获取数据
                getAdminListData()
              })
            }} onOpenChange={() => console.log('open change')}>
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
            </Popconfirm>
          </Space>
        )
      }
    }
  ]
  return (
    <Space style={{ width: '100%' }} direction="vertical">
      <Button type='primary'>添加管理员</Button>
      <Table
        columns={ columns }
        dataSource={ adminList }
        // rowKey = "adminid"
        rowKey = { (record) => record.adminid }
        scroll = {{ y: height - 330 }}
        pagination = { config }
      ></Table>
    </Space>
  )
};

export default Index;

19.8 如何批量删除管理员数据

https://ant-design.gitee.io/components/table-cn/#components-table-demo-row-selection-custom

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
// src/views/account/AdminList.tsx
import React, { FC, useEffect, useState, useMemo } from 'react';
import { Table, Space, Button, Tag, Popconfirm } from 'antd'
import {
  EditOutlined,
  DeleteOutlined
} from '@ant-design/icons'
import type { ColumnsType } from 'antd/es/table';
import type { TableRowSelection } from 'antd/es/table/interface';
import { deleteAdmin, getAdminList } from '@/api/admin';
import usePagination from '@/hooks/usePagination';
interface IIndexProps {
};
interface DataType {
  adminid: string
  adminname: string
  role: number
  checkedKeys: any[]
}

const Index:FC<IIndexProps> = () => {
  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [1, 2, 3, 4],
    showQuickJumper: true
  })

  const [height] = useState(document.body.offsetHeight) // 计算body的高度

  const [adminList, setAdminList] = useState<DataType[]>([])
  const getAdminListData = () => { // 获取列表数据
    getAdminList().then(res => {
      console.log(res.data)
      setAdminList(res.data.data)
    })
  }
  useEffect(() => {
    getAdminListData()
  }, [])


  const columns: ColumnsType<DataType> = [
    {
      title: '序号',
      render (_, record, index) {
        return (<span>{ (config.current - 1) * config.pageSize + index + 1 }</span>)
      }
    },
    {
      title: '账户',
      dataIndex: 'adminname'
    },
    {
      title: '角色',
      dataIndex: 'role',
      render: (text) => { // 第一个参数即为 role
        return text === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      }
      // render: (_, { role }) => { // 第一个参数即为 role 字段的值 第二个参数是当前对象
      //   return role === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      // }
    },
    {
      title: '操作',
      render (_, record, index) {
        return (
          <Space>
            <Button type='ghost'  shape="circle" icon={<EditOutlined />}></Button>
            <Popconfirm title="确定删除吗?" onConfirm={ () => {
              deleteAdmin({ adminid: record.adminid}).then(() => {
                // 删除完毕重新获取数据
                getAdminListData()
              })
            }} onOpenChange={() => console.log('open change')}>
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
            </Popconfirm>
          </Space>
        )
      }
    }
  ]

  // 自定义选择 selectedRowKeys 批量删除的数据
  const [selectedRowKeys, setSelectedRowKeys] = useState<React.Key[]>([]);

  const onSelectChange = (newSelectedRowKeys: React.Key[]) => {
    console.log('selectedRowKeys changed: ', newSelectedRowKeys);
    setSelectedRowKeys(newSelectedRowKeys);
  };
  const rowSelection: TableRowSelection<DataType> = {
    selectedRowKeys,
    onChange: onSelectChange,
  }

  const flag = useMemo(() => {
    return selectedRowKeys.length > 0
  }, [selectedRowKeys])
  return (
    <Space style={{ width: '100%' }} direction="vertical">
      <Space>
        <Button type='primary'>添加管理员</Button>
        { flag && <Button type='primary' onClick={ () => { // ++++++++++
          // 思考： 还用气泡弹出框？ 自行选择删除的方案
          // 接口没有提供批量删除，只能使用单个删除解决
          // 每个删除都是基于 Promise， 综合考虑 Promise.all
          const arr: any = []
          selectedRowKeys.forEach((item: any) => {
            arr.push(deleteAdmin({ adminid: item}))
          })
          Promise.all(arr).then(() => {
            getAdminListData()
          })
        }}>批量删除</Button> }
      </Space>
      <Table
        columns={ columns }
        dataSource={ adminList }
        // rowKey = "adminid"
        rowKey = { (record) => record.adminid }
        scroll = {{ y: height - 330 }}
        pagination = { config }
        rowSelection={rowSelection}
      ></Table>
    </Space>
  )
};

export default Index;

19.9.添加管理员

19.9.1 设置添加管理员的抽屉效果（无树形控件）

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
// src/views/account/AdminList.tsx
import React, { FC, useEffect, useState, useMemo } from 'react';
import { Table, Space, Button, Tag, Popconfirm, Drawer, Input, Select } from 'antd'
import {
  EditOutlined,
  DeleteOutlined
} from '@ant-design/icons'
import type { ColumnsType } from 'antd/es/table';
import type { TableRowSelection } from 'antd/es/table/interface';
import { deleteAdmin, getAdminList } from '@/api/admin';
import usePagination from '@/hooks/usePagination';
interface IIndexProps {
};
interface DataType {
  adminid: string
  adminname: string
  role: number
  checkedKeys: any[]
}

const Index:FC<IIndexProps> = () => {
  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [1, 2, 3, 4],
    showQuickJumper: true
  })

  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])


  const [adminList, setAdminList] = useState<DataType[]>([])
  const getAdminListData = () => { // 获取列表数据
    console.log(66)
    getAdminList().then(res => {
      console.log(res.data)
      setAdminList(res.data.data)
    })
  }
  useEffect(() => {
    getAdminListData()
  }, [])


  const columns: ColumnsType<DataType> = [
    {
      title: '序号',
      render (_, record, index) {
        return (<span>{ (config.current - 1) * config.pageSize + index + 1 }</span>)
      }
    },
    {
      title: '账户',
      dataIndex: 'adminname'
    },
    {
      title: '角色',
      dataIndex: 'role',
      render: (text) => { // 第一个参数即为 role
        return text === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      }
      // render: (_, { role }) => { // 第一个参数即为 role 字段的值 第二个参数是当前对象
      //   return role === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      // }
    },
    {
      title: '操作',
      render (_, record, index) {
        return (
          <Space>
            <Button type='ghost'  shape="circle" icon={<EditOutlined />}></Button>
            <Popconfirm title="确定删除吗?" onConfirm={ () => {
              deleteAdmin({ adminid: record.adminid}).then(() => {
                // 删除完毕重新获取数据
                getAdminListData()
              })
            }} onOpenChange={() => console.log('open change')}>
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
            </Popconfirm>
          </Space>
        )
      }
    }
  ]

  // 自定义选择 selectedRowKeys 批量删除的数据
  const [selectedRowKeys, setSelectedRowKeys] = useState<React.Key[]>([]);

  const onSelectChange = (newSelectedRowKeys: React.Key[]) => {
    console.log('selectedRowKeys changed: ', newSelectedRowKeys);
    setSelectedRowKeys(newSelectedRowKeys);
  };
  const rowSelection: TableRowSelection<DataType> = {
    selectedRowKeys,
    onChange: onSelectChange,
  }

  const flag = useMemo(() => {
    return selectedRowKeys.length > 0
  }, [selectedRowKeys])


  // 抽屉效果 用来添加管理员
  const [open, setOpen] = useState(false);

  return (
    <Space style={{ width: '100%' }} direction="vertical" >
      <Space>
        <Button type='primary' onClick={ () => setOpen(true) }>添加管理员</Button>
        { flag && <Button type='primary' onClick={ () => {
          // 思考： 还用气泡弹出框？ 自行选择删除的方案
          // 接口没有提供批量删除，只能使用单个删除解决
          // 每个删除都是基于 Promise， 综合考虑 Promise.all
          const arr: any = []
          selectedRowKeys.forEach((item: any) => {
            arr.push(deleteAdmin({ adminid: item}))
          })
          Promise.all(arr).then(() => {
            getAdminListData()
          })
        }}>批量删除</Button> }
      </Space>
      <Table
        columns={ columns }
        dataSource={ adminList }
        // rowKey = "adminid"
        rowKey = { (record) => record.adminid }
        scroll = {{ y: height - 330 }}
        pagination = { config }
        rowSelection={rowSelection}
      ></Table>
      <Drawer title="添加管理员" placement="right" onClose={() => {
        setOpen(false)
      }} open={open}>
        <Space direction='vertical' style={{ display: 'flex' }}>
          <Input placeholder='账户名' />
          <Input placeholder='密码' />
          <Select defaultValue={ 1 } style={{ width: '100%'}}>
            <Select.Option value={1}>管理员</Select.Option>
            <Select.Option value={2}>超级管理员</Select.Option>
          </Select>
          选择该管理员的权限：

        </Space>
      </Drawer>
    </Space>
  )
};

export default Index;

19.9.2 修改菜单数据 添加了keyid字段

1
2
3
4
5
6
7
8
9
10
11
12
13
14
// src/router/inter.d.ts
import { ReactNode } from 'react'

// key属性可以使用 左侧菜单的路由地址，因为它具有唯一性
export interface IMenuProps {
  label: string
  key: string
  keyid: string
  icon?: ReactNode
  children?: IMenuProps[]
  element: ReactNode // 因为页面创建时 指定了多级了路由的页面，故这里设置为 必传属性
  index?: 1 | 0 // 不建议使用 boolean，因为react在渲染属性时，具有boolean值的属性会有特殊的含义
  hidden?: 1 | 0 // 宁用 hidden 为 真 不用 show 为假
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
// src/router/menu.tsx
import { IMenuProps } from './inter'
import {
  HomeOutlined,
  UploadOutlined,
  PictureOutlined,
  ProfileOutlined,
  OrderedListOutlined,
  FilterOutlined,
  TeamOutlined,
  UserOutlined,
  SettingOutlined
} from '@ant-design/icons'

import Home from '@/views/home/Index'

import Banner from '@/views/banner/Index'
import BannerList from '@/views/banner/List'
import BannerActive from '@/views/banner/Active'
import BannerAdd from '@/views/banner/Add'

import Product from '@/views/product/Index'
import ProductSearch from '@/views/product/Search'
import ProductList from '@/views/product/list/Index'
import ProductHomeList from '@/views/product/list/Home'
import ProductDetailList from '@/views/product/list/Detail'
import ProductCartList from '@/views/product/list/Cart'

import Account from '@/views/account/Index'
import UserList from '@/views/account/UserList'
import AdminList from '@/views/account/AdminList'

import Setting from '@/views/setting/Index'

const menus: IMenuProps[] = [
  {
    label: '系统首页',
    key: '/',
    keyid: '0-0',
    icon: <HomeOutlined />,
    element: <Home />
  },
  {
    label: '轮播图管理',
    key: '/banner',
    keyid: '0-1',
    icon: <UploadOutlined />,
    element: <Banner />,
    children: [
      {
        label: '首页轮播图',
        key: '/banner/home',
        keyid: '0-1-0',
        icon: <PictureOutlined />,
        element: <BannerList />,
        index: 1
      },
      {
        label: '活动页轮播图',
        key: '/banner/active',
        keyid: '0-1-1',
        icon: <PictureOutlined />,
        element: <BannerActive />
      },
      {
        label: '添加轮播图',
        key: '/banner/add',
        keyid: '0-1-2',
        icon: <UploadOutlined />,
        element: <BannerAdd />,
        hidden: 1
      },
    ]
  },
  {
    label: '产品管理',
    key: '/pro',
    keyid: '0-2',
    icon: <ProfileOutlined />,
    element: <Product />,
    children: [
      {
        label: '产品列表',
        key: '/pro/list',
        keyid: '0-2-0',
        icon: <OrderedListOutlined />,
        element: <ProductList />,
        index: 1,
        children: [
          {
            label: '首页产品列表',
            key: '/pro/list/home',
            keyid: '0-2-0-0',
            element: <ProductHomeList />,
            index: 1
          },
          {
            label: '详情推荐列表',
            key: '/pro/list/detail',
            keyid: '0-2-0-1',
            element: <ProductDetailList />
          },
          {
            label: '购物车推荐列表',
            key: '/pro/list/cart',
            keyid: '0-2-0-2',
            element: <ProductCartList />
          },
        ]
      },
      {
        label: '筛选列表',
        key: '/pro/search',
        keyid: '0-2-1',
        icon: <FilterOutlined />,
        element: <ProductSearch />
      },
    ]
  },
  {
    label: '账户管理',
    key: '/account',
    keyid: '0-3',
    icon: <TeamOutlined />,
    element: <Account />,
    children: [
      {
        label: '用户列表',
        key: '/account/userlist',
        keyid: '0-3-1',
        icon: <UserOutlined />,
        element: <UserList />,
        index: 1
      },
      {
        label: '管理员列表',
        key: '/account/adminlist',
        keyid: '0-3-2',
        icon: <UserOutlined />,
        element: <AdminList />
      }
    ]
  },
  {
    label: '设置',
    key: '/setting',
    keyid: '0-4',
    icon: <SettingOutlined />,
    element: <Setting />,
    hidden: 1
  }
]


export default menus

19.9.3 添加管理员时选择该管理员权限

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
// src/router/utils.tsx
import type { DataNode } from 'antd/es/tree';
// .....
export function getTreeData (menus: IMenuProps[]) {
  const arr: DataNode[] = []
  menus.forEach(item => {
    let obj: DataNode = {
      key: '',
      title: ''
    }
    if (item.children) {
      obj = {
        key: item.keyid,
        title: item.label,
        children: getTreeData(item.children)
      }
    } else {
      obj = {
        key: item.keyid,
        title: item.label
      }
    }
    arr.push(obj)
  })
  return arr
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
// src/views/account/AdminList.tsx
import React, { FC, useEffect, useState, useMemo } from 'react';
import { Table, Space, Button, Tag, Popconfirm, Drawer, Input, Select, Tree } from 'antd'
import {
  EditOutlined,
  DeleteOutlined
} from '@ant-design/icons'
import type { ColumnsType } from 'antd/es/table';
import type { TableRowSelection } from 'antd/es/table/interface';
import type { DataNode } from 'antd/es/tree';
import { addAdmin, deleteAdmin, getAdminList } from '@/api/admin';
import usePagination from '@/hooks/usePagination';
import menus from '@/router/menu';
import { getTreeData } from '@/router/utils';
interface IIndexProps {
};
interface DataType {
  adminid: string
  adminname: string
  role: number
  checkedKeys: any[]
}

const Index:FC<IIndexProps> = () => {
  // 树形控件
  const treeData: DataNode[] = getTreeData(menus)

  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [1, 2, 3, 4],
    showQuickJumper: true
  })

  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])


  const [adminList, setAdminList] = useState<DataType[]>([])
  const getAdminListData = () => { // 获取列表数据
    console.log(66)
    getAdminList().then(res => {
      console.log(res.data)
      setAdminList(res.data.data)
    })
  }
  useEffect(() => {
    getAdminListData()
  }, [])


  const columns: ColumnsType<DataType> = [
    {
      title: '序号',
      render (_, record, index) {
        return (<span>{ (config.current - 1) * config.pageSize + index + 1 }</span>)
      }
    },
    {
      title: '账户',
      dataIndex: 'adminname'
    },
    {
      title: '角色',
      dataIndex: 'role',
      render: (text) => { // 第一个参数即为 role
        return text === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      }
      // render: (_, { role }) => { // 第一个参数即为 role 字段的值 第二个参数是当前对象
      //   return role === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      // }
    },
    {
      title: '操作',
      render (_, record, index) {
        return (
          <Space>
            <Button type='ghost'  shape="circle" icon={<EditOutlined />}></Button>
            <Popconfirm title="确定删除吗?" onConfirm={ () => {
              deleteAdmin({ adminid: record.adminid}).then(() => {
                // 删除完毕重新获取数据
                getAdminListData()
              })
            }} onOpenChange={() => console.log('open change')}>
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
            </Popconfirm>
          </Space>
        )
      }
    }
  ]

  // 自定义选择 selectedRowKeys 批量删除的数据
  const [selectedRowKeys, setSelectedRowKeys] = useState<React.Key[]>([]);

  const onSelectChange = (newSelectedRowKeys: React.Key[]) => {
    console.log('selectedRowKeys changed: ', newSelectedRowKeys);
    setSelectedRowKeys(newSelectedRowKeys);
  };
  const rowSelection: TableRowSelection<DataType> = {
    selectedRowKeys,
    onChange: onSelectChange,
  }

  const flag = useMemo(() => {
    return selectedRowKeys.length > 0
  }, [selectedRowKeys])


  // 抽屉效果 用来添加管理员
  const [adminname, setAdminname] = useState('')
  const [password, setPassword] = useState('')
  const [role, setRole] = useState(1)
  const [open, setOpen] = useState(false);
  // 树形控件
  const [checkedKeys, setcheckedKeys] = useState(['0-0'])

  const onAdd = () => {
    const result: any = {
      adminname, password, role, checkedKeys
    }

    console.log(result)
  }
  return (
    <Space style={{ width: '100%' }} direction="vertical" >
      <Space>
        <Button type='primary' onClick={ () => setOpen(true) }>添加管理员</Button>
        { flag && <Button type='primary' onClick={ () => {
          // 思考： 还用气泡弹出框？ 自行选择删除的方案
          // 接口没有提供批量删除，只能使用单个删除解决
          // 每个删除都是基于 Promise， 综合考虑 Promise.all
          const arr: any = []
          selectedRowKeys.forEach((item: any) => {
            arr.push(deleteAdmin({ adminid: item}))
          })
          Promise.all(arr).then(() => {
            getAdminListData()
          })
        }}>批量删除</Button> }
      </Space>
      <Table
        columns={ columns }
        dataSource={ adminList }
        // rowKey = "adminid"
        rowKey = { (record) => record.adminid }
        scroll = {{ y: height - 330 }}
        pagination = { config }
        rowSelection={rowSelection}
      ></Table>
      <Drawer title="添加管理员" placement="right" onClose={() => {
        setOpen(false)
      }} open={open}>
        <Space direction='vertical' style={{ display: 'flex' }}>
          <Input placeholder='账户名' value = { adminname } onChange = { e => setAdminname(e.target.value) } />
          <Input placeholder='密码' value = { password } onChange = { e => setPassword(e.target.value) } />
          <Select defaultValue={ 1 } style={{ width: '100%'}} value = { role } onChange = { (value) => setRole(value)}>
            <Select.Option value={1}>管理员</Select.Option>
            <Select.Option value={2}>超级管理员</Select.Option>
          </Select>
          选择该管理员的权限：
          <Tree
            checkable
            checkedKeys = { checkedKeys }
            onCheck = { (checkedKeys: any) => {
              setcheckedKeys(checkedKeys)
            }}
            treeData={ treeData }
          />
          <Button type="primary" onClick={ onAdd }>添加管理员</Button>
        </Space>
      </Drawer>
    </Space>
  )
};

export default Index;

19.9.4 添加管理员

添加完毕一定要记得重置（表单，权限）

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
// src/views/account/AdminList.tsx
import React, { FC, useEffect, useState, useMemo } from 'react';
import { Table, Space, Button, Tag, Popconfirm, Drawer, Input, Select, Tree, message } from 'antd'
import {
  EditOutlined,
  DeleteOutlined
} from '@ant-design/icons'
import type { ColumnsType } from 'antd/es/table';
import type { TableRowSelection } from 'antd/es/table/interface';
import type { DataNode } from 'antd/es/tree';
import { addAdmin, deleteAdmin, getAdminList } from '@/api/admin';
import usePagination from '@/hooks/usePagination';
import menus from '@/router/menu';
import { getTreeData } from '@/router/utils';
interface IIndexProps {
};
interface DataType {
  adminid: string
  adminname: string
  role: number
  checkedKeys: any[]
}

const Index:FC<IIndexProps> = () => {
  // 树形控件
  const treeData: DataNode[] = getTreeData(menus)

  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [1, 2, 3, 4],
    showQuickJumper: true
  })

  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])


  const [adminList, setAdminList] = useState<DataType[]>([])
  const getAdminListData = () => { // 获取列表数据
    // console.log(66)
    getAdminList().then(res => {
      // console.log(res.data)
      setAdminList(res.data.data)
    })
  }
  useEffect(() => {
    getAdminListData()
  }, [])


  const columns: ColumnsType<DataType> = [
    {
      title: '序号',
      render (_, record, index) {
        return (<span>{ (config.current - 1) * config.pageSize + index + 1 }</span>)
      }
    },
    {
      title: '账户',
      dataIndex: 'adminname'
    },
    {
      title: '角色',
      dataIndex: 'role',
      render: (text) => { // 第一个参数即为 role
        return text === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      }
      // render: (_, { role }) => { // 第一个参数即为 role 字段的值 第二个参数是当前对象
      //   return role === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      // }
    },
    {
      title: '操作',
      render (_, record, index) {
        return (
          <Space>
            <Button type='ghost'  shape="circle" icon={<EditOutlined />}></Button>
            <Popconfirm title="确定删除吗?" onConfirm={ () => {
              deleteAdmin({ adminid: record.adminid}).then(() => {
                // 删除完毕重新获取数据
                getAdminListData()
              })
            }} onOpenChange={() => console.log('open change')}>
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
            </Popconfirm>
          </Space>
        )
      }
    }
  ]

  // 自定义选择 selectedRowKeys 批量删除的数据
  const [selectedRowKeys, setSelectedRowKeys] = useState<React.Key[]>([]);

  const onSelectChange = (newSelectedRowKeys: React.Key[]) => {
    console.log('selectedRowKeys changed: ', newSelectedRowKeys);
    setSelectedRowKeys(newSelectedRowKeys);
  };
  const rowSelection: TableRowSelection<DataType> = {
    selectedRowKeys,
    onChange: onSelectChange,
  }

  const flag = useMemo(() => {
    return selectedRowKeys.length > 0
  }, [selectedRowKeys])


  // 抽屉效果 用来添加管理员
  const [open, setOpen] = useState(false);
  const [adminname, setAdminname] = useState('')
  const [password, setPassword] = useState('')
  const [role, setRole] = useState(1)
  // 树形控件
  const [checkedKeys, setcheckedKeys] = useState(['0-0'])

  const onAdd = () => {
    const result: any = {
      adminname, password, role, checkedKeys
    }
    addAdmin(result).then((res) => {
      console.log(res.data)
      if (res.data.code === '10004') {
        message.warning('该管理员账户已存在')
      } else if (res.data.code === '10008') {
        message.warning('账户名不符合规则')
      } else {
        message.success('添加成功')
        getAdminListData()
        setAdminname('')
        setPassword('')
        setRole(1)
        setcheckedKeys(['0-0'])
        setOpen(false)
      }

    })
    // console.log(result)
  }

  const dis = useMemo(() => {
    return adminname === '' || password === ''
  }, [adminname, password])
  return (
    <Space style={{ width: '100%' }} direction="vertical" >
      <Space>
        <Button type='primary' onClick={ () => setOpen(true) }>添加管理员</Button>
        { flag && <Button type='primary' onClick={ () => {
          // 思考： 还用气泡弹出框？ 自行选择删除的方案
          // 接口没有提供批量删除，只能使用单个删除解决
          // 每个删除都是基于 Promise， 综合考虑 Promise.all
          const arr: any = []
          selectedRowKeys.forEach((item: any) => {
            arr.push(deleteAdmin({ adminid: item}))
          })
          Promise.all(arr).then(() => {
            getAdminListData()
          })
        }}>批量删除</Button> }
      </Space>
      <Table
        columns={ columns }
        dataSource={ adminList }
        // rowKey = "adminid"
        rowKey = { (record) => record.adminid }
        scroll = {{ y: height - 330 }}
        pagination = { config }
        rowSelection={rowSelection}
      ></Table>
      <Drawer title="添加管理员" placement="right" onClose={() => {
        setOpen(false)
      }} open={open}>
        <Space direction='vertical' style={{ display: 'flex' }}>
          <Input placeholder='账户名' value = { adminname } onChange = { e => setAdminname(e.target.value) } />
          <Input placeholder='密码' value = { password } onChange = { e => setPassword(e.target.value) } />
          <Select defaultValue={ 1 } style={{ width: '100%'}} value = { role } onChange = { (value) => setRole(value)}>
            <Select.Option value={1}>管理员</Select.Option>
            <Select.Option value={2}>超级管理员</Select.Option>
          </Select>
          选择该管理员的权限：
          <Tree
            checkable
            checkedKeys = { checkedKeys }
            onCheck = { (checkedKeys: any) => {
              setcheckedKeys(checkedKeys)
            }}
            treeData={ treeData }
          />
          <Button type="primary" onClick={ onAdd } disabled = { dis }>添加管理员</Button>
        </Space>
      </Drawer>
    </Space>
  )
};

export default Index;

19.10管理员修改

修改不重新生成新的页面，还在这个页面，使用模态框实现

可以使用之前的数据字段 —- 需要注意 树形控件的字段 为 checkedKeys 而不是 checkedkeys

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
// src/views/account/AdminList.tsx
import React, { FC, useEffect, useState, useMemo } from 'react';
import { Table, Space, Button, Tag, Popconfirm, Drawer, Input, Select, Tree, message, Modal } from 'antd'
import {
  EditOutlined,
  DeleteOutlined
} from '@ant-design/icons'
import type { ColumnsType } from 'antd/es/table';
import type { TableRowSelection } from 'antd/es/table/interface';
import type { DataNode } from 'antd/es/tree';
import { addAdmin, deleteAdmin, getAdminList, updateAdmin } from '@/api/admin';
import usePagination from '@/hooks/usePagination';
import menus from '@/router/menu';
import { getTreeData } from '@/router/utils';
interface IIndexProps {
};
interface DataType {
  adminid: string
  adminname: string
  role: number
  checkedKeys: any[]
}

const Index:FC<IIndexProps> = () => {
  // 树形控件
  const treeData: DataNode[] = getTreeData(menus)

  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [1, 2, 3, 4],
    showQuickJumper: true
  })

  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])


  const [adminList, setAdminList] = useState<DataType[]>([])
  const getAdminListData = () => { // 获取列表数据
    // console.log(66)
    getAdminList().then(res => {
      console.log(res.data)
      setAdminList(res.data.data)
    })
  }
  useEffect(() => {
    getAdminListData()
  }, [])


  const columns: ColumnsType<DataType> = [
    {
      title: '序号',
      render (_, record, index) {
        return (<span>{ (config.current - 1) * config.pageSize + index + 1 }</span>)
      }
    },
    {
      title: '账户',
      dataIndex: 'adminname'
    },
    {
      title: '角色',
      dataIndex: 'role',
      render: (text) => { // 第一个参数即为 role
        return text === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      }
      // render: (_, { role }) => { // 第一个参数即为 role 字段的值 第二个参数是当前对象
      //   return role === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      // }
    },
    {
      title: '操作',
      render (_, record, index) {
        return (
          <Space>
            <Button type='ghost'  shape="circle" icon={<EditOutlined />} onClick = {() => {
              // 给表单填充数据
              setAdminname(record.adminname)
              setRole(record.role)
              setCheckedkeys(record.checkedKeys)
              // 弹出框显示
              setIsModalOpen(true)
            }}></Button>
            <Popconfirm title="确定删除吗?" onConfirm={ () => {
              deleteAdmin({ adminid: record.adminid}).then(() => {
                // 删除完毕重新获取数据
                getAdminListData()
              })
            }} onOpenChange={() => console.log('open change')}>
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
            </Popconfirm>
          </Space>
        )
      }
    }
  ]

  // 自定义选择 selectedRowKeys 批量删除的数据
  const [selectedRowKeys, setSelectedRowKeys] = useState<React.Key[]>([]);

  const onSelectChange = (newSelectedRowKeys: React.Key[]) => {
    console.log('selectedRowKeys changed: ', newSelectedRowKeys);
    setSelectedRowKeys(newSelectedRowKeys);
  };
  const rowSelection: TableRowSelection<DataType> = {
    selectedRowKeys,
    onChange: onSelectChange,
  }

  const flag = useMemo(() => {
    return selectedRowKeys.length > 0
  }, [selectedRowKeys])


  // 抽屉效果 用来添加管理员
  const [open, setOpen] = useState(false);
  const [adminname, setAdminname] = useState('')
  const [password, setPassword] = useState('')
  const [role, setRole] = useState(1)
  // 树形控件
  const [checkedKeys, setCheckedkeys] = useState(['0-0'])

  const onAdd = () => {
    const result: any = {
      adminname, password, role, checkedKeys: checkedKeys
    }
    addAdmin(result).then((res) => {
      console.log(res.data)
      if (res.data.code === '10004') {
        message.warning('该管理员账户已存在')
      } else if (res.data.code === '10008') {
        message.warning('账户名不符合规则')
      } else {
        message.success('添加成功')
        getAdminListData()
        setAdminname('')
        setPassword('')
        setRole(1)
        setCheckedkeys(['0-0'])
        setOpen(false)
      }

    })
    console.log(result)
  }

  const dis = useMemo(() => {
    return adminname === '' || password === ''
  }, [adminname, password])


  // 编辑
  const [isModalOpen, setIsModalOpen] = useState(false);
  const onUpdate = () => {
    const result: any = {
      adminname, role, checkedKeys
    }
    updateAdmin(result).then(() => {
      setIsModalOpen(false)
      setAdminname('')
      setRole(1)
      setCheckedkeys(['0-0'])
      getAdminListData()
    })
  }
  return (
    <Space style={{ width: '100%' }} direction="vertical" >
      <Space>
        <Button type='primary' onClick={ () => setOpen(true) }>添加管理员</Button>
        { flag && <Button type='primary' onClick={ () => {
          // 思考： 还用气泡弹出框？ 自行选择删除的方案
          // 接口没有提供批量删除，只能使用单个删除解决
          // 每个删除都是基于 Promise， 综合考虑 Promise.all
          const arr: any = []
          selectedRowKeys.forEach((item: any) => {
            arr.push(deleteAdmin({ adminid: item}))
          })
          Promise.all(arr).then(() => {
            getAdminListData()
          })
        }}>批量删除</Button> }
      </Space>
      <Table
        columns={ columns }
        dataSource={ adminList }
        // rowKey = "adminid"
        rowKey = { (record) => record.adminid }
        scroll = {{ y: height - 330 }}
        pagination = { config }
        rowSelection={rowSelection}
      ></Table>
      <Drawer title="添加管理员" placement="right" onClose={() => {
        getAdminListData()
        setAdminname('')
        setPassword('')
        setRole(1)
        setCheckedkeys(['0-0'])
        setOpen(false)
      }} open={open}>
        <Space direction='vertical' style={{ display: 'flex' }}>
          <Input placeholder='账户名' value = { adminname } onChange = { e => setAdminname(e.target.value) } />
          <Input placeholder='密码' value = { password } onChange = { e => setPassword(e.target.value) } />
          <Select defaultValue={ 1 } style={{ width: '100%'}} value = { role } onChange = { (value) => setRole(value)}>
            <Select.Option value={1}>管理员</Select.Option>
            <Select.Option value={2}>超级管理员</Select.Option>
          </Select>
          选择该管理员的权限：
          <Tree
            checkable
            checkedKeys = { checkedKeys }
            onCheck = { (checkedKeys: any) => {
              setCheckedkeys(checkedKeys)
            }}
            treeData={ treeData }
          />
          <Button type="primary" onClick={ onAdd } disabled = { dis }>添加管理员</Button>
        </Space>
      </Drawer>
      <Modal title="修改管理员" footer={null} open={isModalOpen} onOk={() => {}} onCancel={ () => {
        setAdminname('')
        setRole(1)
        setCheckedkeys(['0-0'])
        setIsModalOpen(false)
      }}>
        <Space direction='vertical' style={{ display: 'flex' }}>
          <Input disabled placeholder='账户名' value = { adminname } onChange = { e => setAdminname(e.target.value) } />
          <Select defaultValue={ 1 } style={{ width: '100%'}} value = { role } onChange = { (value) => setRole(value)}>
            <Select.Option value={1}>管理员</Select.Option>
            <Select.Option value={2}>超级管理员</Select.Option>
          </Select>
          选择该管理员的权限：
          <Tree
            checkable
            checkedKeys = { checkedKeys }
            onCheck = { (checkedKeys: any) => {
              setCheckedkeys(checkedKeys)
            }}
            treeData={ treeData }
          />
          <Button type="primary" onClick={ onUpdate } >修改管理员权限</Button>
        </Space>
      </Modal>
    </Space>
  )
};

export default Index;

20 系统首页数据统计

1
2
3
4
5
6
7
8
9
10
11
12
13
14
// src/api/home.ts
import request from '@/utils/request'

export function getUserTotalNum () {
  return request({
    url: '/statistic/user'
  })
}

export function getShopTotalNum () {
  return request({
    url: '/statistic/product'
  })
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
// src/views/home/Index.tsx
import React, { FC, useState, useEffect } from 'react';
import { CalculatorOutlined, UsergroupDeleteOutlined } from '@ant-design/icons';
import { Statistic, Col, Row, } from 'antd';
import { getShopTotalNum, getUserTotalNum } from '@/api/home';
interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  const [ userNum, setUserNum ] = useState(0)
  const [ proNum, setProNum ] = useState(0)

  useEffect(() => {
    getUserTotalNum().then(res => setUserNum(res.data.data))
    getShopTotalNum().then(res => setProNum(res.data.data))
  }, [])
  return (
    <>
      <Row gutter={16}>
        <Col span={3}>
          <Statistic title="商品总数量" value={proNum} prefix={<CalculatorOutlined />} />
        </Col>
        <Col span={3}>
          <Statistic title="用户总数量" value={userNum} prefix={<UsergroupDeleteOutlined />}  />
        </Col>
      </Row>
    </>
  )
};

export default Index;

21 左侧菜单栏的权限

21.1 思路

  • 当用户登录的时候，可以获取到该用户的 checkedKeys 数据
  • 使用这个数据从 router/menu.tsx中提取匹配的数据，
  • 生成左侧菜单栏组件（目前是直接渲染router/menu.tsx）

21.2 算法过程

image-20221027151803006

从一个数组['0-0', '0-1-0', '0-2-0-0', '0-2-0-1', '0-3-2']触发，筛选 router/menu.tsx，获取到满足条件的数据

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
// src/router/menu.tsx
import { IMenuProps } from './inter'
import {
  HomeOutlined,
  UploadOutlined,
  PictureOutlined,
  ProfileOutlined,
  OrderedListOutlined,
  FilterOutlined,
  TeamOutlined,
  UserOutlined,
  SettingOutlined
} from '@ant-design/icons'

import Home from '@/views/home/Index'

import Banner from '@/views/banner/Index'
import BannerList from '@/views/banner/List'
import BannerActive from '@/views/banner/Active'
import BannerAdd from '@/views/banner/Add'

import Product from '@/views/product/Index'
import ProductSearch from '@/views/product/Search'
import ProductList from '@/views/product/list/Index'
import ProductHomeList from '@/views/product/list/Home'
import ProductDetailList from '@/views/product/list/Detail'
import ProductCartList from '@/views/product/list/Cart'

import Account from '@/views/account/Index'
import UserList from '@/views/account/UserList'
import AdminList from '@/views/account/AdminList'

import Setting from '@/views/setting/Index'

const menus: IMenuProps[] = [
  {
    label: '系统首页',
    key: '/',
    keyid: '0-0',
    icon: <HomeOutlined />,
    element: <Home />
  },
  {
    label: '轮播图管理',
    key: '/banner',
    keyid: '0-1',
    icon: <UploadOutlined />,
    element: <Banner />,
    children: [
      {
        label: '首页轮播图',
        key: '/banner/home',
        keyid: '0-1-0',
        icon: <PictureOutlined />,
        element: <BannerList />,
        index: 1
      }
    ]
  },
  {
    label: '产品管理',
    key: '/pro',
    keyid: '0-2',
    icon: <ProfileOutlined />,
    element: <Product />,
    children: [
      {
        label: '产品列表',
        key: '/pro/list',
        keyid: '0-2-0',
        icon: <OrderedListOutlined />,
        element: <ProductList />,
        index: 1,
        children: [
          {
            label: '首页产品列表',
            key: '/pro/list/home',
            keyid: '0-2-0-0',
            element: <ProductHomeList />,
            index: 1
          },
          {
            label: '详情推荐列表',
            key: '/pro/list/detail',
            keyid: '0-2-0-1',
            element: <ProductDetailList />
          },

        ]
      },

    ]
  },
  {
    label: '账户管理',
    key: '/account',
    keyid: '0-3',
    icon: <TeamOutlined />,
    element: <Account />,
    children: [
      {
        label: '管理员列表',
        key: '/account/adminlist',
        keyid: '0-3-2',
        icon: <UserOutlined />,
        element: <AdminList />
      }
    ]
  }
]

export default menus

21.3 算法实现

算法1：

  • 从[‘0-0’, ‘0-1-0’, ‘0-2-0-0’, ‘0-2-0-1’, ‘0-3-2’] 到
  • [‘0-0’, ‘0-1’, ‘0-1-0’, ‘0-2’, ‘0-2-0’, ‘0-2-0-0’, ‘0-2-0-1’, ‘0-3’, ‘0-3-2’]
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28

// ['0-0', '0-1-0', '0-2-0-0', '0-2-0-1', '0-3-2']
// ['0-0', '0-1', '0-1-0',  '0-2', '0-2-0', '0-2-0-0', '0-2-0-1', '0-3', '0-3-2']
let arr = ['0-0','0-1-0','0-2-0-0','0-2-0-1','0-3-2', '0-4-0-0-2', '0-5-1-2-0-1']
// 0-0
// 0-1 0-1-0
// 0-2 0-2-0 0-2-0-0
// 0-2 0-2-0 0-2-0-1
// 0-3 0-3-2
// 0-4 0-4-0 0-4-0-0  0-4-0-0-2
// 0-5 0-5-1 0-5-1-2  0-5-1-2-0  0-5-1-2-0-1

// let brr = []
// for(let i = 0; i < arr.length; i++){
//   for(let j = 0; j < arr[i].length; j += 2){
//     brr.push(arr[i].substring(0, j + 3))
//   }
// }

// console.log(new Set(brr));
let brr = new Set()
for(let i = 0; i < arr.length; i++){
  for(let j = 0; j < arr[i].length; j += 2){
    brr.add(arr[i].substring(0, j + 3))
  }
}

console.log(brr);

算法2：

[‘0-0’, ‘0-1’, ‘0-1-0’, ‘0-2’, ‘0-2-0’, ‘0-2-0-0’, ‘0-2-0-1’, ‘0-3’, ‘0-3-2’] 提取数据

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
// src/router/utils.tsx
import { Menu } from 'antd';
import { IMenuProps } from './inter';
import { Navigate, Route } from 'react-router-dom'
import React from 'react';
import type { DataNode } from 'antd/es/tree';
// .......

export function getCheckedKeysArr (arr: string[]) {
  const brr: Set<string> = new Set()
  for(let i = 0; i < arr.length; i++){
    for(let j = 0; j < arr[i].length; j += 2){
      brr.add(arr[i].substring(0, j + 3))
    }
  }
  return [...brr]
}
// menus 原始数据
// checkedKeys转换后的数据 ['0-0', '0-1', '0-1-0',  '0-2', '0-2-0', '0-2-0-0', '0-2-0-1', '0-3', '0-3-2']
export function getPermissionMenu (menus: IMenuProps[], checkedKeys: string[]) {
  let arr: IMenuProps[] = []
  // 处理第一级数据
  checkedKeys.forEach(value => {
    menus.forEach(item => {
      if (item.keyid === value) { // 这项数据又
        arr.push({...item})
      }
    })
  })
  // 处理子数据
  arr.forEach(item => {
    if (item.children) {
      let newArr = getPermissionMenu(item.children, checkedKeys)
      item.children = newArr
    }
  })

  return arr
}

此时提示 ts配置中target 需要更改为 ‘es2015’

1
2
3
4
5
6
7
// tsconfig.json
{
  "compilerOptions": {
    "target": "es2015",
    ...
  }
}

21.4 生成动态的左侧菜单项

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
// src/layout/components/SideBar.tsx 左侧菜单栏
import React, { FC, useState, useEffect } from 'react';

import { Layout, Menu, Image, MenuProps } from 'antd';
import { useAppSelector } from '@/store/hook';
import menus from '@/router/menu'
import logo from '@/logo.svg'
import { getCheckedKeysArr, getPermissionMenu, getSubMenu } from '@/router/utils'
import { useLocation, useNavigate } from 'react-router-dom';

interface ISideBarProps {

};

const { Sider } = Layout;

// 设置只展开一个菜单项
const rootSubmenuKeys: string[] = [];
menus.forEach(item => {
  item.children && rootSubmenuKeys.push(item.key)
})

const SideBar:FC<ISideBarProps> = () => {
  const collapsed = useAppSelector(state => state.app.collapsed);
  // 获取当前路由的路径信息
  const { pathname } = useLocation()
  // 当前选中的菜单项key数组
  // 初始值设置为 [pathname],刷新进入选中某一个菜单项
  const [selectedKeys, setSelectedKeys] = useState([pathname])

  // const [openKeys, setOpenKeys] = useState<string[]>(['/pro', '/pro/list'])
  const [openKeys, setOpenKeys] = useState<string[]>(getSubMenu(pathname))

  // 展开哪一项数据
  // const [openKeys, setOpenKeys] = useState<string[]>([])
  // 打开一个菜单项时，需要做判断 - SubMenu 展开/关闭的回调
  const onOpenChange: MenuProps['onOpenChange'] = keys => {
    // 如果当前展开项是 轮播图管理，再点击 账户管理 ['/banner', '/account']
    // console.log('keys', keys) // ['/banner'] =>  ['/banner', '/account']
    // console.log('openKeys', openKeys) // [] => ['/banner']
    // 得到当前
    const latestOpenKey = keys.find(key => openKeys.indexOf(key) === -1);
    // console.log('latestOpenKey', latestOpenKey) // /banner ===> /account
    if (rootSubmenuKeys.indexOf(latestOpenKey!) === -1) {
      setOpenKeys(keys);
    } else {
      setOpenKeys(latestOpenKey ? [latestOpenKey] : []);
    }
  }

  // 点击切换路由
  const navigate = useNavigate()
  const changeUrl = ({ key }: { key: string }) => {
    // console.log(key)
    navigate(key, { replace: false })

    // 点击左侧菜单，切换菜单项，选中样式
    setSelectedKeys([key])
  }

  // 监听 pathname 的变化，然后调整左侧菜单打开和选中状态
  useEffect(() => {
    setSelectedKeys([pathname])
    setOpenKeys(getSubMenu(pathname))
  }, [pathname])

  // admin账户所有的权限均课件  其余权限是动态的
  const adminname = useAppSelector(state => state.admins.adminname);
  const checkedKeys = useAppSelector(state => state.admins.checkedKeys);
  // console.log('checkedKeys', checkedKeys)
  let newMenus = menus
  if (checkedKeys.length === 0 && adminname === 'admin') {
    newMenus = menus
  } else {
    const newCheckedKeys = getCheckedKeysArr(checkedKeys)
    newMenus = getPermissionMenu(menus, newCheckedKeys)
  }

  return (
    <Sider trigger={null} collapsible collapsed={collapsed}>
      <div className="logo" style={ {
        display: 'flex',
        justifyContent: 'center',
        alignItems: 'center',
        color: '#fff'
      }}>
        <Image src = { logo } width="28px" height="28px" preview={ false }></Image>
        { !collapsed && <div style={{
          height: '32px',
          overflow: 'hidden',
          lineHeight: '32px'
        }}>嗨购后台管理系统</div> }
      </div>
      <Menu
        theme="dark"
        mode="inline"
        defaultSelectedKeys={['1']}
        openKeys = { openKeys } // 打开哪一个菜单项
        onOpenChange = { onOpenChange } // 打开某一个菜单项时需要关闭其他菜单项
        onClick = { changeUrl }
        selectedKeys = { selectedKeys }
        items = { newMenus }
      >
      </Menu>
    </Sider>
  )
};

export default SideBar;

有的公司在登录之后，会直接返回类似router/menus.tsx的数据

22、页面权限

也称之为路由权限

一个有权限访问页面A的人，把整个链接地址发给了没有权限访问的另外一个人

根据数据库中存储的字段，提取当前用户需要的 menus 的数据

如果用户访问的当前路由在 总路由中但是不在当前用户的路由中，显示无权限页面，否则显示404页面

核心思想：

  • 当前路由在不在权限路由 - 生成路由时使用 当前权限路由 （getPermissionMenu）

  • 当前的路由在不在所有的路由

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
// src/router/utils.tsx
// ....
// 判断当前请求的地址是不是在路由系统中
export function isContainMenus (menus: IMenuProps[], pathname: string) { // ++++++++++
  let bool = menus.some(item => {
    if (item.children) {
      if (item.key === pathname) {
        return true
      } else {
        return item.children.some(it => it.key === pathname)
      }
    } else {
      return item.key === pathname
    }
  })

  return bool
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
// src/layout/components/AppMain.tsx 内容区域
import React, { FC } from 'react';
import { Layout } from 'antd';
import menus from '@/router/menu';
import { getCheckedKeysArr, getPermissionMenu, isContainMenus, renderRoute } from '@/router/utils';
import { Routes, Route, useLocation } from 'react-router-dom'
import Page404 from '@/views/error/Page404';
import { useAppSelector } from '@/store/hook';
interface IAppMainProps {

};
const { Content } = Layout;
// const arr = renderRoute(menus)
// console.log('arr', arr[1])
const AppMain:FC<IAppMainProps> = () => {
  // admin账户所有的权限均可见  其余权限是动态的
  const adminname = useAppSelector(state => state.admins.adminname);
  const checkedKeys = useAppSelector(state => state.admins.checkedKeys);
  // console.log('checkedKeys', checkedKeys)
  let newMenus = menus
  if (checkedKeys.length === 0 && adminname === 'admin') {
    newMenus = menus
  } else {
    const newCheckedKeys = getCheckedKeysArr(checkedKeys)
    newMenus = getPermissionMenu(menus, newCheckedKeys)
  }

  const { pathname } = useLocation()
  const flag = isContainMenus(menus, pathname)

  return (
    <Content
      className="site-layout-background"
      id = 'test'
      style={{
        margin: '24px 16px',
        padding: 24,
        minHeight: 280,
      }}
    >
      {/*
        多个路由需要定义时，包裹在Routes选项下
      */}
      <Routes>
        {
          renderRoute(newMenus)
        }
        {/*
            ++++++ 404+++++
        */}
        <Route path="*" element = { flag ? <div>无权限</div> : <Page404 /> } />
      </Routes>
    </Content>
  )
};

export default AppMain;

23、按钮权限

超级管理员才可以批量删除

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
// src/views/account/AdminList.tsx
import React, { FC, useEffect, useState, useMemo } from 'react';
import { Table, Space, Button, Tag, Popconfirm, Drawer, Input, Select, Tree, message, Modal } from 'antd'
import {
  EditOutlined,
  DeleteOutlined
} from '@ant-design/icons'
import type { ColumnsType } from 'antd/es/table';
import type { TableRowSelection } from 'antd/es/table/interface';
import type { DataNode } from 'antd/es/tree';
import { addAdmin, deleteAdmin, getAdminList, updateAdmin } from '@/api/admin';
import usePagination from '@/hooks/usePagination';
import menus from '@/router/menu';
import { getTreeData } from '@/router/utils';
import { useAppSelector } from '@/store/hook';
interface IIndexProps {
};
interface DataType {
  adminid: string
  adminname: string
  role: number
  checkedKeys: any[]
}

const Index:FC<IIndexProps> = () => {
  // 树形控件
  const treeData: DataNode[] = getTreeData(menus)

  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [1, 2, 3, 4],
    showQuickJumper: true
  })

  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])


  const [adminList, setAdminList] = useState<DataType[]>([])
  const getAdminListData = () => { // 获取列表数据
    // console.log(66)
    getAdminList().then(res => {
      console.log(res.data)
      setAdminList(res.data.data)
    })
  }
  useEffect(() => {
    getAdminListData()
  }, [])


  const columns: ColumnsType<DataType> = [
    {
      title: '序号',
      render (_, record, index) {
        return (<span>{ (config.current - 1) * config.pageSize + index + 1 }</span>)
      }
    },
    {
      title: '账户',
      dataIndex: 'adminname'
    },
    {
      title: '角色',
      dataIndex: 'role',
      render: (text) => { // 第一个参数即为 role
        return text === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      }
      // render: (_, { role }) => { // 第一个参数即为 role 字段的值 第二个参数是当前对象
      //   return role === 2 ? <Tag color="cyan">超级管理员</Tag> : <Tag>管理员</Tag>
      // }
    },
    {
      title: '操作',
      render (_, record, index) {
        return (
          <Space>
            <Button type='ghost'  shape="circle" icon={<EditOutlined />} onClick = {() => {
              // 给表单填充数据
              setAdminname(record.adminname)
              setRole(record.role)
              setCheckedkeys(record.checkedKeys)
              // 弹出框显示
              setIsModalOpen(true)
            }}></Button>
            <Popconfirm title="确定删除吗?" onConfirm={ () => {
              deleteAdmin({ adminid: record.adminid}).then(() => {
                // 删除完毕重新获取数据
                getAdminListData()
              })
            }} onOpenChange={() => console.log('open change')}>
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
            </Popconfirm>
          </Space>
        )
      }
    }
  ]

  // 自定义选择 selectedRowKeys 批量删除的数据
  const [selectedRowKeys, setSelectedRowKeys] = useState<React.Key[]>([]);

  const onSelectChange = (newSelectedRowKeys: React.Key[]) => {
    console.log('selectedRowKeys changed: ', newSelectedRowKeys);
    setSelectedRowKeys(newSelectedRowKeys);
  };
  const rowSelection: TableRowSelection<DataType> = {
    selectedRowKeys,
    onChange: onSelectChange,
  }

  const flag = useMemo(() => {
    return selectedRowKeys.length > 0
  }, [selectedRowKeys])


  // 抽屉效果 用来添加管理员
  const [open, setOpen] = useState(false);
  const [adminname, setAdminname] = useState('')
  const [password, setPassword] = useState('')
  const [role, setRole] = useState(1)
  // 树形控件
  const [checkedKeys, setCheckedkeys] = useState(['0-0'])

  const onAdd = () => {
    const result: any = {
      adminname, password, role, checkedKeys: checkedKeys
    }
    addAdmin(result).then((res) => {
      console.log(res.data)
      if (res.data.code === '10004') {
        message.warning('该管理员账户已存在')
      } else if (res.data.code === '10008') {
        message.warning('账户名不符合规则')
      } else {
        message.success('添加成功')
        getAdminListData()
        setAdminname('')
        setPassword('')
        setRole(1)
        setCheckedkeys(['0-0'])
        setOpen(false)
      }

    })
    console.log(result)
  }

  const dis = useMemo(() => {
    return adminname === '' || password === ''
  }, [adminname, password])


  // 编辑
  const [isModalOpen, setIsModalOpen] = useState(false);
  const onUpdate = () => {
    const result: any = {
      adminname, role, checkedKeys
    }
    updateAdmin(result).then(() => {
      setIsModalOpen(false)
      setAdminname('')
      setRole(1)
      setCheckedkeys(['0-0'])
      getAdminListData()
    })
  }

  const deleteRole = useAppSelector(state => state.admins.role)
  return (
    <Space style={{ width: '100%' }} direction="vertical" >
      <Space>
        <Button type='primary' onClick={ () => setOpen(true) }>添加管理员</Button>
        { flag && <Button type='primary' onClick={ () => {
          if (deleteRole < 2) {
            message.warn('暂无权限')
            return
          }

          // 思考： 还用气泡弹出框？ 自行选择删除的方案
          // 接口没有提供批量删除，只能使用单个删除解决
          // 每个删除都是基于 Promise， 综合考虑 Promise.all
          const arr: any = []
          selectedRowKeys.forEach((item: any) => {
            arr.push(deleteAdmin({ adminid: item}))
          })
          Promise.all(arr).then(() => {
            getAdminListData()
          })
        }}>批量删除</Button> }
      </Space>
      <Table
        columns={ columns }
        dataSource={ adminList }
        // rowKey = "adminid"
        rowKey = { (record) => record.adminid }
        scroll = {{ y: height - 330 }}
        pagination = { config }
        rowSelection={rowSelection}
      ></Table>
      <Drawer title="添加管理员" placement="right" onClose={() => {
        getAdminListData()
        setAdminname('')
        setPassword('')
        setRole(1)
        setCheckedkeys(['0-0'])
        setOpen(false)
      }} open={open}>
        <Space direction='vertical' style={{ display: 'flex' }}>
          <Input placeholder='账户名' value = { adminname } onChange = { e => setAdminname(e.target.value) } />
          <Input placeholder='密码' value = { password } onChange = { e => setPassword(e.target.value) } />
          <Select defaultValue={ 1 } style={{ width: '100%'}} value = { role } onChange = { (value) => setRole(value)}>
            <Select.Option value={1}>管理员</Select.Option>
            <Select.Option value={2}>超级管理员</Select.Option>
          </Select>
          选择该管理员的权限：
          <Tree
            checkable
            checkedKeys = { checkedKeys }
            onCheck = { (checkedKeys: any) => {
              setCheckedkeys(checkedKeys)
              console.log('666', checkedKeys)
            }}
            treeData={ treeData }
          />
          <Button type="primary" onClick={ onAdd } disabled = { dis }>添加管理员</Button>
        </Space>
      </Drawer>
      <Modal title="修改管理员" footer={null} open={isModalOpen} onOk={() => {}} onCancel={ () => {
         setAdminname('')
         setRole(1)
         setCheckedkeys(['0-0'])
        setIsModalOpen(false)
      }}>
        <Space direction='vertical' style={{ display: 'flex' }}>
          <Input disabled placeholder='账户名' value = { adminname } onChange = { e => setAdminname(e.target.value) } />
          <Select defaultValue={ 1 } style={{ width: '100%'}} value = { role } onChange = { (value) => setRole(value)}>
            <Select.Option value={1}>管理员</Select.Option>
            <Select.Option value={2}>超级管理员</Select.Option>
          </Select>
          选择该管理员的权限：
          <Tree
            checkable
            checkedKeys = { checkedKeys }
            onCheck = { (checkedKeys: any) => {
              setCheckedkeys(checkedKeys)
            }}
            treeData={ treeData }
          />
          <Button type="primary" onClick={ onUpdate } >修改管理员权限</Button>
        </Space>
      </Modal>
    </Space>
  )
};

export default Index;

image-20221027171749565

单点登录

24、轮播图管理

24.1 封装接口

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
// src/api/banner.ts
import request from "../utils/request";

export interface IBannerParams {
  img: string
  alt: string
  link: string
}

export function getBannerList () {
  return request({
    url: '/banner/list'
  })
}


export function addBanner (params: IBannerParams) {
  return request({
    url: '/banner/add',
    method: 'POST',
    data: params
  })
}

export function deleteBanner (params: { bannerid: string}) {
  return request({
    url: '/banner/delete',
    data: params
  })
}

24.2 轮播图页面渲染

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
// src/views/banner/List.tsx
import { getBannerList } from '@/api/banner';
import React, { FC,useState, useEffect } from 'react';
import { Table, Space, Button, Image } from 'antd'
import { useNavigate } from 'react-router-dom';
import {
  DeleteOutlined
} from '@ant-design/icons'
import usePagination from '@/hooks/usePagination';
interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])
   // 分页设置
   const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [1, 2, 3, 4],
    showQuickJumper: true
  })

  const navigate = useNavigate()

  const [list, setList] = useState([])
  const getBannerListData = () => {
    getBannerList().then(res => {
      console.log(res.data)
      setList(res.data.data)
    })
  }
  useEffect(() => {
    getBannerListData()
  }, [])
  return (
    <Space
      direction='vertical'
      style={ { display: 'flex' }}
    >
      <Button type="primary" onClick={ () => {
        navigate('/banner/add')
      }}>添加轮播图</Button>
      <Table
        rowKey="bannerid"
        dataSource = { list }
        scroll = {{ y: height - 330 }}
        pagination = { config }
      >
        <Table.Column title="序号" render = { (_ ,record, index) => {
          return (
            <span>{ index + 1 }</span>
          )
        }}></Table.Column>
        <Table.Column title="图片" dataIndex="img" render = { text => {
          return <Image src = { text} style={{ height: 80 }} />
        }}></Table.Column>
        <Table.Column title="alt" dataIndex="alt"></Table.Column>
        <Table.Column title="link" dataIndex="link"></Table.Column>
        <Table.Column title="操作" render={ () => {
          return (
            <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
          )
        }}></Table.Column>
      </Table>
    </Space>
  )
};

export default Index;

24.3 删除轮播图

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
// src/views/banner/List.tsx
import { deleteBanner, getBannerList } from '@/api/banner';
import React, { FC,useState, useEffect } from 'react';
import { Table, Space, Button, Image, Popconfirm } from 'antd'
import { useNavigate } from 'react-router-dom';
import {
  DeleteOutlined
} from '@ant-design/icons'
import usePagination from '@/hooks/usePagination';
interface IIndexProps {

};
interface DataType {
  bannerid: string
  img: string
  alt: string
  link: string
  flag: boolean
}
const Index:FC<IIndexProps> = () => {
  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])
   // 分页设置
   const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [1, 2, 3, 4],
    showQuickJumper: true
  })

  const navigate = useNavigate()

  const [list, setList] = useState([])
  const getBannerListData = () => {
    getBannerList().then(res => {
      console.log(res.data)
      setList(res.data.data)
    })
  }
  useEffect(() => {
    getBannerListData()
  }, [])
  return (
    <Space
      direction='vertical'
      style={ { display: 'flex' }}
    >
      <Button type="primary" onClick={ () => {
        navigate('/banner/add')
      }}>添加轮播图</Button>
      <Table
        rowKey="bannerid"
        dataSource = { list }
        scroll = {{ y: height - 330 }}
        pagination = { config }
      >
        <Table.Column title="序号" render = { (_ ,record, index) => {
          return (
            <span>{ index + 1 }</span>
          )
        }}></Table.Column>
        <Table.Column title="图片" dataIndex="img" render = { text => {
          return <Image src = { text} style={{ height: 80 }} />
        }}></Table.Column>
        <Table.Column title="alt" dataIndex="alt"></Table.Column>
        <Table.Column title="link" dataIndex="link"></Table.Column>
        <Table.Column title="操作" render={ (_, record: DataType) => {
          return (
            <Popconfirm title="确定删除吗?" onConfirm={ () => {
              deleteBanner({ bannerid: record.bannerid}).then(() => {
                // 删除完毕重新获取数据
                getBannerListData()
              })
            }} onOpenChange={() => console.log('open change')}>
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
            </Popconfirm>
          )
        }}></Table.Column>
      </Table>
    </Space>
  )
};

export default Index;

23.4 添加轮播图

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
// src/views/banner/Add.tsx
import { addBanner } from '@/api/banner';
import { Image, Input, Space, Button } from 'antd';
import React, { FC, useState, useRef, useMemo } from 'react';
import { useNavigate } from 'react-router-dom';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  const navigate = useNavigate()

  const [link, setLink] = useState('')
  const [alt, setAlt] = useState('')
  const [img, setImg] = useState('')

  const file = useRef<any>()
  const onChange = () => {
    // console.log(file.current.input .files)
    const fileInfo = file.current.input.files[0]
    // 利用文件API FileReader 对象 生成图片base64地址
    const reader = new FileReader()
    reader.readAsDataURL(fileInfo)
    reader.onload = function () {
      // this.result 的结果即为 读取之后的值
      setImg(this.result as string)
    }
  }
  const flag = useMemo(() => {
    return link === '' || alt === '' || img === ''
  }, [link, alt, img])
  const onAdd = () => {
    addBanner({
      link, alt, img
    }).then(() => {
      navigate(-1)
    })
  }
  return (
    <Space direction='vertical' style={{ width: 300 }}>
      <Input placeholder='link' value = {link} onChange = { e => setLink(e.target.value)}/>
      <Input placeholder='alt' value = {alt} onChange = { e => setAlt(e.target.value)}/>
      <Input type="file" ref = { file } onChange = { onChange }/>
      <Input placeholder='图片地址' value = {img} onChange = { e => setImg(e.target.value)}/>
      <Image src={img} />
      <Button type='primary' disabled = { flag } onClick={ onAdd }>添加</Button>
    </Space>
  )
};

export default Index;

25.产品管理

25.1 封装接口

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
// src/api/pro.ts
import request from "../utils/request";
interface ISearchParams {
  category: string
  search: string
}

// 首页产品列表
export function getProList () {
  return request({
    url: '/pro/list'
  })
}
// 筛选列表数据
export function getSearchProList (params: ISearchParams) {
  return request({
    url: '/pro/searchPro',
    method: 'POST',
    data: params
  })
}
// 获取商品分类
export function getCategoryList () {
  return request({
    url: '/pro/getCategory'
  })
}
// 商品推荐列表
export function getDetailRecommendList () {
  return request({
    url: '/pro/showdata',
    method: 'POST',
    data: {
      type: 'isrecommend',
      flag: 1
    }
  })
}

// 购物车推荐列表
export function getCartRecommendList () {
  return request({
    url: '/pro/showdata',
    method: 'POST',
    data: {
      type: 'isrecommend',
      flag: 1
    }
  })
}
// 修改推荐
export function updateRecommend (params: { proid: string, flag: boolean }) {
  return request({
    url: '/pro/updateFlag',
    method: 'POST',
    data: {
      ...params,
      type: 'isrecommend'
    }
  })
}

// 修改秒杀
export function updateSeckill (params: { proid: string, flag: boolean }) {
  return request({
    url: '/pro/updateFlag',
    method: 'POST',
    data: {
      ...params,
      type: 'isseckill'
    }
  })
}

25.2 首页产品列表

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
// src/views/product/list/Home.tsx
import React, { FC,useState, useEffect } from 'react';
import { Table, Space, Button, Image, Switch  } from 'antd'
import { useNavigate } from 'react-router-dom';
import {
  DeleteOutlined
} from '@ant-design/icons'
import usePagination from '@/hooks/usePagination';
import { getProList, updateRecommend, updateSeckill } from '@/api/pro';
interface IIndexProps {

};
interface DataType {
  banners: string[]
  brand: string
  category: string
  desc: string
  discount: number
  img1: string
  img2: string
  img3: string
  img4: string
  isrecommend: number
  issale: number
  isseckill: number
  originprice: number
  proid: string
  proname: string
  sales: number
  stock: number
}
const Index:FC<IIndexProps> = () => {
  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])
  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [10, 20, 30, 40],
    showQuickJumper: true
  })

  const navigate = useNavigate()

  const [list, setList] = useState([])
  const getProListData = () => {
    getProList().then(res => {
      console.log(res.data)
      setList(res.data.data)
    })
  }
  useEffect(() => {
    getProListData()
  }, [])
  return (
    <Space
      direction='vertical'
      style={ { display: 'flex' }}
    >
      <Button type="primary">添加商品</Button>
      <Table
        rowKey="proid"
        dataSource = { list }
        scroll = {{ y: height - 330 }}
        pagination = { config }
      >
        <Table.Column title="序号" render = { (_ ,record, index) => {
          return (
            <span>{ (config.current - 1) * config.pageSize +index + 1 }</span>
          )
        }}></Table.Column>
        <Table.Column title="图片" dataIndex="img1" render = { text => {
          return <Image src = { text} style={{ height: 80 }} />
        }}></Table.Column>
        <Table.Column title="商品名称" dataIndex="proname"></Table.Column>
        <Table.Column title="商品价格" dataIndex="originprice"></Table.Column>
        <Table.Column title="是否秒杀" dataIndex="isseckill" render={ (text, record: DataType) => {
          return (
            <Switch defaultChecked = { text === 1}  onChange={
              () => {
                console.log(text)
                updateSeckill({ proid: record.proid, flag: text === 0}).then(() => getProListData())
              }
            } />
          )
        }}></Table.Column>
        <Table.Column title="是否推荐" dataIndex="isrecommend" render={ (text, record: DataType) => {
          return (
            <Switch defaultChecked = { text === 1}  onChange={
              () => {
                updateRecommend({ proid: record.proid , flag: text === 0}).then(() => getProListData())
              }
            } />
          )
        }}></Table.Column>
        <Table.Column title="操作" render={ (_, record: DataType) => {
          return (
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
          )
        }}></Table.Column>
      </Table>
    </Space>
  )
};

export default Index;

25.3 详情推荐数据

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
// src/views/product/list/Detail.tsx
import React, { FC,useState, useEffect } from 'react';
import { Table, Space, Button, Image, Switch  } from 'antd'
import { useNavigate } from 'react-router-dom';
import {
  DeleteOutlined
} from '@ant-design/icons'
import usePagination from '@/hooks/usePagination';
import { getDetailRecommendList, updateRecommend, updateSeckill } from '@/api/pro';
interface IIndexProps {

};
interface DataType {
  banners: string[]
  brand: string
  category: string
  desc: string
  discount: number
  img1: string
  img2: string
  img3: string
  img4: string
  isrecommend: number
  issale: number
  isseckill: number
  originprice: number
  proid: string
  proname: string
  sales: number
  stock: number
}
const Index:FC<IIndexProps> = () => {
  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])
  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [10, 20, 30, 40],
    showQuickJumper: true
  })

  const navigate = useNavigate()

  const [list, setList] = useState([])
  const getProListData = () => {
    getDetailRecommendList().then(res => {
      console.log(res.data)
      setList(res.data.data)
    })
  }
  useEffect(() => {
    getProListData()
  }, [])
  return (
    <Space
      direction='vertical'
      style={ { display: 'flex' }}
    >
      <Button type="primary">添加商品</Button>
      <Table
        rowKey="proid"
        dataSource = { list }
        scroll = {{ y: height - 330 }}
        pagination = { config }
      >
        <Table.Column title="序号" render = { (_ ,record, index) => {
          return (
            <span>{ (config.current - 1) * config.pageSize +index + 1 }</span>
          )
        }}></Table.Column>
        <Table.Column title="图片" dataIndex="img1" render = { text => {
          return <Image src = { text} style={{ height: 80 }} />
        }}></Table.Column>
        <Table.Column title="商品名称" dataIndex="proname"></Table.Column>
        <Table.Column title="商品价格" dataIndex="originprice"></Table.Column>
        <Table.Column title="是否推荐" dataIndex="isrecommend" render={ (text, record: DataType) => {
          return (
            <Switch defaultChecked = { text === 1}  onChange={
              () => {
                updateRecommend({ proid: record.proid , flag: text === 0}).then(() => getProListData())
              }
            } />
          )
        }}></Table.Column>
        <Table.Column title="操作" render={ (_, record: DataType) => {
          return (
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
          )
        }}></Table.Column>
      </Table>
    </Space>
  )
};

export default Index;

25.4 购物车推荐数据

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
// src/views/product/list/Cart.tsx
import React, { FC,useState, useEffect } from 'react';
import { Table, Space, Button, Image, Switch  } from 'antd'
import { useNavigate } from 'react-router-dom';
import {
  DeleteOutlined
} from '@ant-design/icons'
import usePagination from '@/hooks/usePagination';
import { getDetailRecommendList, updateRecommend, updateSeckill } from '@/api/pro';
interface IIndexProps {

};
interface DataType {
  banners: string[]
  brand: string
  category: string
  desc: string
  discount: number
  img1: string
  img2: string
  img3: string
  img4: string
  isrecommend: number
  issale: number
  isseckill: number
  originprice: number
  proid: string
  proname: string
  sales: number
  stock: number
}
const Index:FC<IIndexProps> = () => {
  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])
  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [10, 20, 30, 40],
    showQuickJumper: true
  })

  const navigate = useNavigate()

  const [list, setList] = useState([])
  const getProListData = () => {
    getDetailRecommendList().then(res => {
      console.log(res.data)
      setList(res.data.data)
    })
  }
  useEffect(() => {
    getProListData()
  }, [])
  return (
    <Space
      direction='vertical'
      style={ { display: 'flex' }}
    >
      <Button type="primary">添加商品</Button>
      <Table
        rowKey="proid"
        dataSource = { list }
        scroll = {{ y: height - 330 }}
        pagination = { config }
      >
        <Table.Column title="序号" render = { (_ ,record, index) => {
          return (
            <span>{ (config.current - 1) * config.pageSize +index + 1 }</span>
          )
        }}></Table.Column>
        <Table.Column title="图片" dataIndex="img1" render = { text => {
          return <Image src = { text} style={{ height: 80 }} />
        }}></Table.Column>
        <Table.Column title="商品名称" dataIndex="proname"></Table.Column>
        <Table.Column title="商品价格" dataIndex="originprice"></Table.Column>
        <Table.Column title="是否推荐" dataIndex="isrecommend" render={ (text, record: DataType) => {
          return (
            <Switch defaultChecked = { text === 1}  onChange={
              () => {
                updateRecommend({ proid: record.proid , flag: text === 0}).then(() => getProListData())
              }
            } />
          )
        }}></Table.Column>
        <Table.Column title="操作" render={ (_, record: DataType) => {
          return (
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
          )
        }}></Table.Column>
      </Table>
    </Space>
  )
};

export default Index;

25.5 筛选列表

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
// src/views/product/Search.tsx
import React, { FC,useState, useEffect } from 'react';
import { Table, Space, Button, Image, Switch, Select, Input  } from 'antd'
import { useNavigate } from 'react-router-dom';
import {
  DeleteOutlined
} from '@ant-design/icons'
import usePagination from '@/hooks/usePagination';
import { getCategoryList, getProList, updateRecommend, updateSeckill, getSearchProList } from '@/api/pro';
interface IIndexProps {

};
interface DataType {
  banners: string[]
  brand: string
  category: string
  desc: string
  discount: number
  img1: string
  img2: string
  img3: string
  img4: string
  isrecommend: number
  issale: number
  isseckill: number
  originprice: number
  proid: string
  proname: string
  sales: number
  stock: number
}
const Index:FC<IIndexProps> = () => {
  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])
  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [10, 20, 30, 40],
    showQuickJumper: true
  })

  const navigate = useNavigate()

  const [list, setList] = useState([])
  const getProListData = () => {
    getProList().then(res => {
      console.log(res.data)
      setList(res.data.data)
    })
  }
  useEffect(() => {
    getProListData()
  }, [])

  const [categoryList, setCategoryList] = useState([])
  const [category, setCategory] = useState('')
  const [search, setSearch] = useState('')
  useEffect(() => {
    getCategoryList().then(res => setCategoryList(res.data.data))
  }, [])

  return (
    <Space
      direction='vertical'
      style={ { display: 'flex' }}
    >
      <Space>
        <Select value={ category } style={{ width: 100 }} onChange = { value => setCategory(value)}>
          <Select.Option value="">全部</Select.Option>
          {
            categoryList && categoryList.map((item, index) => {
              return (
                <Select.Option key = {index} value={ item }>{ item }</Select.Option>
              )
            })
          }
        </Select>
        <Input placeholder='请输入搜索关键词' value={ search } onChange = { (e) => setSearch(e.target.value)}></Input>
        <Button type='primary' onClick={ () => {
          getSearchProList({ category, search}).then(res => setList(res.data.data))
        }}>搜索</Button>
      </Space>
      <Table
        rowKey="proid"
        dataSource = { list }
        scroll = {{ y: height - 330 }}
        pagination = { config }
      >
        <Table.Column title="序号" render = { (_ ,record, index) => {
          return (
            <span>{ (config.current - 1) * config.pageSize +index + 1 }</span>
          )
        }}></Table.Column>
        <Table.Column title="图片" dataIndex="img1" render = { text => {
          return <Image src = { text} style={{ height: 80 }} />
        }}></Table.Column>
        <Table.Column title="商品名称" dataIndex="proname"></Table.Column>
        <Table.Column title="商品价格" dataIndex="originprice" sorter={(a: DataType,b: DataType) => a.originprice - b.originprice}></Table.Column>
        <Table.Column title="是否秒杀" dataIndex="isseckill" render={ (text, record: DataType) => {
          return (
            <Switch defaultChecked = { text === 1}  onChange={
              () => {
                console.log(text)
                updateSeckill({ proid: record.proid, flag: text === 0}).then(() => getProListData())
              }
            } />
          )
        }}></Table.Column>
        <Table.Column title="是否推荐" dataIndex="isrecommend" render={ (text, record: DataType) => {
          return (
            <Switch defaultChecked = { text === 1}  onChange={
              () => {
                updateRecommend({ proid: record.proid , flag: text === 0}).then(() => getProListData())
              }
            } />
          )
        }}></Table.Column>
        <Table.Column title="操作" render={ (_, record: DataType) => {
          return (
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
          )
        }}></Table.Column>
      </Table>
    </Space>
  )
};

export default Index;

26.数据可视化

方案：

echarts: https://echarts.apache.org/zh/index.html

ts中使用 echarts ： https://echarts.apache.org/handbook/zh/basics/import#%E5%9C%A8-typescript-%E4%B8%AD%E6%8C%89%E9%9C%80%E5%BC%95%E5%85%A5

highCharts:https://www.highcharts.com.cn/

Antv: https://antv.gitee.io/zh/

g2:https://antv-g2.gitee.io/zh/

g2plot:https://g2plot.antv.vision/zh/

react中使用g2:https://charts.ant.design/zh-CN

D3:视频地址：链接: https://pan.baidu.com/s/1SVS36TjtcR27Rqj_HURDZA 密码: p9ur

1.echarts

添加页面以及配置路由

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
// src/views/data/Index.tsx
import React, { FC } from 'react';
import { Outlet } from 'react-router-dom';

interface IDataProps {

};

const Data:FC<IDataProps> = () => {
  return (
    <>
      <h1>数据可视化</h1>
      <Outlet />
    </>
  )
};

export default Data;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/data/ECharts.tsx
import React, { FC } from 'react';

interface IEChartsProps {

};

const ECharts:FC<IEChartsProps> = () => {
  return (
    <>
      <h3>ECharts</h3>
    </>
  )
};

export default ECharts;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/data/HighCharts.tsx
import React, { FC } from 'react';

interface IHighChartsProps {

};

const HighCharts:FC<IHighChartsProps> = () => {
  return (
    <>
      <h3>HighCharts</h3>
    </>
  )
};

export default HighCharts;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/data/Antv.tsx
import React, { FC } from 'react';

interface IAntvProps {

};

const Antv:FC<IAntvProps> = () => {
  return (
    <>
      <h3>Antv</h3>
    </>
  )
};

export default Antv;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
// src/router/menu.tsx
import { IMenuProps } from './inter'
import {
  HomeOutlined,
  UploadOutlined,
  PictureOutlined,
  ProfileOutlined,
  OrderedListOutlined,
  FilterOutlined,
  TeamOutlined,
  UserOutlined,
  SettingOutlined
} from '@ant-design/icons'

import Home from '@/views/home/Index'

import Banner from '@/views/banner/Index'
import BannerList from '@/views/banner/List'
import BannerActive from '@/views/banner/Active'
import BannerAdd from '@/views/banner/Add'

import Product from '@/views/product/Index'
import ProductSearch from '@/views/product/Search'
import ProductList from '@/views/product/list/Index'
import ProductHomeList from '@/views/product/list/Home'
import ProductDetailList from '@/views/product/list/Detail'
import ProductCartList from '@/views/product/list/Cart'

import Account from '@/views/account/Index'
import UserList from '@/views/account/UserList'
import AdminList from '@/views/account/AdminList'

import Setting from '@/views/setting/Index'

import Data from '@/views/data/Index'
import ECharts from '@/views/data/ECharts'
import HighCharts from '@/views/data/HighCharts'
import Antv from '@/views/data/Antv'

const menus: IMenuProps[] = [
  {
    label: '系统首页',
    key: '/',
    keyid: '0-0',
    icon: <HomeOutlined />,
    element: <Home />
  },
  {
    label: '轮播图管理',
    key: '/banner',
    keyid: '0-1',
    icon: <UploadOutlined />,
    // redirect: '/banner/home',
    element: <Banner />,
    children: [
      {
        label: '首页轮播图',
        key: '/banner/home',
        keyid: '0-1-0',
        icon: <PictureOutlined />,
        element: <BannerList />,
        index: 1
      },
      {
        label: '活动页轮播图',
        key: '/banner/active',
        keyid: '0-1-1',
        icon: <PictureOutlined />,
        element: <BannerActive />
      },
      {
        label: '添加轮播图',
        key: '/banner/add',
        keyid: '0-1-2',
        icon: <UploadOutlined />,
        element: <BannerAdd />,
        hidden: 1
      },
    ]
  },
  {
    label: '产品管理',
    key: '/pro',
    keyid: '0-2',
    icon: <ProfileOutlined />,
    element: <Product />,
    children: [
      {
        label: '产品列表',
        key: '/pro/list',
        keyid: '0-2-0',
        icon: <OrderedListOutlined />,
        element: <ProductList />,
        index: 1,
        children: [
          {
            label: '首页产品列表',
            key: '/pro/list/home',
            keyid: '0-2-0-0',
            element: <ProductHomeList />,
            index: 1
          },
          {
            label: '详情推荐列表',
            key: '/pro/list/detail',
            keyid: '0-2-0-1',
            element: <ProductDetailList />
          },
          {
            label: '购物车推荐列表',
            key: '/pro/list/cart',
            keyid: '0-2-0-2',
            element: <ProductCartList />
          },
        ]
      },
      {
        label: '筛选列表',
        key: '/pro/search',
        keyid: '0-2-1',
        icon: <FilterOutlined />,
        element: <ProductSearch />
      },
    ]
  },
  {
    label: '账户管理',
    key: '/account',
    keyid: '0-3',
    icon: <TeamOutlined />,
    element: <Account />,
    children: [
      {
        label: '用户列表',
        key: '/account/userlist',
        keyid: '0-3-1',
        icon: <UserOutlined />,
        element: <UserList />,
        index: 1
      },
      {
        label: '管理员列表',
        key: '/account/adminlist',
        keyid: '0-3-2',
        icon: <UserOutlined />,
        element: <AdminList />
      }
    ]
  },
  {
    label: '设置',
    key: '/setting',
    keyid: '0-4',
    icon: <SettingOutlined />,
    element: <Setting />,
    hidden: 1
  },
  {
    label: '数据可视化',
    key: '/data',
    keyid: '0-5',
    icon: <SettingOutlined />,
    element: <Data />,
    children: [
      {
        label: 'ECharts',
        key: '/data/echarts',
        keyid: '0-5-0',
        icon: <SettingOutlined />,
        element: <ECharts />,
        index: 1
      },
      {
        label: 'HighCharts',
        key: '/data/highcharts',
        keyid: '0-5-1',
        icon: <SettingOutlined />,
        element: <HighCharts />
      },
      {
        label: 'antv',
        key: '/data/antv',
        keyid: '0-5-2',
        icon: <SettingOutlined />,
        element: <Antv />
      }
    ]
  }
]


export default menus
1
cnpm install echarts --save
1
2
3
4
5
6
7
8
// src/api/data.ts
import request from './../utils/request'

export function getData () {
  return request({
    url: '/data/simpleData'
  })
}

处理数据

自适应

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
// src/views/data/ECharts.tsx
import React, { FC, useEffect, useState } from 'react';
import { Col, Row, Button } from 'antd';
import * as echarts from 'echarts';
import { getData } from '@/api/data';

interface IEChartsProps {

};

const ECharts:FC<IEChartsProps> = () => {
  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])

  const [data, setData] = useState<any[]>([])
  useEffect(() => {
    getData().then(res => {
      console.log(res.data)
      setData(res.data.data)
    })
  }, [])

  useEffect(() => {
    var serverCharts = echarts.init(document.getElementById('serverCharts') as HTMLDivElement);
    serverCharts.setOption({
      title: {
        text: '折线图示例',
        left: 'center',
      },
      legend: {
        data: ['销量', '销量1'],
        bottom: 10,
        left: 'center'
      },
      toolbox: {
        feature: {
          dataZoom: {
            yAxisIndex: 'none'
          },
          restore: {},
          saveAsImage: {}
        },
        right: 200
      },
      xAxis: {
        data: data.map((item:any) => item.x)
      },
      yAxis: {},
      series: [
        {
          name: '销量',
          type: 'line', // 折线图
          data: data.map((item:any) => item.val)
        }
      ]
    });
    window.addEventListener('resize',() => {
      serverCharts && serverCharts.resize();
    })
  }, [data])


  useEffect(() => {
    var barCharts = echarts.init(document.getElementById('barCharts') as HTMLDivElement);
    barCharts.setOption({
      title: {
        text: '柱状图示例'
      },
      tooltip: {},
      xAxis: {
        data: ['衬衫', '羊毛衫', '雪纺衫', '裤子', '高跟鞋', '袜子']
      },
      yAxis: {},
      series: [
        {
          name: '销量',
          type: 'bar', // 柱状图
          data: [5, 20, 36, 10, 10, 20]
        }
      ]
    });
    window.addEventListener('resize',() => {
      barCharts && barCharts.resize();
    })
  }, [])

  useEffect(() => {
    var lineCharts = echarts.init(document.getElementById('lineCharts') as HTMLDivElement);
    lineCharts.setOption({
      title: {
        text: '折线图示例',
        left: 'center',
      },
      legend: {
        data: ['销量', '销量1'],
        bottom: 10,
        left: 'center'
      },
      toolbox: {
        feature: {
          dataZoom: {
            yAxisIndex: 'none'
          },
          restore: {},
          saveAsImage: {}
        },
        right: 200
      },
      xAxis: {
        data: ['衬衫', '羊毛衫', '雪纺衫', '裤子', '高跟鞋', '袜子']
      },
      yAxis: {},
      series: [
        {
          name: '销量',
          type: 'line', // 折线图
          data: [5, 20, 36, 10, 10, 20]
        },
        {
          name: '销量1',
          type: 'line', // 折线图
          data: [15, 200, 316, 210, 410, 300]
        }
      ]
    });
    window.addEventListener('resize',() => {
      lineCharts && lineCharts.resize();
    })
  }, [])

  useEffect(() => {
    var randomCharts = echarts.init(document.getElementById('randomCharts') as HTMLDivElement);

    let base = +new Date(1988, 9, 3);
    let oneDay = 24 * 3600 * 1000;
    let data = [[base, Math.random() * 300]];
    for (let i = 1; i < 20000; i++) {
      let now = new Date((base += oneDay));
      data.push([+now, Math.round((Math.random() - 0.5) * 20 + data[i - 1][1])]);
    }

    randomCharts.setOption({
      tooltip: {
        trigger: 'axis',
        position: function (pt: any[]) {
          return [pt[0], '10%'];
        }
      },
      title: {
        left: 'center',
        text: 'Large Ara Chart'
      },
      toolbox: {
        feature: {
          dataZoom: {
            yAxisIndex: 'none'
          },
          restore: {},
          saveAsImage: {}
        }
      },
      xAxis: {
        type: 'time',
        boundaryGap: false
      },
      yAxis: {
        type: 'value',
        boundaryGap: [0, '100%']
      },
      dataZoom: [
        {
          type: 'inside',
          start: 0,
          end: 20
        },
        {
          start: 0,
          end: 20
        }
      ],
      series: [
        {
          name: 'Fake Data',
          type: 'line',
          smooth: true,
          symbol: 'none',
          areaStyle: {},
          data: data
        }
      ]
    })
    window.addEventListener('resize',() => {
      randomCharts && randomCharts.resize();
    })
  }, [])

  const changeData = () => {
    setData([
      {x: '星期一', val: Math.random()*500},
      {x: '星期二', val: Math.random()*350},
      {x: '星期三', val: Math.random()*150},
      {x: '星期四', val: Math.random()*650},
      {x: '星期五', val: Math.random()*50},
      {x: '星期六', val: Math.random()*850},
      {x: '星期日', val: Math.random()*150}
    ])
  }
  return (
    <>
      <h3>ECharts</h3>
      <Button onClick={ changeData }>改变数据data</Button>
      <Row gutter={15}>
        <Col span={12}>
          <p>柱状图</p>
          <div id='barCharts' style={ { width: '100%', height: 300 }}></div>
        </Col>
        <Col span={12}>
          <p>折线图</p>
          <div id='lineCharts' style={ { width: '100%', height:300  }}></div>
        </Col>
      </Row>
      <Row gutter={15}>
        <Col span={12}>
          <p>随意图形</p>
          <div id='randomCharts' style={ { width: '100%', height: 300 }}></div>
        </Col>
        <Col span={12}>
          <p>服务器数据</p>
          <div id='serverCharts' style={ { width: '100%', height: 300 }}></div>
        </Col>
      </Row>
    </>
  )
};

export default ECharts;

2.Highcharts

vue: https://www.highcharts.com.cn/docs/highcharts-vue

react: https://www.highcharts.com.cn/docs/highcharts-react

1
cnpm install highcharts highcharts-react-official -S
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
// src/views/data/HighCharts.tsx
import React, { FC, useEffect, useState } from 'react';
import * as Highcharts from 'highcharts';
import HighchartsReact from 'highcharts-react-official';

console.log(HighchartsReact)
interface IHighChartsProps {

};

const HighCharts:FC<IHighChartsProps> = (props: HighchartsReact.Props) => {
  const [option, setOption] = useState<any>({
		title: {
				text: '2010 ~ 2016 年太阳能行业就业人员发展情况'
		},
		subtitle: {
				text: '数据来源：thesolarfoundation.com'
		},
		yAxis: {
				title: {
						text: '就业人数'
				}
		},
		legend: {
				layout: 'vertical',
				align: 'right',
				verticalAlign: 'middle'
		},
		plotOptions: {
				series: {
						label: {
								connectorAllowed: false
						},
						pointStart: 2010
				}
		},
		series: [{
				name: '安装，实施人员',
				data: [43934, 52503, 57177, 69658, 97031, 119931, 137133, 154175]
		}, {
				name: '工人',
				data: [24916, 24064, 29742, 29851, 32490, 30282, 38121, 40434]
		}, {
				name: '销售',
				data: [11744, 17722, 16005, 19771, 20185, 24377, 32147, 39387]
		}, {
				name: '项目开发',
				data: [null, null, 7988, 12169, 15112, 22452, 34400, 34227]
		}, {
				name: '其他',
				data: [12908, 5948, 8105, 11248, 8989, 11816, 18274, 18111]
		}],
		responsive: {
				rules: [{
						condition: {
								maxWidth: 500
						},
						chartOptions: {
								legend: {
										layout: 'horizontal',
										align: 'center',
										verticalAlign: 'bottom'
								}
						}
				}]
		}
})
  useEffect(() => {
    window.addEventListener('resize',() => {
      setOption({
        title: {
            text: '2010 ~ 2016 年太阳能行业就业人员发展情况'
        },
        subtitle: {
            text: '数据来源：thesolarfoundation.com'
        },
        yAxis: {
            title: {
                text: '就业人数'
            }
        },
        legend: {
            layout: 'vertical',
            align: 'right',
            verticalAlign: 'middle'
        },
        plotOptions: {
            series: {
                label: {
                    connectorAllowed: false
                },
                pointStart: 2010
            }
        },
        series: [{
            name: '安装，实施人员',
            data: [43934, 52503, 57177, 69658, 97031, 119931, 137133, 154175]
        }, {
            name: '工人',
            data: [24916, 24064, 29742, 29851, 32490, 30282, 38121, 40434]
        }, {
            name: '销售',
            data: [11744, 17722, 16005, 19771, 20185, 24377, 32147, 39387]
        }, {
            name: '项目开发',
            data: [null, null, 7988, 12169, 15112, 22452, 34400, 34227]
        }, {
            name: '其他',
            data: [12908, 5948, 8105, 11248, 8989, 11816, 18274, 18111]
        }],
        responsive: {
            rules: [{
                condition: {
                    maxWidth: 500
                },
                chartOptions: {
                    legend: {
                        layout: 'horizontal',
                        align: 'center',
                        verticalAlign: 'bottom'
                    }
                }
            }]
        }
    })
    })
  }, [])
  return (
    <>
      <h1>HighCharts</h1>
      <HighchartsReact
        highcharts={Highcharts}
        options={option}
        {...props}
      />
    </>
  )
};

export default HighCharts;

3.antv - g2

https://antv-g2.gitee.io/zh

1
cnpm i @antv/g2 -S
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
// src/views/data/G2.tsx
import React, { FC, useEffect } from 'react';
import { Chart } from '@antv/g2';
interface IAntvProps {

};

const Antv:FC<IAntvProps> = () => {
  useEffect(() => {
    const data = [
      { type: '未知', value: 654, percent: 0.02 },
      { type: '17 岁以下', value: 654, percent: 0.02 },
      { type: '18-24 岁', value: 4400, percent: 0.2 },
      { type: '25-29 岁', value: 5300, percent: 0.24 },
      { type: '30-39 岁', value: 6200, percent: 0.28 },
      { type: '40-49 岁', value: 3300, percent: 0.14 },
      { type: '50 岁以上', value: 1500, percent: 0.06 },
    ];

    const chart = new Chart({
      container: 'antv',
      autoFit: true,
      height: 500,
      padding: [50, 20, 50, 20],
    });
    chart.data(data);
    chart.scale('value', {
      alias: '销售额(万)',
    });

    chart.axis('type', {
      tickLine: {
        alignTick: false,
      },
    });
    chart.axis('value', false);

    chart.tooltip({
      showMarkers: false,
    });
    chart.interval().position('type*value');
    chart.interaction('element-active');

    // 添加文本标注
    data.forEach((item) => {
      chart
        .annotation()
        .text({
          position: [item.type, item.value],
          content: item.value,
          style: {
            textAlign: 'center',
          },
          offsetY: -30,
        })
        .text({
          position: [item.type, item.value],
          content: (item.percent * 100).toFixed(0) + '%',
          style: {
            textAlign: 'center',
          },
          offsetY: -12,
        });
    });
    chart.render();
  }, [])

  return (
    <>
      <h1>Antv</h1>
      <div id="antv" style={{ width: 800, height: 600, backgroundColor: '#efefef' }}></div>
    </>
  )
};

export default Antv;

27.编辑器

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
// src/router/menu.tsx
import { IMenuProps } from './inter'
import {
  HomeOutlined,
  UploadOutlined,
  PictureOutlined,
  ProfileOutlined,
  OrderedListOutlined,
  FilterOutlined,
  TeamOutlined,
  UserOutlined,
  SettingOutlined
} from '@ant-design/icons'

import Home from '@/views/home/Index'

import Banner from '@/views/banner/Index'
import BannerList from '@/views/banner/List'
import BannerActive from '@/views/banner/Active'
import BannerAdd from '@/views/banner/Add'

import Product from '@/views/product/Index'
import ProductSearch from '@/views/product/Search'
import ProductList from '@/views/product/list/Index'
import ProductHomeList from '@/views/product/list/Home'
import ProductDetailList from '@/views/product/list/Detail'
import ProductCartList from '@/views/product/list/Cart'

import Account from '@/views/account/Index'
import UserList from '@/views/account/UserList'
import AdminList from '@/views/account/AdminList'

import Setting from '@/views/setting/Index'

import Data from '@/views/data/Index'
import ECharts from '@/views/data/ECharts'
import HighCharts from '@/views/data/HighCharts'
import Antv from '@/views/data/Antv'

import Editor from '@/views/editor/Index'
import {Braft} from '@/views/editor/Braft'
import {MarkDown} from '@/views/editor/MarkDown'

const menus: IMenuProps[] = [
  {
    label: '系统首页',
    key: '/',
    keyid: '0-0',
    icon: <HomeOutlined />,
    element: <Home />
  },
  {
    label: '轮播图管理',
    key: '/banner',
    keyid: '0-1',
    icon: <UploadOutlined />,
    // redirect: '/banner/home',
    element: <Banner />,
    children: [
      {
        label: '首页轮播图',
        key: '/banner/home',
        keyid: '0-1-0',
        icon: <PictureOutlined />,
        element: <BannerList />,
        index: 1
      },
      {
        label: '活动页轮播图',
        key: '/banner/active',
        keyid: '0-1-1',
        icon: <PictureOutlined />,
        element: <BannerActive />
      },
      {
        label: '添加轮播图',
        key: '/banner/add',
        keyid: '0-1-2',
        icon: <UploadOutlined />,
        element: <BannerAdd />,
        hidden: 1
      },
    ]
  },
  {
    label: '产品管理',
    key: '/pro',
    keyid: '0-2',
    icon: <ProfileOutlined />,
    element: <Product />,
    children: [
      {
        label: '产品列表',
        key: '/pro/list',
        keyid: '0-2-0',
        icon: <OrderedListOutlined />,
        element: <ProductList />,
        index: 1,
        children: [
          {
            label: '首页产品列表',
            key: '/pro/list/home',
            keyid: '0-2-0-0',
            element: <ProductHomeList />,
            index: 1
          },
          {
            label: '详情推荐列表',
            key: '/pro/list/detail',
            keyid: '0-2-0-1',
            element: <ProductDetailList />
          },
          {
            label: '购物车推荐列表',
            key: '/pro/list/cart',
            keyid: '0-2-0-2',
            element: <ProductCartList />
          },
        ]
      },
      {
        label: '筛选列表',
        key: '/pro/search',
        keyid: '0-2-1',
        icon: <FilterOutlined />,
        element: <ProductSearch />
      },
    ]
  },
  {
    label: '账户管理',
    key: '/account',
    keyid: '0-3',
    icon: <TeamOutlined />,
    element: <Account />,
    children: [
      {
        label: '用户列表',
        key: '/account/userlist',
        keyid: '0-3-1',
        icon: <UserOutlined />,
        element: <UserList />,
        index: 1
      },
      {
        label: '管理员列表',
        key: '/account/adminlist',
        keyid: '0-3-2',
        icon: <UserOutlined />,
        element: <AdminList />
      }
    ]
  },
  {
    label: '设置',
    key: '/setting',
    keyid: '0-4',
    icon: <SettingOutlined />,
    element: <Setting />,
    hidden: 1
  },
  {
    label: '数据可视化',
    key: '/data',
    keyid: '0-5',
    icon: <SettingOutlined />,
    element: <Data />,
    children: [
      {
        label: 'ECharts',
        key: '/data/echarts',
        keyid: '0-5-0',
        icon: <SettingOutlined />,
        element: <ECharts />,
        index: 1
      },
      {
        label: 'HighCharts',
        key: '/data/highcharts',
        keyid: '0-5-1',
        icon: <SettingOutlined />,
        element: <HighCharts />
      },
      {
        label: 'antv',
        key: '/data/antv',
        keyid: '0-5-2',
        icon: <SettingOutlined />,
        element: <Antv />
      }
    ]
  },
  {
    label: '编辑器',
    key: '/editor',
    keyid: '0-6',
    icon: <SettingOutlined />,
    element: <Editor />,
    children: [
      {
        label: '富文本编辑器',
        key: '/editor/braft',
        keyid: '0-6-0',
        icon: <SettingOutlined />,
        element: <Braft />,
        index: 1
      },
      {
        label: 'MarkDown',
        key: '/editor/md',
        keyid: '0-5-1',
        icon: <SettingOutlined />,
        element: <MarkDown />
      }
    ]
  }
]


export default menus

1.富文本编辑器

react版本： https://braft.margox.cn/demos/basic

1
cnpm i braft-editor -S
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
// src/views/editor/Index.tsx
import React, { FC } from 'react';
import { Outlet } from 'react-router-dom';

interface IEditorProps {

};

const Editor:FC<IEditorProps> = () => {
  return (
    <>
      <h1>编辑器</h1>
      <Outlet />
    </>
  )
};

export default Editor;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
// src/views/editor/Braft.tsx
import React, { useState } from 'react';
import 'braft-editor/dist/index.css'
import BraftEditor from 'braft-editor'

type BraftProps = {}

export const Braft = ({}: BraftProps) => {
  const [editorState, setEditorState] = useState<any>('')
  const [html, setHTML] = useState<any>('')
  const handleChange = (editorState: any) => {
    setEditorState(editorState)
    setHTML(editorState.toHTML())
  }
  return (
    <>
      <h3>富文本编辑器</h3>
      <BraftEditor
        value={editorState}
        onChange={handleChange}
      />
      <div>
        预览
        <div dangerouslySetInnerHTML={{ __html: html }}></div>
      </div>
    </>
  )
};

2.markDown编辑器

阅读器：https://www.npmjs.com/package/react-markdown

编辑器：https://www.npmjs.com/package/react-markdown-editor-lite

1
cnpm i react-markdown react-markdown-editor-lite -S
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
// src/views/editor/MarkDown.tsx
import React, { useState } from 'react';
import ReactMarkdown from 'react-markdown' // 阅读器
import MdEditor from 'react-markdown-editor-lite'; // 编辑器
// import style manually
import 'react-markdown-editor-lite/lib/index.css'; // 样式
type MarkDownProps = {}

export const MarkDown = ({}:MarkDownProps) => {
  const [content, setContent] = useState('')
  return (
    <>
      <h3>MarkDown编辑器</h3>
      <MdEditor style={{ height: '500px' }} renderHTML={text => {

        return <ReactMarkdown>{ text }</ReactMarkdown>
      }} onChange={ ( { html, text }: { html: any; text: any}) => {
        setContent(html)
      }} />
      <hr/>
      <div dangerouslySetInnerHTML={{ __html: content }}></div>
    </>
  );
}

28.导入以及导出

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
// src/views/excel/Index.tsx
import React, { FC } from 'react';
import { Outlet } from 'react-router-dom';

interface IIndexProps {

};

const Index:FC<IIndexProps> = () => {
  return (
    <Outlet></Outlet>
  )
};

export default Index;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/excel/Import.tsx
import React, { FC } from 'react';

interface IImportProps {

};

const Import:FC<IImportProps> = () => {
  return (
    <>
      <h3>导入数据</h3>
    </>
  )
};

export default Import;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// src/views/excel/Export.tsx
import React, { FC } from 'react';

interface IExportProps {

};

const Export:FC<IExportProps> = () => {
  return (
    <>
      <h3>导出数据</h3>
    </>
  )
};

export default Export;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
// src/router/menu.tsx
import { IMenuProps } from './inter'
import {
  HomeOutlined,
  UploadOutlined,
  PictureOutlined,
  ProfileOutlined,
  OrderedListOutlined,
  FilterOutlined,
  TeamOutlined,
  UserOutlined,
  SettingOutlined
} from '@ant-design/icons'

import Home from '@/views/home/Index'

import Banner from '@/views/banner/Index'
import BannerList from '@/views/banner/List'
import BannerActive from '@/views/banner/Active'
import BannerAdd from '@/views/banner/Add'

import Product from '@/views/product/Index'
import ProductSearch from '@/views/product/Search'
import ProductList from '@/views/product/list/Index'
import ProductHomeList from '@/views/product/list/Home'
import ProductDetailList from '@/views/product/list/Detail'
import ProductCartList from '@/views/product/list/Cart'

import Account from '@/views/account/Index'
import UserList from '@/views/account/UserList'
import AdminList from '@/views/account/AdminList'

import Setting from '@/views/setting/Index'

import Data from '@/views/data/Index'
import ECharts from '@/views/data/ECharts'
import HighCharts from '@/views/data/HighCharts'
import Antv from '@/views/data/Antv'

import Editor from '@/views/editor/Index'
import {Braft} from '@/views/editor/Braft'
import {MarkDown} from '@/views/editor/MarkDown'

import Excel from '@/views/excel/Index'
import Import from '@/views/excel/Import'
import Export from '@/views/excel/Export'

const menus: IMenuProps[] = [
  {
    label: '系统首页',
    key: '/',
    keyid: '0-0',
    icon: <HomeOutlined />,
    element: <Home />
  },
  {
    label: '轮播图管理',
    key: '/banner',
    keyid: '0-1',
    icon: <UploadOutlined />,
    // redirect: '/banner/home',
    element: <Banner />,
    children: [
      {
        label: '首页轮播图',
        key: '/banner/home',
        keyid: '0-1-0',
        icon: <PictureOutlined />,
        element: <BannerList />,
        index: 1
      },
      {
        label: '活动页轮播图',
        key: '/banner/active',
        keyid: '0-1-1',
        icon: <PictureOutlined />,
        element: <BannerActive />
      },
      {
        label: '添加轮播图',
        key: '/banner/add',
        keyid: '0-1-2',
        icon: <UploadOutlined />,
        element: <BannerAdd />,
        hidden: 1
      },
    ]
  },
  {
    label: '产品管理',
    key: '/pro',
    keyid: '0-2',
    icon: <ProfileOutlined />,
    element: <Product />,
    children: [
      {
        label: '产品列表',
        key: '/pro/list',
        keyid: '0-2-0',
        icon: <OrderedListOutlined />,
        element: <ProductList />,
        index: 1,
        children: [
          {
            label: '首页产品列表',
            key: '/pro/list/home',
            keyid: '0-2-0-0',
            element: <ProductHomeList />,
            index: 1
          },
          {
            label: '详情推荐列表',
            key: '/pro/list/detail',
            keyid: '0-2-0-1',
            element: <ProductDetailList />
          },
          {
            label: '购物车推荐列表',
            key: '/pro/list/cart',
            keyid: '0-2-0-2',
            element: <ProductCartList />
          },
        ]
      },
      {
        label: '筛选列表',
        key: '/pro/search',
        keyid: '0-2-1',
        icon: <FilterOutlined />,
        element: <ProductSearch />
      },
    ]
  },
  {
    label: '账户管理',
    key: '/account',
    keyid: '0-3',
    icon: <TeamOutlined />,
    element: <Account />,
    children: [
      {
        label: '用户列表',
        key: '/account/userlist',
        keyid: '0-3-1',
        icon: <UserOutlined />,
        element: <UserList />,
        index: 1
      },
      {
        label: '管理员列表',
        key: '/account/adminlist',
        keyid: '0-3-2',
        icon: <UserOutlined />,
        element: <AdminList />
      }
    ]
  },
  {
    label: '设置',
    key: '/setting',
    keyid: '0-4',
    icon: <SettingOutlined />,
    element: <Setting />,
    hidden: 1
  },
  {
    label: '数据可视化',
    key: '/data',
    keyid: '0-5',
    icon: <SettingOutlined />,
    element: <Data />,
    children: [
      {
        label: 'ECharts',
        key: '/data/echarts',
        keyid: '0-5-0',
        icon: <SettingOutlined />,
        element: <ECharts />,
        index: 1
      },
      {
        label: 'HighCharts',
        key: '/data/highcharts',
        keyid: '0-5-1',
        icon: <SettingOutlined />,
        element: <HighCharts />
      },
      {
        label: 'antv',
        key: '/data/antv',
        keyid: '0-5-2',
        icon: <SettingOutlined />,
        element: <Antv />
      }
    ]
  },
  {
    label: '编辑器',
    key: '/editor',
    keyid: '0-6',
    icon: <SettingOutlined />,
    element: <Editor />,
    children: [
      {
        label: '富文本编辑器',
        key: '/editor/braft',
        keyid: '0-6-0',
        icon: <SettingOutlined />,
        element: <Braft />,
        index: 1
      },
      {
        label: 'MarkDown',
        key: '/editor/md',
        keyid: '0-5-1',
        icon: <SettingOutlined />,
        element: <MarkDown />
      }
    ]
  },
  {
    label: '导入以及导出',
    key: '/excel',
    keyid: '0-7',
    icon: <SettingOutlined />,
    element: <Excel />,
    children: [
      {
        label: '导入',
        key: '/excel/import',
        keyid: '0-7-0',
        icon: <SettingOutlined />,
        element: <Import />,
        index: 1
      },
      {
        label: '导出',
        key: '/excel/export',
        keyid: '0-7-1',
        icon: <SettingOutlined />,
        element: <Export />
      }
    ]
  }
]


export default menus

1.导出

cnpm i js-export-excel -S

src/views/excel/test.d.ts

1
declare module 'js-export-excel'

本案例导出产品筛选列表的数据

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
// src/views/excel/Export.tsx
import React, { FC,useState, useEffect } from 'react';
import { Table, Space, Button, Image, Switch  } from 'antd'
import {
  DeleteOutlined
} from '@ant-design/icons'
import usePagination from '@/hooks/usePagination';
import { getProList, updateRecommend, updateSeckill } from '@/api/pro';

import ExportJsonExcel from 'js-export-excel'
interface IExportProps {

};
interface DataType {
  banners: string[]
  brand: string
  category: string
  desc: string
  discount: number
  img1: string
  img2: string
  img3: string
  img4: string
  isrecommend: number
  issale: number
  isseckill: number
  originprice: number
  proid: string
  proname: string
  sales: number
  stock: number
}
const Export:FC<IExportProps> = () => {
  const [height, setHeight] = useState(document.body.offsetHeight) // 计算body的高度
  useEffect(() => {
    window.addEventListener('resize', () => {
      setHeight(document.body.offsetHeight)
    })
  }, [])
  // 分页设置
  const config = usePagination({
    position: ['bottomLeft'],
    showSizeChanger: true,
    pageSizeOptions: [10, 20, 30, 40],
    showQuickJumper: true
  })


  const [list, setList] = useState([])
  const getProListData = () => {
    getProList().then(res => {
      console.log(res.data)
      setList(res.data.data)
    })
  }
  useEffect(() => {
    getProListData()
  }, [])
  return (
    <Space
      direction='vertical'
      style={ { display: 'flex' }}
    >
      <Button type='primary' onClick={ () => {// ++++++++
          let option: {
            fileName: string
            datas: {
              sheetData: DataType[],
              sheetName: string,
              sheetFilter: string[],
              sheetHeader: string[],
              columnWidths: number[]
            }[]
          };
          option = {
            fileName: "产品列表", // 导出的文件的名称
            datas: [
              {
                sheetData: list, // 表格数据
                sheetName: "产品列表1", // excel表格中表格的名字
                sheetFilter: ["proname", "img1",  "category"], // 需要导出的数据的字段
                sheetHeader: ["产品名称", "图片", "分类"], // 表头的值
                columnWidths: [20, 20],
              },
              {
                sheetData: list, // 表格数据
                sheetName: "产品列表2", // excel表格中表格的名字
                sheetFilter: ["proname", "img1",  "category", 'originprice'], // 需要导出的数据的字段
                sheetHeader: ["产品名称", "图片", "分类", '价格'], // 表头的值
                columnWidths: [20, 20],
              },
            ]
          }

          var toExcel = new ExportJsonExcel(option); //new
          toExcel.saveExcel(); //保存
        }}>导出数据</Button>
      <Table
        rowKey="proid"
        dataSource = { list }
        scroll = {{ y: height - 330 }}
        pagination = { config }
      >
        <Table.Column title="序号" render = { (_ ,record, index) => {
          return (
            <span>{ (config.current - 1) * config.pageSize +index + 1 }</span>
          )
        }}></Table.Column>
        <Table.Column title="图片" dataIndex="img1" render = { text => {
          return <Image src = { text} style={{ height: 80 }} />
        }}></Table.Column>
        <Table.Column title="商品名称" dataIndex="proname"></Table.Column>
        <Table.Column title="商品价格" dataIndex="originprice"></Table.Column>
        <Table.Column title="是否秒杀" dataIndex="isseckill" render={ (text, record: DataType) => {
          return (
            <Switch defaultChecked = { text === 1}  onChange={
              () => {
                console.log(text)
                updateSeckill({ proid: record.proid, flag: text === 0}).then(() => getProListData())
              }
            } />
          )
        }}></Table.Column>
        <Table.Column title="是否推荐" dataIndex="isrecommend" render={ (text, record: DataType) => {
          return (
            <Switch defaultChecked = { text === 1}  onChange={
              () => {
                updateRecommend({ proid: record.proid , flag: text === 0}).then(() => getProListData())
              }
            } />
          )
        }}></Table.Column>
        <Table.Column title="操作" render={ (_, record: DataType) => {
          return (
              <Button danger shape="circle" icon={<DeleteOutlined />}></Button>
          )
        }}></Table.Column>
      </Table>
    </Space>
  )
};

export default Export;

以上方案为纯前端的导出，实际上还有其余的导出方法，比如通过接口实现，前端可以通过a的href属性实现

2.导入

数据在 src/views/excel/pro.xlsx

1
cnpm install xlsx
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
// src/views/excel/Import.tsx
import { Button, Table, Switch, Image } from 'antd';
import { useState } from 'react'
import * as XLSX from 'xlsx';

type ImportProps = {}
interface DataType {
  proid: string
  proname: string
  img1: string
  originprice: number
  discount: number
  sales: number
  stock: number
  category: string
  brand: string
  issale: number
  isrecommend: number
  isseckill: number
}
export default function Import (props: ImportProps)  {
  const [proList, setProList] = useState([])
  const importExcel = () => { // 导入数据
    const file = (document.getElementById('fileRef') as HTMLInputElement).files![0]
    const reader = new FileReader()
    reader.readAsBinaryString(file!) // 转成 二进制格式
    reader.onload = function () {
      const workbook = XLSX.read(this.result, { type: 'binary' });
      const t = workbook.Sheets['list'] // 拿到表格数据
      // console.log(t)
      const r: any = XLSX.utils.sheet_to_json(t) // 转换成json格式
      // console.log(r)
      setProList(r)
      // 将r的数据上传至服务器
    }
  }


  return (
    <>
      <Button onClick={() => { // 触发文件选择器
        (document.getElementById('fileRef') as HTMLInputElement).click()
      }}>导入数据</Button>
      <input type="file" hidden id = 'fileRef' onChange = { importExcel }/>
      <Table dataSource={ proList }  rowKey = "proid" scroll={{ y: 600}}>
      <Table.Column
          title="序号"
          render={(text, record, index) => { return <span>{ index + 1 }</span>}}
        ></Table.Column>
        <Table.Column
          title="产品分类"
          dataIndex="category"
        ></Table.Column>
        <Table.Column
          title="产品品牌"
          dataIndex="brand"
        ></Table.Column>
        <Table.Column
          title="产品名称"
          dataIndex="proname"
        ></Table.Column>
        <Table.Column
          title="图片"
          dataIndex="img1"
          render={ (text) => {return <Image src={text} width={80} height={80} /> }}
        ></Table.Column>
        <Table.Column
          title="产品价格"
          dataIndex="originprice"
          sorter={(a: DataType, b: DataType) => a.originprice - b.originprice}
        ></Table.Column>
        <Table.Column
          title="产品折扣"
          dataIndex="discount"
          sorter={(a: DataType, b: DataType) => a.discount - b.discount}
        ></Table.Column>
        <Table.Column
          title="产品销量"
          dataIndex="sales"
          sorter={(a: DataType, b: DataType) => a.sales - b.sales}
        ></Table.Column>
        <Table.Column
          title="产品库存"
          dataIndex="stock"
          sorter={(a: DataType, b: DataType) => a.stock - b.stock}
        ></Table.Column>
        <Table.Column
          title="是否上架"
          dataIndex="issale"
          render={ (text) => {return <Switch checked = { text === 1 } /> }}
        ></Table.Column>
        <Table.Column
          title="是否推荐"
          dataIndex="isrecommend"
          render={ (text) => {return <Switch checked = { text === 1 } /> }}
        ></Table.Column>
        <Table.Column
          title="是否秒杀"
          dataIndex="isseckill"
          render={ (text) => {return <Switch checked = { text === 1 } /> }}
        ></Table.Column>

      </Table>

    </>
  )
}

如果在nodejs环境中,通过接口实现

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
const xlsx = require('node-xlsx').default;
// 导入excel表格的数据
router.get('/uploadPro', (req, res, next) => {
  const originData = xlsx.parse(`${__dirname}/pro.xlsx`);
  const firstData = originData[0].data
  const arr = []
  for (var i = 0; i < firstData.length; i++) {
    if (i !== 0) {
      arr.push({
        proid: 'pro_'+ uuid.v4(),
        category: firstData[i][0],
        brand: firstData[i][1],
        proname: firstData[i][2],
        banners: firstData[i][3],
        originprice: firstData[i][4],
        sales: firstData[i][5],
        stock: firstData[i][6],
        desc: firstData[i][7],
        issale: firstData[i][8],
        isrecommend: firstData[i][9],
        discount: firstData[i][10],
        isseckill: firstData[i][11],
        img1: firstData[i][12],
        img2: firstData[i][13],
        img3: firstData[i][14],
        img4: firstData[i][15],
      })
    }
  }
  // 拿到 arr 的数据，先清空 产品的表格数据，然后再插入
  mysql.delete(Product, {}, 1).then(() => { // 不要忘记写1，因为1 代表的是删除多条数据
    // 所有的数据已删除完成
    // 插入数据
    mysql.insert(Product, arr).then(() => {
      // 重定向到 商品的管理的页面路由
      res.send('导入数据成功') // 相当于浏览器自动跳转到了 /pro 的路由
    })
  })
})

29.地图

https://huiyan.baidu.com/github/react-bmapgl/#/%E5%BF%AB%E9%80%9F%E5%85%A5%E9%97%A8

https://lbsyun.baidu.com/

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
// src/views/map/Baidu.tsx
import React, { FC, useEffect } from 'react';

interface IBaiduProps {

};

const Baidu:FC<IBaiduProps> = () => {
  useEffect(() => {
    var map = new window.BMapGL.Map("container");
    map.centerAndZoom(new window.BMapGL.Point(116.404, 39.915), 11);

    var p1 = new window.BMapGL.Point(116.301934,39.977552);
    var p2 = new window.BMapGL.Point(116.508328,39.919141);

    var driving = new window.BMapGL.DrivingRoute(map, {renderOptions:{map: map, autoViewport: true}});
    driving.search(p1, p2);
  }, [])
  return (
    <>
      <div id="container" style={ {
        width: '100%', height: 500
      }}></div>
      <div id='result'>根据起点和终点经纬度驾车导航路线</div>
    </>
  )
};

export default Baidu;
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
// src/router/menu.tsx
import { IMenuProps } from './inter'
import {
  HomeOutlined,
  UploadOutlined,
  PictureOutlined,
  ProfileOutlined,
  OrderedListOutlined,
  FilterOutlined,
  TeamOutlined,
  UserOutlined,
  SettingOutlined
} from '@ant-design/icons'

import Home from '@/views/home/Index'

import Banner from '@/views/banner/Index'
import BannerList from '@/views/banner/List'
import BannerActive from '@/views/banner/Active'
import BannerAdd from '@/views/banner/Add'

import Product from '@/views/product/Index'
import ProductSearch from '@/views/product/Search'
import ProductList from '@/views/product/list/Index'
import ProductHomeList from '@/views/product/list/Home'
import ProductDetailList from '@/views/product/list/Detail'
import ProductCartList from '@/views/product/list/Cart'

import Account from '@/views/account/Index'
import UserList from '@/views/account/UserList'
import AdminList from '@/views/account/AdminList'

import Setting from '@/views/setting/Index'

import Data from '@/views/data/Index'
import ECharts from '@/views/data/ECharts'
import HighCharts from '@/views/data/HighCharts'
import Antv from '@/views/data/Antv'

import Editor from '@/views/editor/Index'
import {Braft} from '@/views/editor/Braft'
import {MarkDown} from '@/views/editor/MarkDown'

import Excel from '@/views/excel/Index'
import Import from '@/views/excel/Import'
import Export from '@/views/excel/Export'

import Baidu from '@/views/Map/Baidu'

const menus: IMenuProps[] = [
  {
    label: '系统首页',
    key: '/',
    keyid: '0-0',
    icon: <HomeOutlined />,
    element: <Home />
  },
  {
    label: '轮播图管理',
    key: '/banner',
    keyid: '0-1',
    icon: <UploadOutlined />,
    // redirect: '/banner/home',
    element: <Banner />,
    children: [
      {
        label: '首页轮播图',
        key: '/banner/home',
        keyid: '0-1-0',
        icon: <PictureOutlined />,
        element: <BannerList />,
        index: 1
      },
      {
        label: '活动页轮播图',
        key: '/banner/active',
        keyid: '0-1-1',
        icon: <PictureOutlined />,
        element: <BannerActive />
      },
      {
        label: '添加轮播图',
        key: '/banner/add',
        keyid: '0-1-2',
        icon: <UploadOutlined />,
        element: <BannerAdd />,
        hidden: 1
      },
    ]
  },
  {
    label: '产品管理',
    key: '/pro',
    keyid: '0-2',
    icon: <ProfileOutlined />,
    element: <Product />,
    children: [
      {
        label: '产品列表',
        key: '/pro/list',
        keyid: '0-2-0',
        icon: <OrderedListOutlined />,
        element: <ProductList />,
        index: 1,
        children: [
          {
            label: '首页产品列表',
            key: '/pro/list/home',
            keyid: '0-2-0-0',
            element: <ProductHomeList />,
            index: 1
          },
          {
            label: '详情推荐列表',
            key: '/pro/list/detail',
            keyid: '0-2-0-1',
            element: <ProductDetailList />
          },
          {
            label: '购物车推荐列表',
            key: '/pro/list/cart',
            keyid: '0-2-0-2',
            element: <ProductCartList />
          },
        ]
      },
      {
        label: '筛选列表',
        key: '/pro/search',
        keyid: '0-2-1',
        icon: <FilterOutlined />,
        element: <ProductSearch />
      },
    ]
  },
  {
    label: '账户管理',
    key: '/account',
    keyid: '0-3',
    icon: <TeamOutlined />,
    element: <Account />,
    children: [
      {
        label: '用户列表',
        key: '/account/userlist',
        keyid: '0-3-1',
        icon: <UserOutlined />,
        element: <UserList />,
        index: 1
      },
      {
        label: '管理员列表',
        key: '/account/adminlist',
        keyid: '0-3-2',
        icon: <UserOutlined />,
        element: <AdminList />
      }
    ]
  },
  {
    label: '设置',
    key: '/setting',
    keyid: '0-4',
    icon: <SettingOutlined />,
    element: <Setting />,
    hidden: 1
  },
  {
    label: '数据可视化',
    key: '/data',
    keyid: '0-5',
    icon: <SettingOutlined />,
    element: <Data />,
    children: [
      {
        label: 'ECharts',
        key: '/data/echarts',
        keyid: '0-5-0',
        icon: <SettingOutlined />,
        element: <ECharts />,
        index: 1
      },
      {
        label: 'HighCharts',
        key: '/data/highcharts',
        keyid: '0-5-1',
        icon: <SettingOutlined />,
        element: <HighCharts />
      },
      {
        label: 'antv',
        key: '/data/antv',
        keyid: '0-5-2',
        icon: <SettingOutlined />,
        element: <Antv />
      }
    ]
  },
  {
    label: '编辑器',
    key: '/editor',
    keyid: '0-6',
    icon: <SettingOutlined />,
    element: <Editor />,
    children: [
      {
        label: '富文本编辑器',
        key: '/editor/braft',
        keyid: '0-6-0',
        icon: <SettingOutlined />,
        element: <Braft />,
        index: 1
      },
      {
        label: 'MarkDown',
        key: '/editor/md',
        keyid: '0-5-1',
        icon: <SettingOutlined />,
        element: <MarkDown />
      }
    ]
  },
  {
    label: '导入以及导出',
    key: '/excel',
    keyid: '0-7',
    icon: <SettingOutlined />,
    element: <Excel />,
    children: [
      {
        label: '导入',
        key: '/excel/import',
        keyid: '0-7-0',
        icon: <SettingOutlined />,
        element: <Import />,
        index: 1
      },
      {
        label: '导出',
        key: '/excel/export',
        keyid: '0-7-1',
        icon: <SettingOutlined />,
        element: <Export />
      }
    ]
  },
  {
    label: '百度地图',
    key: '/map',
    keyid: '0-8',
    icon: <SettingOutlined />,
    element: <Baidu />
  }
]


export default menus
1
2
3
4
5
// src/views/map/map.d.ts.
interface Window {
  BMapGL: any
  BMAP_STATUS_SUCCESS: any
}
1
2
3
// public/index.html
 <title>React App</title>
    <script type="text/javascript" src="//api.map.baidu.com/api?type=webgl&v=1.0&ak=tvN3aLzFzvthpM9OwvsxmrSjD9dsdlbd"></script>

30.项目打包发布

https://blog.csdn.net/daxunshuo/article/details/102976306?spm=1001.2014.3001.5501

1
2
$ cnpm run build
# 估计需要一点时间请耐心等待

打包完毕项目 build 文件夹即为 项目打包出来的文件，只需要把build文件夹上传至服务器，一般情况下，都需要修改build文件夹的名字

如果打开 build/index.html 文件，发现 css js 文件的引入使用的都是绝对路径

如果服务器只部署这一个项目，那么可以把 build文件夹的内容替换了 服务器的静态资源文件 — 绝对路径

如果服务器部署多个项目，那么可以把修改过后的 build的文件夹上传到 服务器的静态资源文件 — 项目路径

如何打包项目时使用相对路径

package.json

1
2
3
{
	"homepage": '.'
}

http://121.89.205.189:2207/
